Micro800™ Non-isolated Unipolar Analog

Input Plug-in Module

Catalog Numbers 2080-IF2, 2080-IF4

http://literature.rockwellautomation.com

FR Cette publication est disponible en français sous forme électronique (fichier PDF).

Pour la télécharger, rendez-vous sur la page Internet indiquée ci-dessus.

IT Questa pubblicazione è disponibile in Italiano in formato PDF. Per scaricarla

collegarsi al sito Web indicato sopra.

DE Diese Publikation ist als PDF auf Deutsch verfügbar. Gehen Sie auf die oben

genannte Web-Adresse, um nach der Publikation zu suchen und sie

herunterzuladen.

ES Esta publicación está disponible en español como PDF. Diríjase a la dirección web

indicada arriba para buscar y descarga esta publicación.

PT Esta publicação está disponível em portugués como PDF. Vá ao endereço web que

aparece acima para encontrar e fazer download da publicação.

2Micro800™ Non-isolated Unipolar Analog Input Plug-in Module

Publication 2080-WD003A-EN-P - May 2011

Environment and Enclosure

Preventing Electrostatic Discharge

ATTENTION

This equipment is intended for use in a Pollution Degree 2 industrial

environment, in overvoltage Category II applications (as defined in IEC

60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment

is considered Group 1, Class A industrial equipment according to IEC/CISPR

11. Without appropriate precautions, there may be difficulties with

electromagnetic compatibility in residential and other environments due to

conducted and radiated disturbances.

This equipment is supplied as open-type equipment. It must be mounted

within an enclosure that is suitably designed for those specific environmental

conditions that will be present and appropriately designed to prevent personal

injury resulting from accessibility to live parts. The enclosure must have

suitable flame-retardant properties to prevent or minimize the spread of flame,

complying with a flame spread rating of 5V A, V2, V1, V0 (or equivalent) if

non-metallic. The interior of the enclosure must be accessible only by the use

of a tool. Subsequent sections of this publication may contain additional

information regarding specific enclosure type ratings that are required to

comply with certain product safety certifications.

In addition to this publication, see:

• Industrial Automation Wiring and Grounding Guidelines, Rockwell

Automation publication 1770-4.1, for additional installation

requirements.

• NEMA Standard 250 and IEC 60529, as applicable, for explanations of

the degrees of protection provided by different types of enclosure.

ATTENTION

This equipment is sensitive to electrostatic discharge, which can cause

internal damage and affect normal operation. Follow these guidelines when

you handle this equipment:

• Touch a grounded object to discharge potential static.

• Wear an approved grounding wriststrap.

• Do not touch connectors or pins on component boards.

• Do not touch circuit components inside the equipment.

• Use a static-safe workstation, if available.

• Store the equipment in appropriate static-safe packaging when not in

use.

Micro800™ Non-isolated Unipolar Analog Input Plug-in Module 3

Publication 2080-WD003A-EN-P - May 2011

North American Hazardous Location Approval

The following modules are North American Hazardous Location approved:

2080-IF2, 2080-IF4

The following information applies

when operating this equipment in

hazardous locations:

Informations sur l’utilisation de cet

équipement en environnements dangereux:

Products marked "CL I, DIV 2, GP A, B, C, D" are

suitable for use in Class I Division 2 Groups A,

B, C, D, Hazardous Locations and nonhazardous

locations only. Each product is supplied with

markings on the rating nameplate indicating the

hazardous location temperature code. When

combining products within a system, the most

adverse temperature code (lowest "T" number)

may be used to help determine the overall

temperature code of the system. Combinations

of equipment in your system are subject to

investigation by the local Authority Having

Jurisdiction at the time of installation.

Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne

conviennent qu'à une utilisation en environnements de

Classe I Division 2 Groupes A, B, C, D dangereux et non

dangereux. Chaque produit est livré avec des marquages

sur sa plaque d'identification qui indiquent le code de

température pour les environnements dangereux.

Lorsque plusieurs produits sont combinés dans un

système, le code de température le plus défavorable

(code de température le plus faible) peut être utilisé

pour déterminer le code de température global du

système. Les combinaisons d'équipements dans le

système sont sujettes à inspection par les autorités

locales qualifiées au moment de l'installation.

WARNING

EXPLOSION HAZARD

• Do not disconnect

equipment unless power

has been removed or the

area is known to be

nonhazardous.

• Do not disconnect

connections to this

equipment unless power

has been removed or the

area is known to be

nonhazardous. Secure any

external connections that

mate to this equipment by

using screws, sliding

latches, threaded

connectors, or other means

provided with this product.

• Substitution of any

component may impair

suitability for Class I,

Division 2.

• If this product contains

batteries, they must only be

changed in an area known

to be nonhazardous.

AVERTISSEMENT

RISQUE D’EXPLOSION

• Couper le courant ou s'assurer

que l'environnement est

classé non dangereux avant de

débrancher l'équipement.

• Couper le courant ou s'assurer

que l'environnement est

classé non dangereux avant de

débrancher les connecteurs.

Fixer tous les connecteurs

externes reliés à cet

équipement à l'aide de vis,

loquets coulissants,

connecteurs filetés ou autres

moyens fournis avec ce

produit.

• La substitution de tout

composant peut rendre cet

équipement inadapté à une

utilisation en environnement

de Classe I, Division 2.

• S'assurer que l'environnement

est classé non dangereux

avant de changer les piles.

4Micro800™ Non-isolated Unipolar Analog Input Plug-in Module

Publication 2080-WD003A-EN-P - May 2011

Parts List

Your package contains one Micro800 Non-isolated Unipolar Analog Input

Plug-in Module and these pinout guide wiring instructions.

You can choose to wire the plug-in before inserting it onto the controller, or

wire it once the module is secured in place.

ATTENTION

• This equipment is considered Group 1, Class A industrial equipment

according to IEC/CISPR 11. Without appropriate precautions, there may be

difficulties with electromagnetic compatibility in residential and other

environments due to conducted and radiated disturbance.

• Be careful when stripping wires. Wire fragments that fall into the controller

could cause damage. Once wiring is complete, make sure the controller is

free of all metal fragments before removing the protective debris strip.

• Do not wire more than 2 conductors on any single terminal.

• If you insert or remove the plug-in module while power is on, an electrical

arc can occur. This could cause an explosion in hazardous location

installations. Be sure that power is removed or the area is nonhazardous

before proceeding.

• Cable length should be less than 10 meters.

• Do not insert or remove the plug-in module while power is applied,

otherwise, permanent damage to equipment may occur.

45010

Micro800™ Non-isolated Unipolar Analog Input Plug-in Module 5

Publication 2080-WD003A-EN-P - May 2011

Wire the Module

Follow the pinout diagram to wire your plug-in module.

12-Pin Female Terminal Block

Insert Module into Controller

Follow the instructions to insert and secure the plug-in module to the

controller.

1. Position the plug-in module with the terminal block facing the front

of the controller as shown.

1 2 3 4

5 6

Back

Front 40511

(View into terminal block)

Pin A1 COM Pin A5 Not used Pin B3 COM

Pin A2 Not used Pin A6 Not used Pin B4 VI-1

Pin A3 Not used Pin B1 VI-0 Pin B5 CI-1

Pin A4 COM Pin B2 CI-0 Pin B6 COM

(View into terminal block)

Pin A1 COM Pin A5 VI-3 Pin B3 COM

Pin A2 VI-2 Pin A6 CI-3 Pin B4 VI-1

Pin A3 CI-2 Pin B1 VI-0 Pin B5 CI-1

Pin A4 COM Pin B2 CI-0 Pin B6 COM

2080-IF2

2080-IF4

44012

6Micro800™ Non-isolated Unipolar Analog Input Plug-in Module

Publication 2080-WD003A-EN-P - May 2011

2. Snap the module into the module bay.

3. Using a screwdriver, tighten the 10…12 mm (0.39…0.47 in.) M3 self

tapping screw to torque specifications.

Specifications

General and Environmental Specifications

Attribute Value

Mounting torque 0.2 Nm (1.48 lb-in)

Terminal screw torque 0.22…0.25 Nm (1.95…2.21 lb-in)

(using a 2.5 mm (0.10 in.) flat-blade screwdriver)

Wire size

Input impedence >100 kΩfor voltage mode

250 Ωfor current mode

Input voltage range 0…10V

Input current range 0…20 mA

Power consumption <60 mA @ 3.3V

Temperature, operating IEC60068-2-1 (Test Ad, Operating Cold),

IEC60068-2-2, (Test Bd, Operating Dry Heat),

IEC 60068-2-14 (Test Nb, Operating Thermal Shock):

-20...65 °C (-4…149 °F)

Temperature,

surrounding air, max. 65 °C (149 °F)

Temperature,

non-operating IEC60068-2-1 (Test Ad, Operating Cold),

IEC60068-2-2, (Test Bd, Operating Dry Heat),

IEC 60068-2-14 (Test Nb, Operating Thermal Shock):

-40...85 °C (-40…185 °F)

North American temp

code T4

Min Max

Solid 0.14 mm2 (26 AWG) 1.5 mm2 (16 AWG) rated @ 90 °C

(194 °F )

insulation max

Stranded 0.14 mm2 (26 AWG) 1.0 mm2 (18 AWG)

Micro800™ Non-isolated Unipolar Analog Input Plug-in Module 7

Publication 2080-WD003A-EN-P - May 2011

Certifications

Certification (when

product is marked)(1)

Value

c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada.

See UL File E322657.

UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations,

certified for U.S. and Canada. See UL File E334470.

CE European Union 2004/108/EC EMC Directive, compliant with:

EN 61326-1; Meas./Control/Lab., Industrial Requirements

EN 61000-6-2; Industrial Immunity

EN 61000-6-4; Industrial Emissions

EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)

European Union 2006/95/EC LVD, compliant with:

EN 61131-2; Programmable Controllers (Clause 11)

C-Tick Australian Radiocommunications Act, compliant with:

AS/NZS CISPR 11; Industrial Emissions

(1) See the Product Certification link at http://www.ab.com for Declarations of Conformity, Certificates,

and other certification details.

Rockwell Automation Support

Rockwell Automation provides technical information on the Web to assist you in using

its products. At http://support.rockwellautomation.com, you can find technical

manuals, a knowledge base of FAQs, technical and application notes, sample code and

links to software service packs, and a MySupport feature that you can customize to

make the best use of these tools.

For an additional level of technical phone support for installation, configuration, and

troubleshooting, we offer TechConnect support programs. For more information,

contact your local distributor or Rockwell Automation representative, or visit

http://support.rockwellautomation.com.

Installation Assistance

If you experience a problem within the first 24 hours of installation, please review the

information that's contained in this manual. You can also contact a special Customer

Support number for initial help in getting your product up and running.

New Product Satisfaction Return

Rockwell Automation tests all of its products to ensure that they are fully operational

when shipped from the manufacturing facility. However, if your product is not

functioning and needs to be returned, follow these procedures.

Allen-Bradley, Rockwell Automation, Micro800 and TechConnect are trademarks of Rockwell Automation, Inc.

Trademarks not belonging to Rockwell Automation are property of their respective companies.

United States 1.440.646.3434

Monday – Friday, 8 a.m. – 5 p.m. EST

Outside United States Please contact your local Rockwell Automation representative for any

technical support issues.

United States Contact your distributor. You must provide a Customer Support case number

(see phone number above to obtain one) to your distributor in order to

complete the return process.

Outside United States Please contact your local Rockwell Automation representative for the return

procedure.

Publication 2080-WD003A-EN-P - May 2011 PN 953203-23(01)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Rockwell Automation Unité de contrôle

Rockwell Automation

Rockwell Automation Allen-Bradley 1794-IRT8 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley Guard I/O DeviceNet 1732DS-IB8 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley PowerFlex 750 Series Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1718 Series Manuel utilisateur

Rockwell Automation

Rockwell Automation ArmorBlock Series Manuel utilisateur

Rockwell Automation

Rockwell Automation Reliance electric GV3000/SE Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley POINT I/O B Series Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 2198-R031 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley ControlLogix 1756-HSC Manuel utilisateur

Rockwell Automation

Rockwell Automation 1768-L43 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley Guard I/O DeviceNet 1732DS-IB8 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley PowerFlex 750 Series Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1794-OB8EPXT Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley ControlLogix DeviceNet... Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley DM2 Guide de l'utilisateur

Rockwell Automation

Rockwell Automation Sprecher + Schuh CEP7 Guide de l'utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1734-232ASC Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen Bradley Guardmaster Sipha 2 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1769-OF4 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1606-XLSCAP24-6 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley FLEX 5000 Series Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1734-IR2 Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley 1441-DYN25-MBAL Manuel utilisateur

Rockwell Automation

Rockwell Automation Allen-Bradley FLEX Integra Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
