Roborock Xiaowa Robotic Vacuum Cleaner Manual

Please read this manual carefully before using the product and store it properly

Safety Information

Restrictions

This product is designed for indoor floor cleaning only, do not use it outdoors (such

as on an open-ended terrace), on any surface other than the ground (such as a

sofa), or in any commercial or industrial environment

Do not use this product on elevated surfaces without barriers such as the floor of a

loft, an open-ended terrace, or on top of furniture

Do not use the product when the ambient temperature is higher than 40℃,lower

than 4℃, or if there are liquids or tacky substances on the floor

Before using the product, move wires off the ground or place them to the side to

prevent them being pulled on by the cleaner

To prevent blocking the product and to avoid damage to valuables, remove

lightweight items (such as plastic bags) and fragile objects (such as vases) from

the floor before cleaning

Children should be supervised to ensure that they do not interfere with the product

This product is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or a lack of experience and

knowledge, unless they have been given supervisor instruction concerning use

of the product by a person responsible for their safety（CB）

Safety Information

This product can be used by children aged age 8 years and above and persons

with reduced physical, sensory or mental capabilities or a lack of experience

and knowledge once they have been given supervision or instruction

concerning the safe use of the product and understand the hazards involved.

Children should not play with the appliance. Cleaning and maintenance should

not be carried out by children without supervision（EU）

Keep the main brush cleaning tools out of reach of children

Do not place any object (including children and pets) on the product, whether

it is in operation or not

Keep hair, loose clothing, fingers, and all parts of the body away from openings

and moving parts

Do not use the product on burning objects (such as cigarette butts)

Do not use the product on high pile carpets (product effectiveness may also be

reduced on dark carpets)

Do not use the product to clean hard or sharp objects (such as glass and nails)

Do not carry the product using the laser scanner cap, main unit cover, or collision

buffer

Safety Information

The product must be switched off and the plug must be removed from socket-

outlet before cleaning or maintaining the appliance

Do not use wet cloth or liquids for cleaning the product

Do not use the mopping module on carpets

Use the product according to the manual. Any loss or damage caused from

improper use will be borne by the user

Battery and Charging

WARNING

For the purposes of recharging the battery, only use the detachable supply Unit

Xiaowa CDZ03RR or CDZ04RR provided with this product

Do not dismantle, repair or modify the battery or charging dock

Keep the charging dock away from heat (such as heating vents)

The battery must be removed from the product before it is disposed of

The product must be disconnected from the mains supply when removing the

battery

The battery must be disposed of safely. Do not discard waste batteries. Leave them

with a professional recycling organization

Do not wipe or clean the charger prongs with wet cloth or wet hands

Safety Information

If the supply cord is damaged, it must be replaced by the manufacturer, its service

agent or similarly qualified persons in order to avoid a hazard

Make sure the product is powered off before shipment. Use of the original packaging

is advised

If to be left unused for a long period of time, fully charge the product and switch it off

before storing it in a cool, dry place. Charge it at least every three months to avoid

over discharging the battery

Table of Faults of Robotic Vacuum Cleaner

Item

Faults

Functions do not work

Main unit

Does not power on

Main brush, side brush, fan or main wheel issue

Charging dock

Main unit does not charge

Power cable

Charging dock has no power

Charging dock Xiaowa CDZ03RR/ CDZ04RR s Xiaowa C1

Rechargeable Li-on battery pack information

BRR-1P4S-2600S/BRR-1P4S-2600D

2600mAh/37.44Wh

Cell number

Introduction

Main unit

Spot cleaning

Press to start spot

cleaning

Clean/ON&OFF

Press to start cleaning

Press and hold to power

on or off

POWER light

White: battery capacity ≥

30%

Red: battery capacity ＜

30%

Slow flashing: Charging or

starting up

Flashing red: Error

Recharge

Press to return to charging

dock

Note: press any button to

pause cleaning,

recharging or spot cleaning

Reset WIFI

Press and hold and for 3 seconds

Cover latch

Introduction

Dust bin Main unit

Dustbin lid

Dustbin latch

Strainer

Accessories

Charging dock Main brush cleaning tool

WIFI indicator

Slow blinking:

Waiting to connect

Fast blinking: Connecting

Stable: WIFI is

connected

Air vent

Speaker

Power cable

Introduction

Main unit and sensors Charging dock

Charging dock

indicator

Signal transmission area

Infrared deceleration sensor

Power connector

Charging point Charging point

Cliff Sensor

Omni-directional

Omni-directional wheel

charging dock sensor

Charging contact points

Bumper

Side brush

Main wheels

Main brush

Main brush cover latch

Installation

1 Connect the power cable and use a cable

tie to clear excess wiring

2 Place the charging dock on a level surface, flat

against a wall, plugged into a power outlet.

More than 0.5 m

More than 1.5 m

Notes:

Leave at least 20in (50cm) either sides, and at least 60in (150cm) in front of the

charging dock

Poor placement may cause the charging dock to be dragged by the product,

causing power dropout.

The charging dock indicator light switches on when plugged into a power outlet,

and is off when the when main unit is being charged.

Placement in an open area will improve cleaning efficiency

3 Powering on and charging

Press and hold the button to power on, wait until the

power light sops flashing, then dock the main unit to the

charging dock to charge

The product is equipped with a high-performance lithium-

ion rechargeable battery. Keep the product charged for

maximum battery performance.

The color of the power light

indicates battery level

White: battery capacity ≥ 30%

Red: battery capacity ＜30%

Note: The product may not switch on when power is low.

Connect it to a charging dock before switching on.

4Connect to smartphone (optional)
