Ricoh IS330DC - IS - Flatbed Scanner Manuel utilisateur

7,19

Color Scanner

Setup Guide

ZDLH001E.eps

Read this manual carefully before you use this product and keep it handy for future

reference.

For safety, please follow the instructions in this manual.

7,19

Setup Guide

Printed in the Japan

EE GB G412-6661

7,19

Introduction

This manual contains detailed instructions on the operation and maintenance of this machine. To get

maximum versatility from this machine all operators should carefully read and follow the instructions in

this manual. Please keep this manual in a handy place near the machine.

Please read the Safety Information before using this machine. It contains important information related

to USER SAFETY and PREVENTING EQUIPMENT PROBLEMS.

Power Source

Color Scanner: 220 - 240V, 50/60 Hz, 4.5 A or more

Please be sure to connect the Power Cord to a power source as above.

Two kinds of size notation are employed in this manual. With this machine refer to the metric version.

Important

Parts of this manual are subject to change without prior notice. In no event will the company be liable

for direct, indirect, special, incidental, or consequential damages as a result of handling or operating

the machine.

Caution:

Use of controls or adjustment or performance of procedures other than those specified in this manual

might result in hazardous radiation exposure.

Do not attempt any maintenance or troubleshooting other than that mentioned in this manual. This

scanner contains a laser beam generator and direct exposure to laser beams can cause permanent

eye damage.

Ricoh shall not be responsible for any damage or expense that might result from the use of parts other

than genuine Ricoh parts in your Ricoh office product.

7,19

Declaration of Conformity

“The Product complies with the requirements of the EMC Directive 89/336/EEC and the Low Voltage

Directive 73/23/EEC.”

In accordance with IEC 60417, this machine uses the following symbols for the main power switch:

ameans POWER ON.

bmeans POWER OFF.

Ricoh Aficio Color Scanner IS330DC

7,19

Trademarks

Microsoft®, Windows®and Windows NT®are registered trademarks of Mi-

crosoft Corporation in the United States and/or other countries.

Other product names used herein are for identification purposes only and might

be trademarks of their respective companies. We disclaim any and all rights in

those marks.

Notes:

Some illustrations might be slightly different from your machine.

Certain options might not be available in some countries. For details, please con-

tact your local dealer.

Note

The proper names of the Windows operating systems are as follows:

•Microsoft

®Windows®95 operating system

•Microsoft

®Windows®98 operating system

•Microsoft

®Windows®Millennium Edition (Windows Me) operating system

•Microsoft

®Windows®2000 Professional

•Microsoft

®Windows®2000 Server

•Microsoft

®Windows NT®Server operating system Version 4.0

•Microsoft

®Windows NT®Workstation operating system Version 4.0

•Microsoft

®Windows NT®Server network operating system version 3.51

•Microsoft

®Windows NT®work station operating system version 3.51

7,19

Safety Information

When using your scanner, the following safety precautions should always be

followed.

Safety During Operation

In this manual, the following important symbols are used:

RWARNING:

WARNING:

Indicates a potentially hazardous situation which, if instructions

are not followed, could result in death or serious injury.

CAUTION:

Indicates a potentially hazardous situation which, if instructions are

not followed, may result in minor or moderate injury or damage to

property.

•Connect the Power Cord directly into a wall outlet and never use an extension cord.

•Disconnect the power plug (by pulling the plug, not the cable) if the power cable or plug

becomes frayed or otherwise damaged.

•To avoid hazardous electric shock or laser radiation exposure, do not remove any covers

or screws other than those specified in this manual.

•Turn off the power and disconnect the power plug (by pulling the plug, not the cable) if

any of the following conditions exists:

•You spill something into the equipment.

•You suspect that your equipment needs service or repair.

•Your equipment's cover has been damaged.

•Disposal can take place at our authorized dealer or at appropriate collection sites.

7,19

iii

RCAUTION:

Lithium Batteries (Memory Back-up)

RWARNING:

•Protect the equipment from dampness or wet weather, such as rain, snow, and so on.

•Unplug the Power Cord from the wall outlet before you move the equipment.

While moving the equipment, you should take care that the Power Cord will not be dam-

aged under the equipment.

•When you disconnect the power plug from the wall outlet, always pull the plug (not the

cable).

•Do not allow paper clips, staples, or other small metallic objects to fall inside the equip-

ment.

•For environmental reasons, do not dispose of the equipment or expended supply waste

at household waste collection points. Disposal can take place at an authorized dealer or

at appropriate collection sites.

•The inside of the machine could be very hot. Do not touch the parts with a label indicating

the "hot surface". Otherwise it could cause a personal burn.

•Our products are engineered to meet high standards of quality and functionality, and we

recommend that you only use the expendable supplies available at an authorized dealer.

•Do not try to replace the lithium batteries by yourself. A battery of this type can explode

if incorrectly replaced. If the lithium batteries need to be replaced, contact an authorized

dealer to request servicing.

•Never dispose of the lithium batteries by incineration. This can cause them to rupture re-

sulting in injury.

Note

❒Please return used NIC boards to our authorized dealer or service representative.

Your cooperation with our recycling activities is appreciated.

❒NIC boards are equipped with a lithium battery. In the case NIC boards are disposed

of by the customer, please dispose them in accordance with national or local regula-

tions after separating the lithium batteries from the NIC board.

7,19

Energy Star Program

❖

❖❖

❖Energy Saver mode

This unit automatically lowers its power consumption at a predetermined

time (approximately 15 minutes) after the last operation was performed. To

operate the unit from this mode, see the instructions below.

•Method for clearing

•Put a document on the Document Tray.

•Open the cover of the Automatic Document Feeder (ADF).

•Open the White Sheet cover.

•Follow the instructions from the PC.

Note

❒The Energy Saver mode does not work in the following conditions.

•When an optional device is attached.

•When an error occurs.

•When a document is placed on the Document Tray.

❖

❖❖

❖Specifications

As an ENERGY STAR Partner, we have determined

that this machine model meets the ENERGY STAR

Guidelines for energy efficiency.

The ENERGY STAR Guidelines intend to establish an international energy-saving system for

developing and introducing energy-efficient office equipment to deal with environmental is-

sues, such as global warming.

When a product meets the ENERGY STAR Guidelines for energy efficiency, the Partner shall

place the ENERGY STAR logo onto the machine model.

This product was designed to reduce the environmental impact associated with office equip-

ment by means of energy-saving features, such as Low-power mode.

Energy Saver mode Power consumption Approx. 11W

Transitional interval 15 minutes

7,19

Manuals for This Scanner

The following manuals describe the operational and maintenance procedures of

this machine.

To enhance safe and efficient operation of this scanner, all users should read and

follow the instructions carefully.

❖

❖❖

❖Quick Installation Guide

Describes how to install the scanner.

❖

❖❖

❖Setup Guide (this manual)

Provides information about setting up the scanner and its options. This man-

ual is provided as a printed manual, and also as a PDF file on the CD-ROM.

❖

❖❖

❖Scanner Reference

Provides information about using the scanner. This manual is provided as a

PDF file.

Note

❒There is a CD-ROM that comes with this scanner.

7,19

How to Read This Manual

Symbols

In this manual, the following symbols are used:

WARNING:

This symbol indicates a potentially hazardous situation which, if instructions

are not followed, could result in death or serious injury.

CAUTION:

This symbol indicates a potentially hazardous situation which, if instructions

are not followed, may result in minor or moderate injury or damage to property.

* The statements above are notes for your safety.

Important

If this instruction is not followed, paper might be misfed, originals might be

damaged, or data might be lost. Be sure to read this.

Preparation

This symbol indicates the prior knowledge or preparations required before op-

erating.

Note

This symbol indicates precautions for operation, or actions to take after misop-

eration.

Limitation

This symbol indicates numerical limits, functions that cannot be used together,

or conditions in which a particular function cannot be used.

Reference

This symbol indicates a reference.

[]

Keys that appear on the machine's panel display.

Keys and buttons that appear on the computer's display.

{}

Keys built into the machine's operation panel.

Keys on the computer's keyboard.
