RICOH Ri 4000

Option Platen

User Guide

For Hat Platen/Shoe Platen/Sleeve Platen

Face Covering Platen

TABLE OF CONTENTS RICOH Ri 4000

User Manual

TABLE OF CONTENTS

TABLE OF CONTENTS .......................................................................................................... 2

How to Read the Manuals ..................................................................................................... 3

Before You Begin.............................................................................................................................. 3

Disclaimer ......................................................................................................................................... 3

Notes................................................................................................................................................. 3

1. Printing Method ................................................................................................................ 4

1.1. Target Printer.................................................................................................................................... 4

1.2. Setup Printer..................................................................................................................................... 4

1.3. Printing method for Textile Productionserver ................................................................................... 4

2. Appendix ......................................................................................................................... 11

2.1. Revision history .............................................................................................................................. 11

How to Read the Manuals RICOH Ri 4000

User Manual

How to Read the Manuals

Before You Begin...

Only appropriately trained users should operate the machine.

Disclaimer

Contents of this manual are subject to change without prior notice.

To the maximum extent permitted by applicable laws, in no event will the manufacturer be liable for any

damages whatsoever arising out of failures of this machine, losses of the registered data, or the use or

non-use of this machine and operation manuals provided with it.

Make sure that you always copy or have backups of the data registered in this machine. Documents or

data might be erased due to your operational errors or malfunctions of the machine.

In no event will the manufacturer be responsible for any documents created by you using this machine or

any results from the data executed by you.

Notes

Read this manual carefully before you use the machine and keep it handy for future reference.

For safe and correct use, be sure to read Safety Information before using the machine.

The manufacturer will not be responsible for any damage or expense that might result from the use of

parts other than genuine parts from the manufacturer with your products.

For good output quality, the manufacturer recommends that you use genuine ink from the manufacturer.

Some illustrations in this manual may be slightly different from the machine.

Certain options may not be available in some countries. For details, please contact your local dealer.

Depending on which country you are in, certain units may be optional. For details, please contact your

local dealer.

Printing Method RICOH Ri 4000

User Manual

1. Printing Method

1.1. Target Printer

This document applies only to Ricoh genuine platen only.

1.2. Setup Printer

Refer to Ricoh Ri series Direct to Garment Printer Manual.

1.3. Printing method for Textile Productionserver

Start Textile Productionserver.

Input the image to Textile Productionserver.

Please set with Textile Productionserver according to the platen type.

Platen type Textile Productionserver

Hat a) User select Media size

(*1)

Sleeve a) User select Media size

Shoe a) User select Media size

b) User set Offset/Scaling

Face Covering a) User select Media size

b) User set Offset/Scaling

Printing Method RICOH Ri 4000

User Manual

(CAUTION *1)

The image is printed 180 degrees inverted from the display on the Textile

Productionserver.

In that case, the user should set 180 degrees.

The print settings are below.

Default Settings: After Set Rotate(180 degree)

Printing Method RICOH Ri 4000

User Manual

a) User select Media size

Textile Productionserver:

b) User set Offset/Scaling

♦For “Shoe Platen”

According to type of Shoe Attachment, user set Height x Width, Offset x, y.

Offset Y

Printer

Distance between printable

areas

Printable Area (Width)

Offset X

Printable Area (Height)

Printing Method RICOH Ri 4000

User Manual

If you want to print on both feet, please prepare the following image and set Offset x,y.

Offset of each Shoe attachement

Shoe

Attachment

Offset

(Reference)

Printable Area(Width x Height)

(Reference)

Distance between printable areas

Small

X:20 Y:220

85 x 150 mm

205 mm

Medium

X:40 Y:360

50 x 50 mm

40 mm

Large

X:40 Y:350

60 x 60 mm

40 mm

Setting method of Textile Productionserver:

Printing Method RICOH Ri 4000

User Manual

Default Settings: After Set Offset(X =40, Y=350)

♦For “Face Covering Platen”

User set Height x Width, Offset x, y.

IMPORTANT! If you print with “Printing on the entire surface” method, depending on image, it

may print to the area outside the platen.

In the figure below, it may be printed in the red area.

Offset Y (Back side)

Printable Area (Width)

Offset X

Printable Area (Height)

Offset Y (Back side)

Printer

Printable Area (Height)

Printable Area (Width)

Printing on the

entire surface:

Printing one side

surface:

Offset X

Offset Y (Front side)

Printing Method RICOH Ri 4000

User Manual

Offset of Face Covering Platen

Printing Method

(Reference)

Offset

(Reference)

Printable Area(Width x Height)

Printing on the entire surface

[Front side]

X: 40

Y: 100

[Back side]

X: 40

Y: 275

330 x 120 mm

Printing one side surface

[Front side]

X: 10

Y: 90

[Back side]

X: 10

Y: 265

385 x 140 mm

If you want to print on multiple media, please prepare the following image and set Offset

x,y.

Setting method of Productionserver:

See page 6 "For “Shoe Platen”".

Adjust the platen height.

For details on height adjustment, see the user manual.

Send the print job to the printer.

For details, refer to the ColorGATE Productionserver help or user manual.

Printing Method RICOH Ri 4000

User Manual

After the print preview appears on the preview window, press [PRINT START].
