Ricoh M109 Manuel

Ti-P1 Training

Slide 1

M109

Service Training

Ti-P1

Version 1.1

This course explains the low-end color A3 printer Ti-P1.

Version 1.1: Changes were made to the following slides

3, 12, 13, 17, 19, 22, 24, 34, 35, 44, 47, 49, 50, 65, 97, 101, 107, 117, 118

Ti-P1 Training

Slide 2

M109

Service Training

Product Overview

This section provides an overview of the machine, and the options that can be

installed.

Ti-P1 Training

Slide 3

What Models are there in the Series?

Ti-P1a (M109)

32 ppm

Low-end A3 printer

GW+ Controller (2012 Autumn)

Contains PostScript3, Gigabit Ethernet, duplex

unit, and bypass tray as standard equipment.

Main points

LED print head

QSU fusing unit

Eco night sensor

Maintenance can be done by users

No additional notes

Ti-P1 Training

Slide 4

Appearance

Up to three one-tray feed units can be installed (not shown

here).

Duplex and bypass are standard.

There are no finishers.

There is no external USB/SD card slot by the operation

panel.

One paper tray

is standard

No additional notes

Ti-P1 Training

Slide 5

Options: Paper Feed

Also used with these

new models:

500 sheetsNewOne-tray paper feed unit

(M406): TK2000

NoteSimilar to:

There are no finishers.

Ti-P1 Training

Slide 6

Options: Printer

160 GBM417: Hard Disk Drive Option Type C730

M417: IPDS Unit Type C730

M417: Memory Unit Type N 1GB

M417: SD card for NetWare Printing Type M

D417: Camera Direct Print Card Type L

Note

There is no RPCS driver.

Ti-P1 Training

Slide 7

Options: Controller

M417: IEEE 802.11

Interface Unit Type O

AL-P2

Also used with these

new models:

Requires the optional

hard disk

M417: VM Card Type W

B679: IEEE 1284 Interface

Board Type A

Note

No Bluetooth option

VM card: requires optional HDD

Ti-P1 Training

Slide 8

Controller Options

Memory Upgrade Options

Optional hard disk

160 GB

Memory

Standard memory: 512 MB

Upgrades: 1 GB memory card option

» There is only one slot for memory. To upgrade to 1 GB,

remove the standard 512 GB memory and install the 1

GB memory option.

Max possible memory: 1 GB

No additional notes

Ti-P1 Training

Slide 9

Ports on the Controller Board

1. USB port A: Connect external

devices such as a digital

camera, a card

authentication device, etc.

Use of a digital camera

requires the Camera

Direct Print option.

2. Expansion card slots:

Remove the cover to install

SD cards.

3. Optional interface board slot:

Insert an optional wireless

LAN interface board or IEEE

1284 interface board.

4. USB port B: Use a USB cable

to connect the printer to a

computer.

5. Ethernet port: Use a network

interface cable to connect

the printer to a network.

Board Slot: One of the following can be installed.

¾IEEE 802.11a/g Interface Unit Type J or IEEE 802.11g Interface Unit

Type K

¾IEEE 1284 Interface Board Type A

The SD Card slots are discussed in more detail on the next few slides.

Use of a digital camera requires the Camera Direct Print SD card option.

There is a mini USB slot behind the screw above item 4 in the diagram. This

is for designer purposes only.

Ti-P1 Training

Slide 10

SD Card Slots (1)

Slot 1 (upper slot):

The slot is empty when shipped

Use when installing the following options

» Camera direct print

» SD card for Netware printing

»VMcard

If the number of options that you wish to install is

more than the number of available SD card slots,

move them onto one SD card.

» Destination card: SD slot 1

If more than one SD card options must be

merged, and the VM card is one of them, the VM

card must be the target SD card.

» The VM card option cannot be moved.

Installation > Controller Options

PDF Direct/PCL/PostScript 3 are pre-installed in the Controller Firmware.
