Renesas RL78/G11 Manuel utilisateur

RL78/G11 Target Board

YQB-R5F1057A-TB User's Manual

The YQB-R5F1057A-TB is a target board used for evaluating microcontroller operations using a Renesas E1 or E2 Lite

on-chip debugging emulator / flash programmer.

1. RL78/G11 target board (YQB-R5F1057A-TB) features

•Incorporates RL78/G11 (R5F1057AANA).

•Equipped with universal area (2.54mm pitch).

•Supports both flash memory programming and on-chip debugging (using TOOL0 pin).

•Highly extendable; peripheral board connector used to access microcontroller pins.

•Lead-free (Pb-free) product.

2. Hardware Specifications

CPU R5F1057AANA

High Speed On-Chip Oscillator

48MHz to 1MHz

Crystal Oscillator Connection

20MHz HC-49 (Not Fitted)

Embedded parts

CN2 : Peripheral board connector (2.54mm pitch), 24 pin socket (pads only).

CN1 : 14-pin connector (for E1 or E2 Lite connection)

Power LED : Red x 1(POWERLED)

Test LED : Yellow x 2 (LED1 connected to P52, LED2 connected to P51).

Test Switch : SW1 (connected to P137 / INTP0).

Main clock : Internal HOCO up to 48MHz. Provision for 20MHz HC-49 crystal at

position X1 (not fitted, also requiring links at R11, R12 and 18pF capacitors at C2, C3).

Operating voltage

1.6V to 5.5V

3. Dimensions and Parts Layout

On-Board Link options: Removing the small (0402) 0Ωlink resistors leaves open the relevant circuit (see schematic).

To reconnect the circuit, short the link resistor pads by soldering or reconnecting link resistor.

Link resistor positions are shown on the PCB silkscreen.

4. Product Support:

5. Limitation of Warranty

The foregoing warranty does not cover damage caused by accidental misuse, abuse, neglect, misapplication or

modification. No warranty of fitness for a particular purpose is offered. The user assumes the entire risk of using the

product. Any liability of Renesas Electronics Europe is limited exclusively to the replacement of defective media,

materials or workmanship.

R20UT3915EG0100

Rev.1.00

Oct 25,2016

14 pin

Connector for

E1 or E2 Lite

38.1mm

55.88mm

CN2

Power LED

71.12mm

Universal

Area

LED1

LED2

Test Switch

SW1

Online technical support and information is available at http://www.renesas.com

Page 1 of 2

R20UT3915EG0100 Rev.1.00

Oct 25,2016

(DNF)

POWERLED

LED1 LED2

CN1

yellow

red

yellow

Size Document Number

Title

Date:

RESET_INTOOL0

RESET_OUT

Vss

RESET IN

RSTPU

P20_ANI0_AVREFP

R5F1057AANA

(DNF)

header 16way

(DNF)

header 16way

(DNF)

16 15

P52_INTP7

P51_INTP8

P33_ANI18

P32_ANI19

Tue Aug 09 15:40:13 2016 PAGE 1 OF 21.00

1413

1211

109

1615

1413

1211

109

TP7

TP6

1TP4

1TP5

IC1

TP1

TP2

TP3

P32_ANI19

1K0

P40_TOOL0

1K0

(DNF)

20.000 MHz

P122

P22_ANI12

P23_ANI13

P33_ANI18

P30_ANI21

P125_RESET

(DNF)

header 16way

P40_TOOL0

P54_TXD0

P53_INTP6

P30_ANI21

P55_RXD0

P20_ANI0_AVREFP

P137_INTP0

Fiducial_1mm

P56_ANI22_SCK0

P125_RESET

P23_ANI13

P22_ANI12

P21_ANI1_AVREFM

P121

P01_ANI16

P31_ANI20

header 16way

P00_ANI17

P01_ANI16

P122

P31_ANI20

P21_ANI1_AVREFM

header 14way shrouded SMD

P00_ANI17

(DNF)

P121

EXPOSE

P125/_RESET/INTP9

P40/TOOL0/TO03/(PCLBUZ0)/SCK10/SCL10/VCOUT0/VCOUT1/INTFO/(SCLA1)

P00/ANI17/PCLBUZ1/TI03/(VCOUT1)/SI10/RXD1/SDA10/(SDAA1)

P01/ANI16/INTP5/SO10/TXD1

P20/ANI0/AVREFP/IVREF1/(SO10/TXD1)

P21/ANI1/AVREFM/IVREF0 P56/ANI22/KR2/SCK00/SCL00/(SO11)/INTP10/(TO03)/(INTFO)/SCLA1

P55/KR3/SI00/RXD0/SDA00/TOOLRXD/TI02/TO02/INTP11/(VCOUT0)/SDAA1

P54/KR4/SO00/TXD0/TOOLTXD/(TI03)/(TO03)/SCLA0

P53/KR5/INTP6/SO01/SDAA0

P52/KR6/INTP7/SI01/SDA01/(RXD0)/(SDAA0)

P51/KR7/INTP8/(TI02)/(TO02)/SCK01/SCL01/(TXD0)

CNX1

CNX4

CNX2

CNX5 CNX6

CNX3

CN2

VDDVDD

VDD

1615

1413

1211

109

1615

1413

1211

109

1615

1413

1211

109

1615

1413

1211

109

1615

1413

1211

109

1615

1413

1211

109

1413

1211

109

2423

2221

2019

1817

1615

1413

1211

109

1 2 3 4 5 6 7 8 9

IOIO

Electronics Europe GmbH

User LEDs

User Switch

Connection

E1/E2 Lite

RL78/G11 Target Board

A3 R20UT3915EG0100

Uncommitted array of pins

Power / Analogue / Vref

Configuration

MCU Port Connections

RL78/G11 Target Board

Mouser Electronics

Authorized Distributor

Click to View Pricing, Inventory, Delivery & Lifecycle Information:

Renesas Electronics:

YQB-R5F1057A-TB
