Renault VelSatis Manuel utilisateur

NU739_4_Gcv-FRA.qxd 12/01/06 9:56 Page Couv4

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_Tcv-ENG.win 17/3/2006 13:09 -page1

RENAULT s.a.s. Société par Actions Simplifiée au capital de 533 941 113 / 13-15, quai Le Gallo - 92100 Boulogne-Billancourt

R.C.S. Nanterre 780 129 987 - SIRET 780 129 987 03591 / Tél. : 0810 40 50 60

Driver's handbook – 82 00 642 027 – NU 739-4 – 12/2005 – Edition anglaise

8200642027

NU739_4_Gcv-FRA.qxd 12/01/06 9:56 Page Couv2

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_Tcv-ENG.win 17/3/2006 13:09 -page2

has chosen ELF

For all engines

For all petrol engines

For all engines except

3.0 dCi diesel

and 2.2 dCi with

particulate filter

Manual gearbox

Automatic gearbox

ELF EXCELLIUM LDX 5W-40 ACEA A3 / B3 / B4

Optimum performance and maximum protection in the most severe conditions

All types of driving

ELF EVOLUTION SXR 5W-40 ACEA A3 / B3 / B4

Optimum performance

All types of driving

ELF EVOLUTION SXR 5W-30 ACEA A5 / B5

Fuel economy, engine protection and respect for the environment

All types of driving

ELF COMPETITION ST 10W-40

ELF TURBO DIESEL 10W-40 ACEA A3 / B3 / B4

ACEA B3 / B4

Other RENAULT approved lubricants for normal use

TRANSELF TRP 75W-80 API GL5

Please contact your RENAULT Dealer

RENAULT recommends approved ELF lubricants.

When topping up or changing the oil, we recommend you use only the original lubricants.

Consult your RENAULT Dealer or visit the site www.lubricants.elf.com

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.01

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page1

0.01

WelcometoyournewRENAULT

This driver’s handbook contains the information necessary to:

• enable you to get to know your RENAULT, to use it to its full potential and to benefit from all the latest technical

developments which are incorporated into it.

• ensure that it always gives the best performance by following the simple, but comprehensive advice concerning regular

maintenance.

• enable you to deal quickly with minor faults not requiring specialist attention.

It is well worth taking a few minutes to read this manual to familiarise yourself with the information and guidelines it

contains about the vehicle and its innovative features. If certain points are still unclear, the technicians in our Network will

be only too pleased to provide you with any additional information you may require.

The following symbol will help you when reading this handbook:

To indicate a hazard, danger or safety advice.

The description of the models given in this manual is based on the technical specifications at the time of writing. This

handbook covers all equipment (both standard and optional) available for these models, but whether or not this is fitted

to the vehicle depends on the version, options selected and the country in which the vehicle is sold.

This handbook may also contain information about items of equipment to be introduced later in the model year.

Enjoy driving your new RENAULT.

Copying or translation, in part or in full, is forbidden unless prior written permission has been obtained from RENAULT, 92100 Billancourt 2005.

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.02

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page2

0.02

Brief overview

•Tyre pressures ............................................................................................ 0.04 ➟0.07

•RENAULT card: use .................................................................................. 1.02 ➟1.09

•Child restraint/seat .................................................................................... 1.35 ➟1.46

•Warning lights (instrument panel) .......................................................... 1.50 ➟1.65

•Driving ........................................................................................................ 2.02 ➟2.42

•Starting/stopping the engine .................................................................... 2.03 ➟2.06

Assisted parking brake ......................................................................... 2.11 ➟2.13

Tyre Pressure Monitor .......................................................................... 2.18 ➟2.21

Electronic Stability Program: ESP ......................................................... 2.22 - 2.23

Traction control system .......................................................................... 2.24 - 2.25

Emergency brake assist ..................................................................................... 2.28

Cruise control/Speed limiter ............................................................... 2.29 ➟2.35

Parking proximity sensor ..................................................................... 2.36 ➟2.39

•Air conditioning ........................................................................................ 3.02 ➟3.13

•Bonnet/maintenance .................................................................................. 4.02 ➟4.12

•Practical advice (changing bulbs, fuses, breakdown, faults) ................ 5.02 ➟5.35

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.03

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page3

0.03

CONTENTS

Sections

Getting to know your vehicle ............................................................

Driving ...............................................................................................................

Your comfort .................................................................................................

Maintenance ..................................................................................................

Practical advice ...........................................................................................

Technical specifications ........................................................................

Alphabetical index ....................................................................................

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.04

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page4

0.04

TYRE PRESSURES inbarorkg/cm²(when cold)

Versions fitted with 17”wheels 2.0 T 3.5 V6 2.0 dCi

2.2 dCi 3.0 dCi

Non-motorway use

•Front 2.1 2.2 2.2 2.3

•Rear 2.0 2.0 2.0 2.0

Motorway use (1)

•Front 2.2 2.5 2.3 2.4

•Rear 2.0 2.0 2.0 2.0

Emergency spare wheel 3.7

Wheel rim sizes 7J17-5.5J17(sparewheel)

Tyre sizes 225/55 R 17 W - 185/60 R 17 C (spare wheel)

Tyre safety and snow chains

Refer to the information on Tyres in Section 5 for information on maintenance and, depending on the version, the

conditions under which snow chains may be used.

(1) Special note concerning vehicles used under full load (Maximum Permissible All-Up Weight) and towing a trailer.

The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 0.2 bar.

Refer to the information on Weights in Section 6 for more details.

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.05

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page5

0.05

TYRE PRESSURES inbarorkg/cm²(when cold) (continued)

Versions fitted with 18”wheels 2.0 T 3.5 V6 2.0 dCi

2.2 dCi 3.0 dCi

Non-motorway use

•Front 2.1 2.3 2.3 2.4

•Rear 2.0 2.0 2.0 2.0

Motorway use (1)

•Front 2.2 2.6 2.4 2.5

•Rear 2.0 2.0 2.0 2.0

Emergency spare wheel 3.7

Wheel rim sizes 7.5 J 18 - 5.5 J 17 (spare wheel)

Tyre sizes 245/45 R 18 W - 185/60 R 17 C (spare wheel)

Tyre safety and snow chains

Refer to the information on Tyres in Section 5 for information on maintenance and, depending on the version, the

conditions under which snow chains may be used.

(1) Special note concerning vehicles used under full load (Maximum Permissible All-Up Weight) and towing a trailer.

The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 0.2 bar.

Refer to the information on Weights in Section 6 for more details.

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.06

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page6

0.06

TYRE INFLATION PRESSURE in PSI (when cold)

Versions fitted with 17”wheels 2.0 T 3.5 V6 2.0 dCi

2.2 dCi 3.0 dCi

Non-motorway use

•Front 30323233

•Rear 29 29 29 29

Motorway use (1)

•Front 32363335

•Rear 29 29 29 29

Emergency spare wheel 47

Wheel rim sizes 7J17-5,5J17(sparewheel)

Tyre sizes 225/55 R 17 W - 185/60 R 17 C (spare wheel)

Tyre safety and snow chains

Refer to the information on Tyres in Section 5 for information on maintenance and, depending on the version, the

conditions under which snow chains may be used.

(1) Special note concerning vehicles used under full load (Maximum Permissible All-Up Weight) and towing a trailer.

The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 3PSI.

Refer to the information on Weights in Section 6 for more details.

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.07

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page7

0.07

TYRE PRESSURES in PSI (when cold) (continued)

Versions fitted with 18”wheels 2.0 T 3.5 V6 2.0 dCi

2.2 dCi 3.0 dCi

Non-motorway use

•Front 30333335

•Rear 29 29 29 29

Motorway use (1)

•Front 32383536

•Rear 29 29 29 29

Emergency spare wheel 47

Wheel rim sizes 7,5 J 18 - 5,5 J 17 (spare wheel)

Tyre sizes 245/45 R 18 W - 185/60 R 17 C (spare wheel)

Tyre safety and snow chains

Refer to the information on Tyres in Section 5 for information on maintenance and, depending on the version, the

conditions under which snow chains may be used.

(1) Special note concerning vehicles used under full load (Maximum Permissible All-Up Weight) and towing a trailer.

The maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 3PSI.

Refer to the information on Weights in Section 6 for more details.

NU739_4_G1-FRA.qxd 19/01/06 11:56 Page 0.08

NU739-4 - B73 C:\Documentum\Checkout\NU739_4_T1-ENG.win 20/3/2006 13:30 -page8

0.08
