Reed Instruments R1600 Manuel utilisateur
www.REEDInstruments.com
Instruction
Manual
R1600
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
1 YEAR
1 AN
G
A
R
A
N
T
I
E
G
A
R
A
N
T
I
E
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
G
A
R
A
N
T
I
E
G
A
R
A
N
T
I
E
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
G
A
R
A
N
T
I
E
G
A
R
A
N
T
I
E
White background
Transparentbackground
White
Black
1 YEAR1AN
Vane
Anemometer
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Table of Contents
Introduction ................................................................................................ 3
Product Quality ........................................................................................... 3
Safety ......................................................................................................... 3
FCC Statement ........................................................................................... 4
FCC RF Exposure Statement ................................................................. 4
IC statement ............................................................................................... 5
IC RF Exposure Statement .................................................................... 5
Features ...................................................................................................... 6
Included ...................................................................................................... 6
Specification .......................................................................................... 7-8
Instrument Description ............................................................................... 9
Display Description .................................................................................. 10
REED Smart Series................................................................................... 11
Operating Instructions ......................................................................... 12-13
Power ON/OFF .................................................................................... 12
Backlight .............................................................................................. 12
Establishing Bluetooth® Connection .................................................... 12
Selecting the Temperature and Air Velocity Unit of Measure ............... 13
Enabling/Disabling Data Hold .............................................................. 13
Toggling between Relative Humidity and Air Velocity Mode ................ 13
Enabling/Disabling Auto Power OFF .................................................... 13
Battery Replacement ................................................................................ 14
Applications .............................................................................................. 14
Accessories and Replacement Parts ....................................................... 14
Product Care ............................................................................................ 15
Product Warranty ..................................................................................... 15
Product Disposal and Recycling .............................................................. 15
Product Support ....................................................................................... 16
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Introduction
Thank you for purchasing your REED R1600 Vane Anemometer, Bluetooth
®
Smart Series. Please read the following instructions carefully before using
your instrument. By following the steps outlined in this manual your meter
will provide years of reliable service.
Product Quality
This product has been manufactured in an ISO9001 facility and has been
calibrated during the manufacturing process to meet stated product
specifications. If a certificate of calibration is equired, please contact the
nearest authorized REED distributor or authorized Service Center. Please
note an additional fee for this service will apply.
Safety
• Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.
Servicing should only be provided by an authorized service center.
• Magnetic field warning; please keep a minimum distance of 4 inche
(10cm) between pacemaker and meter.
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: Any changes or modifications not exp essly approved by
the party responsible for compliance could void the user's authority to
operate this equipment.
FCC RF Exposure Statement
This product complies with FCC portable RF exposure limit set forth for
an uncontrolled environment and is safe for the intended operation as
described in this manual.
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
IC statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic Development Canada’s licence-
exempt RSS(s). Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that
may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
CAN ICES-003(B)/NMB-003(B)
IC RF Exposure Statement
This product complies with the Canadian portable RF exposure limit
set forth for an uncontrolled environment and is safe for the intended
operation as described in this manual.
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Features
• Measures air velocity (m/s, ft/min, km/h and mph), air temperature
and humidity
• Easy to operate, designed for one hand operation
• Integrated display provides flexibility for use without mobile devic
• Magnetic backing allows instrument to be mounted to metallic surfaces
• Data Hold function
• Low battery indicator and auto shut off
• Tripod mount for long-term monitoring
When used with REED Smart Series App:
• Calculates air volume
• Real-time data logger
• User selectable sampling rate from 1 to 120 seconds
• Bluetooth® 5.0 provides connectivity to instruments up to
246' (75m) away
• Connect, measure and datalog up to 6 instruments, simultaneously
• Easy setup with automatic app integration for compatible REED Smart
Series instruments
• Export data via Excel or PDF and create custom reports that can be
emailed from mobile device
Included
• Vane Anemometer
• 4 x AAA Batteries
• Protective Cap
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Specifications
Air Velocity (Anemometer)
Measuring Range: fpm: 118 to 4921
m/s: 0.6 to 25
km/h: 2.1 to 90
mph:1.3 to 55.9
Accuracy: fpm: ±(40fpm +3.5%)
m/s: ±(0.2m/s +3.5%)
km/h: ±(0.8km/h +3.5%)
mph: ±(0.5mph +3.5%)
Resolution: fpm:1
m/s: 0.1
km/h: 0.1
mph: 0.1
Temperature
Measuring Range: -4 to 140°F (-20 to 60°C)
Accuracy: -4 to 32°F (-20 to 0°C):±1.6°F (0.8°C)
32 to 140°F (0 to 60°C):±1°F (0.5°C)
Resolution: 0.1°F/°C
Humidity
Measuring Range: 0 to 100% RH
Accuracy: 20 to 80% RH: ±3.5% rdg.
0 to 20% & 80 to 100% RH: ±5% rdg.
Resolution: 0.1% RH
General Specifications
Display: Multi-Line Enhanced Black Twisted
Nematic (EBTN) LCD
Display Size: 1.3" (34mm)
Backlit Display: Yes
Data Hold: Yes
Datalogging Capabilities: Yes (with Smart Series App)
continued...
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Real-Time Clock and Date Stamp: Yes (with Smart Series App)
Customizable Sampling Rate: Yes
Overrange Indicator: Yes
Auto Shut-off: Yes (adjustable)
Tripod Mountable:
Yes
Magnetic Backing: Yes
Low Battery Indicator: Yes
Power Supply: 4 x AAA Batteries
Battery Life: Approx. 50 hours
(sampling time dependent)
Connectivity: Bluetooth® 5.0
Bluetooth® Range: Up to 246' (75m)
Max # of Connected Devices: 6
Software: REED Smart Series App
(iOS and Android)
App Supported Languages: English, French
Product Certifications
CE, UKCA, FCC, IC ID
Maximum Operating Altitude: 6561' (2000m)
Operating Temperature: -4 to 122°F (-20 to 50°C)
Storage Temperature: -4 to 140°F (-20 to 60°C)
Operating Humidity Range: 10 to 90%
Storage Humidity Range: 10 to 90%
Dimensions: 6.9 x 1.5 x 1" (175 x 38 x 25mm)
Weight: 3.8oz (108g)
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Instrument Description
1. Air Flow Sensor
2. Temperature and
Humidity Sensor
3. LCD Display
4. POWER/HOLD Button
5. Bluetooth® Status
Indicator Light
6. Tripod Mounting Screw
7. Battery Cover Lock
8. Battery Cover
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Display Description
1. Temperature
Measurement Value
2. Air Velocity/
Relative Humidity
Measurement Value
3. Air Velocity Unit of Measure
4. Humidity Unit of Measure
5. Temperature Unit
of Measure
6. Data Hold Indicator
7. Bluetooth® Indicator
8. Low Battery Indicator
www.calcert.com sales@calcert.com1.888.610.7664 0
5
10
15
20
25
30
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Reed Instruments Instrument de mesure
Reed Instruments
Reed Instruments SMART Series Manuel utilisateur
Reed Instruments
Reed Instruments HT-6510A Manuel utilisateur
Reed Instruments
Reed Instruments LM-81AM Manuel utilisateur
Reed Instruments
Reed Instruments R4700SD Manuel utilisateur
Reed Instruments
Reed Instruments R7150 Manuel utilisateur
Reed Instruments
Reed Instruments R6200 Manuel utilisateur
Reed Instruments
Reed Instruments SMART Series Manuel utilisateur
Reed Instruments
Reed Instruments R7000SD Manuel utilisateur
Reed Instruments
Reed Instruments R1620 Manuel utilisateur
Reed Instruments
Reed Instruments R8180 Manuel utilisateur
Reed Instruments
Reed Instruments R8085 Manuel utilisateur
Reed Instruments
Reed Instruments R9930 Manuel utilisateur
Reed Instruments
Reed Instruments R5065 Manuel utilisateur
Reed Instruments
Reed Instruments R8008 Manuel utilisateur
Reed Instruments
Reed Instruments Smart Series Manuel utilisateur
Reed Instruments
Reed Instruments Smart Series Manuel utilisateur
Reed Instruments
Reed Instruments R9510 Manuel utilisateur
Reed Instruments
Reed Instruments R3000SD Manuel utilisateur
Reed Instruments
Reed Instruments R8070SD Manuel utilisateur
Reed Instruments
Reed Instruments R7700 Manuel utilisateur
Manuels Instrument de mesure populaires d'autres marques
Endress+Hauser
Endress+Hauser Proline Promag 50 Caractéristiques techniques
Siemens
Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces
KLINGER
KLINGER CMF V Series Manuel utilisateur
EXFO
EXFO FTB-2 Manuel d'exploitation et d'entretien
Keysight
Keysight M8290A Manuel utilisateur
ADTEK
ADTEK MW-5 Manuel utilisateur
