RAISE 3D N1 Manuel utilisateur
N1
Quick Start Guide
N-Series 3D Printer
* Please review this entire guide before operating the printer.
N-Series 3D Printer
/ Quick Start Guide
AList of Parts
N1
Touch Screen
Nozzle(s)
Fan(s)
Z-Stage
Print Bed
Filament Feeder
Z Ball Screws
Power Inlet
Power Switch
USB Storage & SD Card Slot
GPIO Ports
N-Series 3D Printer
/ Quick Start Guide
BHardware Installation
Please remove the 24 clips holding the
extruder assembly in place before power-
ing on your printer. If you fail to remove
these clips your printer will be damaged.
Please save these clips and re-install them
if you transport your printer.
Remove!
3
(×24)
Untie the rope which fastens the accessory
box.
4
Recommend to unclip the Zipties as you
are able to reuse the ties later.
2
Remove!
Take the power cable out from the left
foam box for later using.
1
Remove!
N-Series 3D Printer
/ Quick Start Guide
BHardware Installation (continued)
The printer will go through a start-up
sequence. When the touch screen displays
"Home", the printer is ready.
6
When the Z axis return to original position,
gently lift the build plate gently with your
hands and remove the accessory bag
under the build plate and open it for
standby.
8
Plug in the power plug and turn the switch
on.
5
Select the “Utilities” menu on the screen.
Press Z “Home” button to raise the Z ball
screws to the highest point.
7
N-Series 3D Printer
/ Quick Start Guide
BHardware Installation (continued)
List of Contents
Spatula
Filament
(×1/×2)*
Filament Holder
(×1/×2)*
Nozzle
Cleaning Kit
Glass with
Protective Foam
Hex Wrenches
2.5mm 2mm 1.5mm3mm
Feeler GageFan Cover
(×0/×2)*
Tweezers
USB Storage
Filament Guide
Tube (×2/×4)*
Fuse
15A
10A
Build Plate Clips Filament Guide
Tube Holder
Other Accessories
(Spare)
* Due to the difference between single and dual extrusion machines, the quantity of some of the products
received will be different.
Besides, there is only one fan cover in the printer with single extruder and it is has already been equipped
to the printer.
N-Series 3D Printer
/ Quick Start Guide
BHardware Installation (continued)
Remove the glass build plate from the
protective foam.
9
Gently slide the glass plate. Make sure it
snaps into the build plate clamps at the
back.
NOTE: Place the surface which posted with
BuildTak upwards, while the yellow label is at the
back left corner. Make sure it snaps into the build
plate clamps in this way.
10
Remove the remaining build plate clips
from the accessory box and secure them
to the glass and heated bed plate.
NOTE: The best distance between the glass clip
and the edge of print platform is 5cm.
11
Protective Foam
Cover Build Plate Remove!
5cm5cm
N-Series 3D Printer
/ Quick Start Guide
B Hardware Installation (continued)
Install the filament holder in the mounting
hole on the side of the printer and place a
spool of filament on the holder.
NOTE: The filament should load clockwise.
A
B
14
Mounting
holes
Please follow the instructions of “Bed
Leveling Steps” on the screen and use the
feeler to adjust the build plate. Make sure
the distance between the nozzle and the
plate are all even at four corners. The best
condition is that you can feel a little
friction when you slide the feeler into the
gap.
12
Feeler Gage
“Bed Leveling Steps” could be viewed by
clicking the “Leveling” button on the
“Utilities” interface. Follow the instruction
on the screen and operate step by step
until the end.
13
N-Series 3D Printer
/ Quick Start Guide
BHardware Installation (continued)
Feed the filament through the guide tube.
16
Push the filament down to the feed gear
until the gear grips the filament.
NOTE: For your first set of prints please use the
left nozzle only. The printer has been pre-cali-
brated based on printing with the left nozzle in
the factory. If you want to print with the right
nozzle or dual extrufers, please follow the
instructions on aligning both extruders found
here: https://www.raise3d.com/pages/faq.
17
Press the “Utilities” menu on the screen
and set the temperature of the left nozzle
for the filament, then press the “Load”
button. Finish the feeding operation step
by step according to the instructions on
the screen.
NOTE: This document is set based on the
Raise3D PLA filament, which is delivered
together with the printer. Therefore we advise
that you use this PLA for testing.
15
N-Series 3D Printer
/ Quick Start Guide
CideaMaker Installation
Open the installer and choose the language. Set a path for installing ideaMaker then
click "Next".
1
The ideaMaker software is
available on the USB storage
included with your printer.
Or go to www.raise3d.com and
download the ideaMaker
software.
www.raise3d.com
Download ideaMaker
WINDOWS
N-Series 3D Printer
/ Quick Start Guide
Click "Finish" and ideaMaker is installed.
Follow the instructions and click "Install". After the installation is finished, click "Next" to
go to the next step.
2
3
CideaMaker Installation (continued)
