03 Video Configuration and Preview - VBOX HD Lite
Available on iOS & Android
You can use the VBOX HD Lite preview app to fine-tune
the image on your VBOX HD Lite unit so that you get the
quality of video you need for your test.
Notes:
•The Wi-Fi dongle needs to be connected to the
device before you boot it up to make the VBOX
Video app work.
•The use of the dongle and the VBOX Video app is
for setup ONLY. The VBOX HD Lite will not log data
while the dongle is connected.
Connect
1. Download and open the VBOX HD Lite app from
the app store.
2. Plug in the WiFi dongle.
3. Connect your device to the HD Lite WiFi network.
Network name: HDLite_xxxxxx
Password: 1234567890
4. Open the HD Lite preview app.
5. Connect your camera.
Configuration
When the app has connected to the HD Lite unit, you will see the home page of the app showing the video feed from the
HD Lite unit along with the different available video settings you can use to configure the video from your HD Lite unit.
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_HD_Lite/VBOX_HD_Lite_User_Guide/
02_Video_Configuration_and_Preview_-_VBOX_HD_Lite
2
Saturation
You can change the video
saturation on a scale of 1
to 10. The video feed will
preview the saturation as
you move between the
different levels.
Contrast
You can change the video
contrast on a scale of 1 to
10. The video feed will
preview the contrast as
you move between the
different levels.
Sharpness
You can change the video
sharpness on a scale of 1
to 10. The video feed will
preview the sharpness as
you move between the
different levels.
Brightness
You can change the video
brightness on a scale of 1
to 10. The video feed will
preview the brightness as
you move between the
different levels.
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_HD_Lite/VBOX_HD_Lite_User_Guide/
02_Video_Configuration_and_Preview_-_VBOX_HD_Lite
3
White Balance
You can change the white
balance for the video. You
can choose between
Auto,Sunny,Cloudy,
Fluorescent Light or
Incandescent Light. The
video feed will preview the
white balance as you
select the different
options.
Exposure Value
You can change the
exposure value in the
video on a scale of - 2 to +
2. The video feed will
preview the exposure as
you move between the
different levels.
Field of View
You can change the field
of view for the video. You
can choose between
Wide,Medium
and Narrow. The
video feed will preview the
field of view as you select
the different options.
Metering Mode
You can change the
metering mode for the
video. You can choose
between Average
metering,Centre-
weighted
metering and Spot
metering. The video feed
will preview the metering
as you select the different
options.
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_HD_Lite/VBOX_HD_Lite_User_Guide/
02_Video_Configuration_and_Preview_-_VBOX_HD_Lite
4
Gallery
Tap the Gallery icon to open the gallery and view the
available videos and photos.
Full screen
Tap the full-screen icon to set the video to cover the full
screen on the device.
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_HD_Lite/VBOX_HD_Lite_User_Guide/
02_Video_Configuration_and_Preview_-_VBOX_HD_Lite
5
App Settings
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_HD_Lite/VBOX_HD_Lite_User_Guide/
02_Video_Configuration_and_Preview_-_VBOX_HD_Lite
6
Wide Dynamic Range (WDR)
This setting can improve the overall image exposure
under extreme backlight to show the natural effect. Tap
on the setting switch to toggle it on or off.
Volume
Tap on this setting to open it and select the volume level
you wish to use, on a scale of 1 to 5.
Note: The HD Lite does not have an external
microphone. It relies on a microphone inside the sealed
unit, which can make the audio distorted and low
volume.
Wi-Fi Settings
Wi-Fi Name
Change the name of the Wi-Fi network for the HD Lite
unit.
Wi-Fi password
Change the password for the Wi-Fi network for the HD
Lite unit.
MicroSD Card
Micro SD Card capacity
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_HD_Lite/VBOX_HD_Lite_User_Guide/
02_Video_Configuration_and_Preview_-_VBOX_HD_Lite
7
This setting will show you how much space you have
available on the inserted media.
Restore factory settings
Select this setting to Restore the app settings to the
factory settings.
When the factory settings have been restored
successfully, you will be asked to power cycle the HD
Lite unit.
Application version
This setting will display the version of the app on your
device.
Power-Cycle the HD Lite
To prepare the HD Lite to log after the video configuration, you must disconnect the power supply, disconnect the Wi-Fi
dongle and reconnect the power supply. This will make the HD Lite reboot in logging mode.
Press the Record button to start recording. Be aware that even though the LED will change to blue immediately, there
will be a logging delay of five seconds.
NOTE: The Record only when moving logging strategy will make the VBOX HD Lite start recording when the vehicle is
travelling over 15 km/h and will stop the recording once the vehicle has travelled under 15 km/h for 10 seconds.
IMPORTANT
• Never remove the SD card while the device is recording (blue LED). This can lead to loss of data/video and you
may have to repair the card on a PC before you can use it again.
• If you have stopped the vehicle, but the record light (blue LED) is still on, press the Record button to stop the
logging before you eject the SD card.
• The box may start recording even if the car is stationary in areas with poor satellite visibility. Always check the
LED to see that the device is not recording before you eject the SD card.
