Quectel EC2 Series Instructions d'installation

EC2x&EG9x&EM05 SMTP

AT Commands Manual

LTE Module Series

Rev. EC2x&EG9x&EM05_SMTP_AT_Commands_Manual_V1.0

Date: 2017-12-08

Status: Released

www.quectel.com

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 1 / 31

Our aim is to provide customers with timely and comprehensive service. For any

assistance, please contact our company headquarters:

Quectel Wireless Solutions Co., Ltd.

7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China

Tel: +86 21 5108 6236

Email: [email protected]om

Or our local office. For more information, please visit:

http://quectel.com/support/sales.htm

For technical support, or to report documentation errors, please visit:

http://quectel.com/support/technical.htm

Or Email to: support@quectel.com

GENERAL NOTES

QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION

PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT

TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT

MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT

ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR

RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO

CHANGE WITHOUT PRIOR NOTICE.

THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF

QUECTEL CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION AND EDITING OF THIS

DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE FORBIDDEN WITHOUT

PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF DAMAGES. ALL RIGHTS

ARE RESERVED IN THE EVENT OF A PATENT GRANT OR REGISTRATION OF A UTILITY MODEL

OR DESIGN.

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 2 / 31

About the Document

History

Revision

Date

Author

Description

1.0

2017-12-08

Duke XIN/

Haley HUANG

Initial

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 3 / 31

Contents

About the Document...................................................................................................................................2

Contents.......................................................................................................................................................3

Table Index...................................................................................................................................................4

1Introduction..........................................................................................................................................5

1.1. Introduction about SSL Type...................................................................................................5

1.2. The Process of Sending Email................................................................................................6

1.3. Description of Data Mode........................................................................................................7

2Description of SMTP AT Commands.................................................................................................8

2.1. AT+QSMTPCFG Configure Parameters for SMTP Server..................................................8

2.2. AT+QSMTPDST Add or Delete Recipients........................................................................10

2.3. AT+QSMTPSUB Edit the Subject of an Email ...................................................................12

2.4. AT+QSMTPBODY Edit the Body of an Email.....................................................................13

2.5. AT+QSMTPATT Add or Delete Attachments for an Email..................................................15

2.6. AT+QSMTPCLR Clear the Content of an Email.................................................................16

2.7. AT+QSMTPPUT Send an Email.........................................................................................17

3Examples ............................................................................................................................................19

3.1. Send an Email without SSL...................................................................................................19

3.2. Send an Email with SSL........................................................................................................21

3.3. Send an Email with STARTTLS ............................................................................................22

4Error Handling....................................................................................................................................24

4.1. Executing SMTPAT Command Fails....................................................................................24

4.2. PDPActivation Fails..............................................................................................................24

4.3. DNS Parse Fails....................................................................................................................25

4.4. Error Response ofAT+QSMTPPUT......................................................................................25

5Summary of Error Codes ..................................................................................................................26

6Summary of SMTP Protocol Error Codes .......................................................................................28

7Appendix A References.....................................................................................................................30

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 4 / 31

Table Index

TABLE 1: SUMMARY OF ERROR CODES ...................................................................................................... 26

TABLE 2: SUMMARY OF SMTP PROTOCOL ERROR CODES...................................................................... 28

TABLE 3: RELATED DOCUMENTS.................................................................................................................. 30

TABLE 4: TERMS AND ABBREVIATIONS........................................................................................................ 30

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 5 / 31

1Introduction

Quectel EC2x&EG9x&EM05 modules provide SMTP application interface for sending emails. This

document is a reference guide to all the AT commands defined for SMTP.

This document is applicable to following Quectel modules:

EC2x (including EC25, EC21, EC20 R2.0 and EC20 R2.1)

EG9x (including EG91 and EG95)

EM05

1.1. Introduction about SSL Type

There are three kinds of connections between SMTP client and SMTP server:

Without SSL

SSL

STARTTLS

Some SMTP servers do not support connection without SSL, while some can support all of them.

Customers can choose one kind according to the mail service provider.

These three kinds of connections can be set by <ssltype> parameter in AT+QSMTPCFG="ssltype".

1. If <ssltype> is 0, it means “without SSL”. In this case, SSL function will not be used, and emails are

sent with insecure connection. The port of SMTP server depends on mail service provider, and it is

the port 25 usually.

2. If <ssltype> is 1, it means “SSL”. In this case, emails are sent with SSL/TLS encrypted SMTP. The

port of SMTP server depends on mail service provider, and it is the port 465 or 587 usually.

3. If <ssltype> is 2, it means “STARTTLS”. In this case, the normal insecure connection can be

upgraded to secure connection through STARTTLS function, for sending the mail data. The port of

SMTP server depends on mail service provider, and it is the port 25, 465 or 587 usually.

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 6 / 31

1.2. The Process of Sending Email

As EC2x&EG9x&EM05 modules support SMTP protocol, customers can send emails easily by

EC2x&EG9x&EM05 SMTP AT commands. The general process is as follows:

Step 1: Configure and activate a PDP context.

1) Configure <APN>, <username>, <password> and other parameters of a PDP context by

AT+QICSGP. Please refer to Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_Manual

for details.

If QoS settings need to be updated, configure them by AT+CGQMIN, AT+CGEQMIN,

AT+CGQREQ and AT+CGEQREQ commands. For more details, please refer to

Quectel_EC25&EC21_AT_Commands_Manual, Quectel_EG9x_AT_Commands_Manual and

Quectel_EM05_AT_Commands_Manual.

2) Activate the PDP context by AT+QIACT.

3) Configure the PDP context ID for SMTP by AT+QSMTPCFG="contextid",<contextID>.

Step 2: Configure SMTP server and user account.

1) Configure SSL type by AT+QSMTPCFG="ssltype",<ssltype>. If <ssltype> is SSL or STARTTLS,

customers should choose an SSL context by AT+QSMTPCFG="sslctxid",<sslctxID> and

configure the <sslctxID> by AT+QSSLCFG="ciphersuite",<sslctxID>,<ciphersuites>. For more

details about these commands, please refer to Quectel_EC2x&EG9x&EM05_SSL_AT_

Commands_Manual.

2) Configure SMTP server by AT+QSMTPCFG="smtpserver",<srvaddr>,<srvport>. <srvaddr> and

<srvport> parameters depend on the mail service provider.

3) Configure account information by AT+QSMTPCFG="account",<username>,<password>.

4) Configure sender information by AT+QSMTPCFG="sender",<sender_name>,<sender_email>.

Step 3: Edit the email content.

1) Configure the recipient email address by AT+QSMTPDST.

2) Configure the subject of email by AT+QSMTPSUB.

3) Configure the body of email by AT+QSMTPBODY.

4) Add attachments for the email by AT+QSMTPATT. The attachments can be RAM, UFS or SD

files. And the files can be uploaded to RAM, UFS or SD card by AT+QFUPL. After sending email

successfully, the file should be deleted by AT+QFDEL. For more details of these commands,

please refer to Quectel_EC2x&EG9x&EM05_FILE_AT_Commands_Manual

Step 4: Send email.

Send the email byAT+QSMTPPUT. It will take some time to send the email depending on the total

size of attachments and network status. When the sending action ends, “+QSMTPPUT:

<err>,<protocol_error>” will be returned.

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 7 / 31

Step 5: Clear the email content.

AT+QSMTPCLR will clear the email content configured in Step 3. The attached files should be

deleted by AT+QFDEL. For more details of these commands, please refer to

Quectel_EC2x&EG9x&EM05_FILE_AT_Commands_Manual. Then repeat Step 3 and 4. If the

SMTP server information and user information need to be changed, then Step 2 to Step 4 should

be repeated.

If emails have not been sent for a long time, such as 30 minutes or even longer, then the PDP

context should be deactivated by AT+QIDEACT=<contextID>. For more details, please refer to

Quectel_EC2x&EG9x&EM05_TCP(IP)_AT_Commands_Manual.

1.3. Description of Data Mode

The COM port of EC2x&EG9x&EM05 modules has two working modes: AT command mode and data

mode. InAT command mode, the inputted data via COM port will be treated asAT command, while in data

mode, it will be treated as data.

Inputting “+++” or pulling up DTR (AT&D1 should be set first) can make the module exit from data mode.

To prevent the “+++” from being misinterpreted as data, the following sequence should be followed:

1) Do not input any character within 1s or longer before inputting “+++”.

2) Input “+++” within 1s, and no other characters can be inputted during the time.

3) Do not input any character within 1s after “+++” has been inputted.

When AT+QSMTPBODY is executed, the COM port will enter into data mode. All inputted data will be the

body of email. If the inputted data reaches the <body_length> or the time reaches <input_time>, the port

will exit from data mode automatically. If the inputted data is less than the <body_length>, customers can

finish editing body by inputting “+++” or changing DTR level from low to high before <input_time> reaches.

In such case, the COM port cannot reenter data mode by executingATO command.

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 8 / 31

2Description of SMTP AT Commands

2.1. AT+QSMTPCFG Configure Parameters for SMTP Server

The command is used to configure SMTP server, user account and SSL settings. If the Write Command

only executes one parameter, it will query the current settings.

AT+QSMTPCFG Configure Parameters for SMTP Server

Test Command

AT+QSMTPCFG=?

Response

+QSMTPCFG: "account",<username>,<password>

+QSMTPCFG: "sender",<sender_name>,<sender_email>

+QSMTPCFG: "smtpserver",<srvaddr>,<srvport>

+QSMTPCFG: "contextid",(1-16)

+QSMTPCFG: "sslctxid",(0-5)

+QSMTPCFG: "ssltype",(0-2)

Write Command

AT+QSMTPCFG="account"[,<userna

me>,<password>]

Response

If <username> and <password> are not omitted:

+CME ERROR: <err>

If <username> and <password> are both omitted, query the

current settings:

+QSMTPCFG: "account",<username>,<password>

Write Command

AT+QSMTPCFG="sender"[,<sender_

name>,<sender_email>]

Response

If <sender_name> and <sender_email> are not omitted:

+CME ERROR: <err>

If <sender_name> and <sender_email> are both omitted,

query the current settings:

LTE Module Series

EC2x&EG9x&EM05 SMTP AT Commands Manual

EC2x&EG9x&EM05_SMTP_AT_Commands_Manual 9 / 31

+QSMTPCFG: "sender",<sender_name>,<sender_email>

Write Command

AT+QSMTPCFG="smtpserver"[,<srva

ddr>,<srvport>]

Response

If <srvaddr> and <srvport> are not omitted:

+CME ERROR: <err>

If <srvaddr> and <srvport> are both omitted, query the current

settings:

+QSMTPCFG: "smtpserver",<srvaddr>,<srvport>

Write Command

AT+QSMTPCFG="contextid"[,<conte

xtID>]

Response

If <contextID> is not omitted:

+CME ERROR: <err>

If <contextID> is omitted, query the current settings:

+QSMTPCFG: "contextid",<contextID>

Write Command

AT+QSMTPCFG="sslctxid"[,<sslctxID

Response

If <sslctxID> is not omitted:

+CME ERROR: <err>

If <sslctxID> is omitted, query the current settings:

+QSMTPCFG: "sslctxid",<sslctxID>

Write Command

AT+QSMTPCFG="ssltype"[,<ssltype>

]

Response

If <ssltype> is not omitted:

+CME ERROR: <err>

If <ssltype> is omitted, query the current settings:

+QSMTPCFG: "ssltype",<ssltype>

Autres manuels pour EC2 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Quectel Unité de contrôle

Quectel

Quectel NB-IoT Module Series Manuel utilisateur

Quectel

Quectel EM12-G Supplément

Quectel

Quectel UG89 Supplément

Quectel

Quectel BC950N-N1 Supplément

Quectel

Quectel SC206E Series Supplément

Quectel

Quectel EP06 Manuel utilisateur

Quectel

Quectel Smart LTE Module Series Supplément

Quectel

Quectel SA800U-WF Manuel utilisateur

Quectel

Quectel M66 Supplément

Quectel

Quectel BG96 Supplément

Quectel

Quectel BC95 Manuel utilisateur

Quectel

Quectel BG95 Series Instructions d'installation et d'utilisation

Quectel

Quectel EG915U Series Supplément

Quectel

Quectel EC200U Series Instructions d'installation et d'utilisation

Quectel

Quectel SC200R Series Supplément

Quectel

Quectel LG77L EVB Manuel utilisateur

Quectel

Quectel RM510Q-GL Supplément

Quectel

Quectel M35 Instructions d'installation

Quectel

Quectel EP06 Manuel utilisateur

Quectel

Quectel UG95 Supplément

Quectel

Quectel GNSS Module Series Manuel utilisateur

Quectel

Quectel GNSS Module Series Manuel utilisateur

Quectel

Quectel LTE Module Series Instructions d'installation

Quectel

Quectel Smart Module Series Supplément

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
