Quectel BG96 Manuel d'installation

BG96 NIDD

AT Commands Manual

LTE Module Series

Rev. BG96_NIDD_AT_Commands_Manual_V1.0

Date: 2018-05-25

Status: Released

www.quectel.com

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 1 / 13

Our aim is to provide customers with timely and comprehensive service. For any

assistance, please contact our company headquarters:

Quectel Wireless Solutions Co., Ltd.

7th Floor, Hongye Building, No.1801 Hongmei Road, Xuhui District, Shanghai 200233, China

Tel: +86 21 5108 6236

Email: [email protected]om

Or our local office. For more information, please visit:

http://quectel.com/support/sales.htm

For technical support, or to report documentation errors, please visit:

http://quectel.com/support/technical.htm

Or email to: support@quectel.com

GENERAL NOTES

QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION

PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT

TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT

MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT

ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR

RELIANCE UPON THE INFORMATION. ALL INFORMATION SUPPLIED HEREIN IS SUBJECT TO

CHANGE WITHOUT PRIOR NOTICE.

THE INFORMATION CONTAINED HERE IS PROPRIETARY TECHNICAL INFORMATION OF

QUECTEL WIRELESS SOLUTIONS CO., LTD. TRANSMITTING, REPRODUCTION, DISSEMINATION

AND EDITING OF THIS DOCUMENT AS WELL AS UTILIZATION OF THE CONTENT ARE

FORBIDDEN WITHOUT PERMISSION. OFFENDERS WILL BE HELD LIABLE FOR PAYMENT OF

DAMAGES. ALL RIGHTS ARE RESERVED IN THE EVENT OF A PATENT GRANT OR

REGISTRATION OF A UTILITY MODEL OR DESIGN.

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 2 / 13

About the Document

History

Revision

Date

Author

Description

1.0

2018-05-25

Lane HAO

Initial

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 3 / 13

Contents

About the Document.................................................................................................................................. 2

Contents...................................................................................................................................................... 3

Table Index.................................................................................................................................................. 4

1Introduction......................................................................................................................................... 5

2Description of AT Commands........................................................................................................... 6

2.1. Description of NIDD Related AT Commands............................................................................. 6

2.1.1. AT+QCFGEXT="pdp_type" Modify the Parameters of Specified PDP Context........... 6

2.1.2. AT+QCFGEXT="nipdcfg" Configure Parameters for NIDD Connection...................... 7

2.1.3. AT+QCFGEXT="nipd" Open or Close the NIDD Connection...................................... 7

2.1.4. AT+QCFGEXT="nipds" Send MO Non-IP Data........................................................... 8

2.1.5. AT+QCFGEXT="nipdr" Retrieve MT Non-IP Data....................................................... 9

2.2. Description of NIDD Related URCs......................................................................................... 10

2.2.1. URC of Incoming Data.................................................................................................. 10

2.2.2. URC of Connection Closed........................................................................................... 10

2.3. Example of NIDD Related Configurations............................................................................... 10

3Summary of <err> Codes................................................................................................................. 12

4Appendix A References.................................................................................................................... 13

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 4 / 13

Table Index

TABLE 1: SUMMARY OF <ERR> CODE.......................................................................................................... 12

TABLE 2: RELATED DOCUMENTS.................................................................................................................. 13

TABLE 3: TERMS AND ABBREVIATIONS........................................................................................................ 13

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 5 / 13

1Introduction

The support for NIDD (Non-IP Data Delivery) is introduced from 3GPP Rel. 13 and later releases.

Functions for NIDD may be used to handle MO and MT communication with UE, where the data used for

the communication is considered unstructured from the EPS standpoint (which we refer to also as

Non-IP). NIDD is only applicable for LTE Cat NB1 RAT. Non-IP data calls are supported for both tethered

and embedded use cases.

This document mainly introduces how to use the NIDD function of Quectel BG96 module through AT

commands.

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 6 / 13

2Description of AT Commands

2.1. Description of NIDD Related AT Commands

2.1.1. AT+QCFGEXT="pdp_type" Modify the Parameters of Specified PDP Context

Parameter

AT+QCFGEXT="pdp_type" Modify the Parameters of Specified PDP Context

Write Command

Query the current configuration:

AT+QCFGEXT="pdp_type"

Response

+QCFGEXT: "pdp_type",<cid>,<type>,<apn>

Write Command

Configure the parameters of a specified

PDP context:

AT+QCFGEXT="pdp_type",<cid>,<typ

e>[,<apn>[,<username>,<password>]

]

Response

<cid> Integer type. PDP context identifier. A numeric parameter which specifies a particular

PDP context definition (see AT+CGDCONT command in Quectel_BG96_AT_

Commands_Manual for more details). It is currently only valid for <cid> is 1.

<type> String type. Packet data protocol type.

“IP”

“PPP”

“IPV6”

“IPV4V6”

“Non-IP”

<apn> String type.Access point name.

<username> String type. User name of the selectedAPN.

<password> String type. Password of the selectedAPN.

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 7 / 13

The command will take effect after reboot, or by executing AT+CFUN=0 and AT+CFUN=1 consecutively.

2.1.2. AT+QCFGEXT="nipdcfg" Configure Parameters for NIDD Connection

Parameter

2.1.3. AT+QCFGEXT="nipd" Open or Close the NIDD Connection

AT+QCFGEXT="nipdcfg" Configure Parameters for NIDD Connection

Write Command

Query the current configuration for NIDD

connection:

AT+QCFGEXT="nipdcfg"

Response

+QCFGEXT: "nipdcfg",<type>,<apn>

Write Command

Configure the parameters for NIDD

connection:

AT+QCFGEXT="nipdcfg",<type>[,<ap

n>[,<username>,<password>]]

Response

<type> Non-IP outgoing data type.

0 MO Non-IP data type

1 MO Exception Non-IP data type

<apn> String type. Access point name.

<username> String type. User name of the selected APN.

<password> String type. Password of the selectedAPN.

AT+QCFGEXT="nipd" Open or Close the NIDD Connection

Write Command

Configure to open or close the NIDD

connection:

AT+QCFGEXT="nipd",<mode>[,<time

out>]

Response

If <mode> is 1, the following URC is reported after the OK

response:

+QIND: "nipd","open",<err>

If there is an error related to ME functionality, response:

+CME ERROR: <err>

NOTE

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 8 / 13

Parameter

1. NV 73916 should be set as 277 to enable NIDD function.

2. Non-IP data calls are supported forAP embedded and tethered RmNet calls only.

3. Non-IP data calls are not supported for modem embedded calls.

2.1.4. AT+QCFGEXT="nipds" Send MO Non-IP Data

Parameter

If there is any other error, response:

ERROR

<mode> Integer type.

0 Close the NIDD connection.

1 Open the NIDD connection.

<timeout> Integer type. The range is 30-90 and the default value is 30. Unit: second.

<err> Integer type. The error code of the operation. Please refer to Chapter 3 for details.

AT+QCFGEXT="nipds" Send MO Non-IP Data

Write Command

Configure the MO Non-IP data to be

sent:

AT+QCFGEXT="nipds",<mode>,<data

>[,<data_length>]

Response

If there is an error related to ME functionality, response:

+CME ERROR: <err>

If there is any other error, response:

ERROR

<mode> Integer type. Data format.

0 ASCII format string.

1 HEX format string.

<data> String type. The data to be sent.

<data_length> Integer type. The data length to be sent. The range is 1-100. Unit: byte.

<err> Integer type. The error code of the operation. Please refer to Chapter 3 for details.

NOTES

LTE Module Series

BG96 NIDD Commands Manual

BG96_NIDD_AT_Commands_Manual 9 / 13

2.1.5. AT+QCFGEXT="nipdr" Retrieve MT Non-IP Data

Parameter

AT+QCFGEXT="nipdr" Retrieve MT Non-IP Data

Write Command

AT+QCFGEXT="nipdr"[,<read_length

Response

If the connection has received data, response:

+QCFGEXT: "nipdr",<read_actual_length>,<data>

If there is no data that can be retrieved, response:

+QCFGEXT: "nipdr",0

If there is an error related to ME functionality, response:

+CME ERROR: <err>

If there is any other error, response:

ERROR

Write Command

When <read_length> is 0, query the

retrieved data:

AT+QCFGEXT="nipdr",0

Response

If the connection has existed, response:

+QCFGEXT:

"nipdr",<total_receive_length>,<have_read_length>,<unr

ead_length>

If there is an error related to ME functionality, response:

+CME ERROR: <err>

If there is any other error, response:

ERROR

<read_length> Integer type. The data length to be retrieved. Unit: byte.

<read_actual_length> The actual length of retrieved data. Unit: byte.

<data> String type. Retrieved data.

<total_receive_length> The total length of received data. Unit: byte.

<have_read_length> The length of read data. Unit: byte.

<unread_length> The length of unread data. Unit: byte.

<err> Integer type. The error code of the operation. Please refer to Chapter 3 for
