Quantum SuperLoader 3:

Rackmount Replacement

Follow the steps in the document to replace a rackmount for your

SuperLoader 3:

To replace the rackmount, refer to the following sections:

•Preparing to Replace the SuperLoader 3 Rackmount on page 1

•Removing the SuperLoader 3 from the Rackmount on page 4

•Replacing the SuperLoader 3 In a New Rackmount on page 10

•Completing the Installation on page 12

Preparing to Replace the SuperLoader 3 Rackmount

Note: Read this entire document before beginning any of the procedures.

Safety Precautions Before beginning a rack mount installation, complete the following safety

precautions:

1Lower the cabinet feet.

2Extend the cabinet anti-tip device, if available.

3Ensure that the cabinet and all rack mounted equipment have a reliable

ground connection.

4If you have made any changes to the location of your SuperLoader 3, verify

that the total current of all rack mounted components (including the

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

2 Preparing to Replace the SuperLoader 3 Rackmount

SuperLoader 3) will not exceed the current rating of the power distribution

unit or outlet receptacles.

5Secure the help of at least one other person. At least two people are

required to safely reinstall the SuperLoader 3 into a rack cabinet.

WARNING: Failure to take these safety steps may result in personal injury

or equipment damage.

Caution: Never remove the top cover of the SuperLoader 3. Removing

the top cover could result in damage to the SuperLoader 3.

Required Tools and Kits Make sure you have the following tools.

• (1) #2 Phillips screwdriver

• (1) Level (required when placing SuperLoader 3 into the rack cabinet)

Make sure you have the following kits:

• Replacement Rack Rail Kit

SuperLoader 3

Replacement Rack Rail

Kit Contents

Verify the contents of the SuperLoader 3 Replacement Rack Rail Kit you received

from Quantum.

Table 1 SuperLoader 3 Rack

Rail Kit Contents

Component Description Quantity

10-32 x 1/4 inch button head screws 8

(4 per support

bracket)

Support brackets 2

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

Preparing to Replace the SuperLoader 3 Rackmount 3

Note: Commonly, the short SuperLoader 3 brackets are used. However, if the

distance from the front mounting rail to the rear mounting rail is

longer than 30.25 in. (76.84 cm), you must use the long brackets to be

sure the SuperLoader 3 can reach and be securely attached to the rear

mounting rail.

Preparing the

SuperLoader 3 for

Removal From the Rack

These instructions explain how to prepare your SuperLoader 3 so you can safely

remove it from the rack.

1Release the magazines from the SuperLoader 3; complete the following

steps for each magazine or magazine blank:

aFrom the main menu, select Commands and press Enter.

bSelect Eject and press Enter.

cSelect the appropriate magazine (Right Magazine or Left Magazine)

and press Enter.

You will hear a distinctive popping sound as the appropriate magazine

is ejected from the SuperLoader 3. The LCD indicates which magazine

has been ejected.

Note: To prevent damage to the SuperLoader 3 or the magazine, use

both hands when removing it from the SuperLoader 3 and

support the entire length of the magazine.

dGrasp the magazine by the handle and slide it out while supporting it

from underneath with the other hand.

Note: To remove the magazine blank, pull it straight out.

2Safely power down the SuperLoader 3; press and hold the power button on

the front panel until the System Shutdown wait 60 sec message is

SuperLoader 3 Long brackets 2

SuperLoader 3 Short brackets 2

Component Description Quantity

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

4 Removing the SuperLoader 3 from the Rackmount

displayed on the LCD, Power Off is displayed, and then the SuperLoader 3

shuts off.

3Disconnect the cables and power cords.

Note: Label the cables so that you can reconnect them to the correct

ports.

Removing the SuperLoader 3 from the Rackmount

Caution: Retain all the parts removed in this procedure. Depending on what

parts of the rackmount are replaced, you may need to reuse some

parts.

WARNING: At least two people are required to safely remove the

SuperLoader 3 from the rack cabinet. Failure to take this safety

step may result in personal injury or equipment damage.

When the SuperLoader 3 is rack mounted directly to the stationary cabinet rails,

complete the following steps to remove it.

Removing the

SuperLoader 3 From a

Rackmount

These instructions explain how to remove the SuperLoader 3 from a rackmount.

Required Tools:

• #2 Phillips screwdriver.

While the other installer holds the front end of the SuperLoader 3, remove it

from the rack by completing the following steps:

Note: Before removing the SuperLoader 3 from the rack, you will need to

loosen the screws just enough to hold the support brackets firmly

against the rail while still allowing the support bracket to be slightly

shifted by hand. This shifting will help facilitate the removal of the

SuperLoader 3 brackets as the SuperLoader 3 is uninstalled from the

rack.

1Loosen the four (4) screws that connect the two (2) support brackets to the

two (2) SuperLoader 3 brackets. Do not remove the screws completely at

this time (see Figure 1).

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

Removing the SuperLoader 3 from the Rackmount 5

Figure 1 Support Brackets and

SuperLoader 3 Brackets

Screws

SuperLoader 3

bracket

Support bracket

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

6 Removing the SuperLoader 3 from the Rackmount

2Loosen the four (4) screws on the front of the SuperLoader 3 that attach the

two (2) front tabs (support brackets) to the front rails. Do not remove the

screws completely at this time (see Figure 2).

Figure 2 Front Tabs and Rails

Front rail

Rack

screws

Tab (one

per side)

SuperLoader 3

(front)

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

Removing the SuperLoader 3 from the Rackmount 7

3Remove the four (4) screws at the back of the SuperLoader 3 that connect

the support brackets (two screws per bracket) to the SuperLoader 3 brackets

(see Figure 3).

Figure 3 Support Brackets and

SuperLoader 3 Brackets

Outer cover of rack

Clip nuts

Support bracket

Rear rail in rack

Rack screws

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

8 Removing the SuperLoader 3 from the Rackmount

WARNING: Injury may occur if the unit is not supported when you remove

the front screws. The screws are holding up the front of the unit.

4While supporting the front of the SuperLoader 3, remove the four (4) front

screws (see Figure 4).

Figure 4 SuperLoader 3 Front

Screws and Support Brackets

SuperLoader 3

bracket

Support bracket

Front screws

5Using two people, or an appropriately rated mechanical lift, remove the

SuperLoader 3 from the rack; complete the following steps:

aHave one person slide the SuperLoader 3 out of the rack while

supporting it from the bottom.

bThe other person should handle the back of the unit and depress the

locking tab on the support bracket while sliding the unit forward.

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

Removing the SuperLoader 3 from the Rackmount 9

6Remove the four (4) screws and the brackets from the back of the

SuperLoader 3 (see Figure 5).

Figure 5 SuperLoader 3

Brackets

7When the SuperLoader 3 has been completely removed from the rack, set it

down gently on a stable surface.

8Compare the SuperLoader 3 brackets you received in the SuperLoader 3

Rack Rail Kit (see SuperLoader 3 Replacement Rack Rail Kit Contents on

page 2) with the brackets that were removed from in Step 6. If you are

replacing the brackets, you will need to use the same size bracket from the

kit to reinstall the SuperLoader 3 into the rack.

Note: Save any screws and clip nuts you remove in a safe place in case you

need them when you replace the SuperLoader 3 in the new rackmount.

SuperLoader 3

Screws (10-32 x 1/4 only)

SuperLoader 3

bracket

Quantum SuperLoader 3: Rackmount Replacement

6-68061-01 Rev A

December 2013

10 Replacing the SuperLoader 3 In a New Rackmount

Replacing the SuperLoader 3 In a New Rackmount

Be sure you have the correct tools and parts before proceeding with these

instructions (see Required Tools and Kits on page 2).

These instructions explain how to attach the SuperLoader 3 directly to the

stationary rails of a rack.

1Secure the help of at least one other person. At least two people are

required to safely reinstall the SuperLoader into a rack cabinet.

WARNING: Failure to take these safety steps may result in personal injury

or equipment damage.

Caution: Never remove the top cover of the SuperLoader 3. Removing

the top cover could result in damage to the SuperLoader 3.

2If present, install two (2) clip nuts, 1.75 in. (44.45 mm) apart, onto each of

the four (4) rails of the rack, making sure that you install each pair of clip

nuts at exactly the same height (see Figure 6).

Figure 6 Installing Clip Nuts

3Attach the appropriate SuperLoader 3 brackets (long or short depending on

the depth of the rack and as determined in Step 8 on page 9) to the rear of

Rail

Outer covers

of the rack

Rail

Clip nut

1.75 in

(44.45mm)
