Quantum StorNext QD7000 Manuel utilisateur
Upgrading Host Interface Cards
StorNext QD7000
Firmware 8.30.xx.xx
6-68564-01 Rev A
ii Upgrading Host Interface Cards
Upgrading Host Interface Cards, 6-68564-01 Rev A, April 2017 Product of USA.
Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not
limited to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this
publication from time to time without notice.
COPYRIGHT STATEMENT
© 2017 Quantum Corporation. All rights reserved.
Your right to copy this manual is limited by copyright law. Making copies or adaptations without prior written authorization of
Quantum Corporation is prohibited by law and constitutes a punishable violation of the law.
TRADEMARK STATEMENT
Artico, Be Certain (and the Q brackets design), DLT, DXi, DXi Accent, DXi V1000, DXi V2000, DXi V4000, DXiV-Series, FlexTier,
Lattus, the Q logo, the Q Quantum logo, Q-Cloud, Quantum (and the Q brackets design), the Quantum logo, Quantum Be Certain
(and the Q brackets design), Quantum Vision, Scalar, StorageCare, StorNext, SuperLoader, Symform, the Symform logo (and
design), vmPRO, and Xcellis are either registered trademarks or trademarks of Quantum Corporation and its affiliates in the United
States and/or other countries. All other trademarks are the property of their respective owners. Products mentioned herein are for
identification purposes only and may be registered trademarks or trademarks of their respective companies. All other brand names
or trademarks are the property of their respective owners. Quantum specifications are subject to change.
Upgrading Host Interface Cards iii
Preface
Note: The 8.30.xx.xx firmware (Lehigh) is used in the QD7000 (E5600,
Titan RAID controller, only). Refer to the NetApp to Quantum
Naming Decoder section for additional information.
This section provides the following information:
•Audience
•Prerequisites
•NetApp to Quantum Naming Decoder
•Product Safety Statements
•Contacts
•Comments
•Quantum Global Services
Audience This manual is intended for storage customers and technicians.
Preface
iv Upgrading Host Interface Cards
Prerequisites Prerequisites for installing and using this product include knowledge of:
• Servers and computer networks
• Network administration
• Storage system installation and configuration
• Storage area network (SAN) management and direct attach storage
(DAS)
• Fibre Channel (FC) and Ethernet protocols
NetApp to Quantum
Naming Decoder
Use Table 1 to correlate the NetApp product nomenclature to the
equivalent Quantum-storage naming conventions.
Table 1 Product Nomenclature
E-Series NetApp
Product Quantum-Storage Description
Controller-Drive Tray Base System Quantum uses Base System when referring to a drive
tray with the RAID controllers.
Drive Tray Expansion Unit Quantum uses Expansion Unit when referring to a
drive tray with the environmental services modules
(ESMs).
E5600 (Code Name:
Titan)
RAID Controller Four 16Gb/s FC SFP+ host ports
E5500 (Code Name:
Soyuz)
RAID Controller Four 16Gb/s FC SFP+ host ports
E5400 (Code Name:
Pikes Peak)
RAID Controller Four 8Gb/s FC SFP+ host ports
DE6600 (Code Name:
Wembley)
4U 60-drive
enclosure
Sixty 3.5 inch disk drives
Preface
Upgrading Host Interface Cards v
E5560 or E5660
(DE6600 4U drive
enclosure with
E5500 or E5600 RAID
controllers)
Quantum StorNext
QD7000
E5460
(DE6600 4U drive
enclosure with
E5400 RAID
controllers)
Quantum StorNext
QD6000
E5424
(DE5600 24-drive 2U
drive enclosure
(Code Name:
Camden with E5400
RAID controllers)
Quantum StorNext
QS2400
E5412
(DE1600 12-drive 2U
drive enclosure
(Code Name: Ebbets
with E5400 RAID
controllers)
Quantum StorNext
QS1200
E-Series NetApp
Product Quantum-Storage Description
Preface
vi Upgrading Host Interface Cards
Product Safety
Statements
Quantum will not be held liable for damage arising from unauthorized
use of the product. The user assumes all risk in this aspect.
This unit is engineered and manufactured to meet all safety and
regulatory requirements. Be aware that improper use may result in
bodily injury, damage to the equipment, or interference with other
equipment.
WARNING: Before operating this product, read all instructions and
warnings in this document and in the system, safety, and
regulatory guide.
Preface
Upgrading Host Interface Cards vii
Contacts For information about contacting Quantum, including Quantum office
locations, go to:
http://www.quantum.com/aboutus/contactus/index.aspx
Comments To provide comments or feedback about this document, or about other
Quantum technical publications, send e-mail to:
Preface
viii Upgrading Host Interface Cards
Quantum Global
Services
Accelerate service issue resolution with these exclusive Quantum
StorageCare services:
•Service and Support Website - Register products, license software,
browse Quantum Learning courses, check backup software and
operating system support, and locate manuals, FAQs, firmware
downloads, product updates and more in one convenient location.
Benefit today at:
http://www.quantum.com/serviceandsupport/get-help/
index.aspx#contact-support
•eSupport - Submit online service requests, update contact
information, add attachments, and receive status updates via email.
Online Service accounts are free from Quantum. That account can
also be used to access Quantum’s Knowledge Base, a
comprehensive repository of product support information. Get
started at:
http://www.quantum.com/customercenter/
For further assistance, or if training is desired, contact the Quantum
Customer Support Center:
North America 1-800-284-5101 (toll free)
+1-720-249-5700
EMEA +800-7826-8888 (toll free)
+49-6131-324-185
APAC +800-7826-8887 (toll free)
+603-7953-3010
For worldwide support:
http://www.quantum.com/serviceandsupport/get-help/
index.aspx#contact-support
Copyright 2014 NetApp Inc. All rights reserved.
Replacing Controller Canisters in the E5660 Controller-Drive
Tray to Upgrade Host Interface Cards
To access this product, go to the NetApp® support site at mysupport.netapp.com.
Planning the Host Interface Card Upgrade
Use these procedures to upgrade the host interface in a controller-drive tray by replacing all of the controllers. For
duplex controller-drive trays, you replace both controllers. For simplex controller-drive trays, you replace the one
controller. In both cases, you must power off the controller-drive tray. As a result, you cannot access data on the
storage array until you successfully complete the replacement.
If your storage array participates in remote volume mirroring, only iSCSI or Fibre Channel connections are
supported between the primary site and the remote site. If your new HIC configuration does not include iSCSI or
Fibre Channel connections, remote volume mirroring will not be supported.
If you upgrade to 56 Gb/s InfiniBand, you must perform the steps from the InfiniBand Configuration and Provisioning
for Linux® Express Guide to configure your storage array to use the iSCSI Extensions for RDMA (iSER) protocol.
Make sure that you have access to that document before you start these procedures.
To complete this procedure, you will need antistatic protection and one or two new controller canisters. Depending
on your new host interface, you might need new host bus adapters (HBAs), host channel adapters (HCAs),
switches, cables, Small Form-factor Pluggable (SFP) transceivers, or quad SFP (QSFP) transceivers to re-cable
your host connections. Table 1 summarizes requirements for cabling and SFP transceivers.
Your new controller canisters are shipped without a battery installed. You will remove the battery from each of your
old controllers and then install those batteries in the new controllers.
ATTENTION Possible loss of data access – If any controller that you are replacing manages any secure volumes,
the new controller needs the correct security key to manage those volumes. After you replace the controller and
restore power to the controller-drive tray, you can use SANtricity Storage Manager to load the key from the file in
which it was saved. Be sure that such a file exists and that you know the pass phrase required to install the security
key before you replace the controller.
Cabling Considerations for the E5600 Controller-Drive Trays
Compare your current host cabling to the supported cabling for your new controllers to determine whether you can
reuse SFPs, QSFPs or cables from your old cabling configuration. The HBAs, HCAs, or Ethernet adapters, as well
as switches in the network fabric used to connect your hosts to your storage array must match the HICs in your
controller canisters.
2 - Replacing Controller Canisters in the E5660 Controller-Drive Tray to Update HICs
Table 1. Host Cabling Configurations
HIC Cable
Data Rate and
Protocol
Number of
Connectors
Connector Type Length
MiniSAS-HD passive copper 1-5m
MiniSAS-HD active copper 8-15m
MiniSAS-HD optical 5-100m
Fan-out cable type #2 passive copper 2m
12 Gb/s SAS 4
Fan-out cable type #3 passive copper 2m
QSFP+ passive copper 1-3m56 Gb/s InfiniBand 2
QSFP+ optical 5-100m
SFP+ OM2 SW optical 2,3,5,10,25m
SFP+ OM3 SW optical 50-150m
16 Gb/s Fibre Channel 4
SFP+ OS2 LW optical 50-300m
SFP+ OM2 optical 2,3,5,10,25m
SFP+ OM3 optical 50-150m
10 Gb/s iSCSI 4
Twin-Ax passive copper 2-7m
1 Gb/s iSCSI 4 RJ-45 passive copper 2-70m
Preparing to Replace the Controllers
1. Make sure that the existing storage array is updated to the latest released controller firmware.
2. If an FDE security key exists on the storage array, save the FDE security key to a location not on the storage
array.
3. Perform the following steps to record the serial number for your storage array:
a. In the EMW tree view, double-click your storage array.
The AMW opens
b. In the Summary tab of the AMW, click the View Storage Array Profile link.
c. Make a record of the value for Chassis Serial Number.
You need this serial number to perform the steps in Powering On the E5600 Storage Array.
4. Gather support data about your storage array by using one of these methods:
Use the storage management software to collect and save a support bundle of your storage array. From the
Array Management Window toolbar, select Monitor > Health > Collect Support Data Manually. Then
name and specify a location on your system where you want to store the support bundle.
Use the command line interface (CLI) to run the save storageArray supportData command to gather
comprehensive support data about the storage array. For more information about this command, refer to the
current version of the Command Line Interface and Script Commands Programming Guide.
NOTE Gathering support data can temporarily impact performance on your storage array.
5. Stop all I/O operations between the storage array and all connected hosts.
