Pyle PSBV28HB Manuel utilisateur

35''2.1ChannelConvertibleSoundbar

Wireless BT Soundbar Speaker with Remote Control

PSBV28HB

www.PyleUSA.com2

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS

IMPORTANT

DESCRIPTION OF THE APPLIANCE

Remote Control Function Keys

Wireless BT Streaming Connectivity

AUX CONNECTION (3. 5 mm JACK)

SPECIFICATIONS

Important Safety Instructions

IMPORTANT

Please read these instructions carefully and retain for future reference.

• To prevent the risk of re or electric shock, keep this sound bar away from

water, rain and moisture.

• To prevent any risk of electric shock, never remove the cover or the rear panel

of the device.

• If the appliance breaks down, have it repaired by a professional.

No part of this device can be repaired by the user.

WARNING!

Danger! Device powered on. Do not open. Risk of electric shock! No part of

this device can be repaired by the user. Maintenance and repair of this

device should be entrusted to a professional.

As a safety measure, ask the manufacturer or the after-sales service to replace the

appliance's electric cable if it is damaged.

The device must be installed in accordance with current regulations.

This sound bar has been specially developed for LED/LCD/Plasma TVs. It should not

be installed on CRT (Cathode Ray Tube) televisions to avoid picture interference.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

www.PyleUSA.com 3

Installation

• Install the device on a at, rigid and stable surface. The speaker may fall and

cause serious injury to a child or adult. A fall can seriously damage the device.

• The sound bar and subwoofer should be kept away from heat sources such as

radiators, stoves or other devices that produce heat.

• To prevent the risk of overheating, do not install the sound bar on another device.

• Do not place any object under the device (eg. CDs or magazine).

Ventilation Instructions

• To prevent any risk of overheating, install the appliance in a suciently ventilated

space.

• Make sure that the ventilation grids are not blocked.

• Do not expose the soundbar to high temperatures, and protect in from water,

humidity and dust.

• Protect the device from leaks or splashes.

Do not place objects containing liquids (eg. vase) on top of the device.

• Do not place objects liable to damage it (eg. objects containing liquids or lighted

candles) near the device.

• Do not pIace open ames (eg lighted candles) on top of the appliance.

Power Supply

• Unplug the sound bar when you are not using it for long periods of time.

• For safety reasons, ask the manufacturer or the after-sales service to replace the

appliance's electric cable if it is damaged.

• This appliance must be connected to an electrical network of 110~240V TO Hz.

• The electric cable must remain accessible because you will need to unplug it to

switch o the appliance.

• To connect the device to the mains, use only the supplied electric cable.

• Do not operate the device with a battery other than the one already installed.

This sound bar must be connected to a power outlet of the same voltage as

that specied on the device.

CAUTION: There is a risk of explosion if the battery is incorrectly installed.

Do not attempt to replace the battery with another model.

www.PyleUSA.com4

• The batteries (whether the supplied batteries or the battery already installed)

should not be exposed to excessive heat (eg sunlight, ames or other heat

source).

• If you notice that after fully recharging the battery, its life is reduced by half,

carry out the next recharge under supervision.

Warning: A damaged battery presents a danger of overheating.

When performing any maintenance or repair, ask the service center/workshop to

use the factory authorized spare parts. Replacement with unauthorized parts may

result in re, shock, or other hazards.

Out of respect for the environment, comply with local regulations on battery

collection (check with the store where you purchased the device).

Clean only with a soft, damp cloth. Unplug this product from the wall outlet

before cleaning.

What's in the Box:

• Main Speakers

• AC/DC Power Cord

• Remote Control

DESCRIPTION OF THE APPLIANCE

www.PyleUSA.com 5

Remote Control Function Keys

1. LED Indicator

2. HDMI/ARC

3. OPTICAL

4. USB IN

5. AUX IN

6. DC IN

7. PLAY

8. NEXT/V+

9. ON/OFF

10. SOURCE

11. PRV/V-

12. Subwoofer

13. LED pairing indicator

14. AC Power input: 110-240V -50/60Hz

AC110-240V~

50/60Hz

1. POWER

2. MODE

3. VOLUME +

4. PREVIOUS

5. PLAY/PAUSE

6. VOLUME -

7. MUSIC

8. FILM

9. PAIRING

10. RESET

11. MUTE

12. NEXT

13. NEWS

14. MENU

www.PyleUSA.com6

CONNECTION TO THE TV

Optical source (TOSLINK)

Make sure the soundbar is connected to the TV or other device via Toslink optical

cable. Press the Power/Standby button on the side of the soundbar to switch to

optical mode (or via remote control).

HDMI source

Make sure the soundbar is connected to the TV or other device via an HDMI cable.

Press the Power/Standby button on the side of the soundbar to switch to HDMI

mode (or Via the remote control).

PAIRING MODE OF SUBWOOFER AND SOUNDBAR

Pairing the subwoofer and sound bar

1. Turn on the subwoofer by connecting it to a power source. The blue LED on the

back of the device will start to ash slowly. Press the WPS Auto Pairing button.

The subwoofer will enter pairing mode and the blue LED will start blinking

rapidly.

2. Turn on the soundbar by connecting it to a power source. Press the on/o

button on the sound bar (1). The sound bar goes into “pairing” mode. It will try

to connect with the wireless subwoofer.

3. Within 30 seconds, the blue LED on the back of the subwoofer will stop ashing

and stay on. This indicates that the subwoofer and the sound bar have been

successfully paired.

4. The subwoofer will automatically remember the pairing for future use.

Warning: If the subwoofer is on, but the standby mode is activated or the

device is disconnected from its power source, after 5 minutes the blue LED

indicator will turn solid red. This indicates that the subwoofer is in standby mode.

To avoid sound quality problems caused by wireless signal interference, please

keep the system at a suitable distance from other 2. 4Ghz wireless devices.

The maximum connection range is 10 meters.

www.PyleUSA.com 7

Wireless BT Streaming Connectivity:

• Built-in BT for Wireless Music Streaming

• Simple and Hassle-Free Pairing

• Works with All of Today's Latest Devices

(Smartphones, Tablets, Laptops, computers, etc.)

• Wireless BT Version: 5.0

• Wireless BT Network Name: "PSBV28HB"

• Wireless Range: 32.8' ft.

1. Turn ON the sound bar by connecting it to a power source.

Press the On/Standby button on the remote control (1). The soundbar's LCD

screen will display“BT” and the letters will ash regularly.

2. Activate the Wireless BT function on your device (Smartphone, Tablet etc.) and

make sure that the Wireless BT mode is activated. Look in the list of Wireless BT

devices: PSBV28HB.

3. Once paired, the letters “BT” on the LCD screen will stop ashing and stay on.

USB CONNECTION

1. Turn on the soundbar by plugging it into a power source and pressing the

Power/Standby button on the soundbar or remote control (mode).

2. Plug in your USB stick. The unit will automatically play les and start playing

music on the sound bar. The LCD screen will display the word USB.

3. You can control playback from the remote control

(Volume, tracks, play/pause, stop).

Note: Support USB driver up to 32GB and Mp3 le format.

The USB port does not support charging.

AUX CONNECTION (2.5 mm JACK)

Use the 3.5mm AUX socket to connect a computer, smartphone, tablet, or any

other external sound source with a 3.5mm jack output.

1. Turn on the sound bar by connecting it to a power source.

Press the Power/Standby button on the side.

Press until the LCD screen displays the letters “AUX”.

2. Use a 3.5mm jack cable to connect the soundbar to an audio source.

Note: You will need to adjust the device volume and volume independently.

www.PyleUSA.com8

Features:

• Built-in Class D Stereo Power Amplier

• (2) 2” Full-range Drivers

• (2) 6.5” Subwoofer Drivers

• Built-in BT Technology

• 3.5mm Auxiliary Input

• Optical Input

• USB Input

• HDMI ARC Input

• Built-in LED lights

Technical Specs:

• MAX Power: 500W

• RMS Power: 120W

• AC Power Adapter: Input: 100-240V, 50/60Hz; Output: DC 24V

• Impedance: 4 Ohm

• Frequency Response: Bass: 20Hz-150Hz, Soundbar: 120Hz-20kHz

• Total Harmonic Distortion: Bass: ≥0.5%@60W, Soundbar: ≥0.5%@60W

• Supported Media Files: MP3 Audio

• AUX (LINE) Input: 2-Channel Analog Audio, 3.5mm

• Remote Control Battery Operated, Requires (2) x 'AAA' Batteries (not Included)

• Product Dimensions (L x W x H):36'' x 2.6'' x 2.6'' -inches

www.PyleUSA.com 9

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: suppor[email protected]
