Pyle PPHP265DJB Manuel utilisateur

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: suppor[email protected]

PPHP265DJB

WirelessBTBoomBoxStereoSpeakerSystem

Built-in Full Panel LED Lights, FM Radio/Aux/MP3/

USB Flash Drive Memory Reader/Micro SD

& 1/4 Input Jack for Microphone/DJ Sound Effects Control Panel

WARNING

Illegal operation may cause personal injury, which could be fatal and may cause

damage to property. For safety, we do not suggest to charge unit and use micro-

phone together.

1. DO NOT place objects on top of the device, as objects may

scratch the device.

2. DO NOT expose the device to dirty or dusty environments.

3. DO NOT insert any foreign objects into the device.

4. DO NOT expose the device to strong magnetic or electrical eld.

5. DO NOT use the device in the rain

6. Please check with your Local Authority or retailer for proper

disposaI of electronic products.

7. DO NOT disassemble the device. Only a certied service

technician should perform repair.

8. The device has apertures to disperse heat. DO NOT block the

device ventilation, the device may become hot and malfunction

as a result.

CONTROL BOARD FUNCTIONS

1. Play/stop music on USB/Micro SD/BT mode, scan FM channel on FM mode

2. USB and micro SD memory card input jack

3. Press and hold to decrease music volume, short press to choose last channel

4. 3.5MM AUX input jack

5. 6.5MM microphone input jack

6. Power switch button

7. Mode button: short press to select USB/Micro SD/AUX/BT/FM mode

8. Menu button: short press to select Bass (b) or Treble (t) or main volume (U),

and then use Prev (-) or Next (+) button to decrease or increase

9. Charge LED indicator: Red light in charge, blue light full charge

10. DC 9V charge input jack

11. Increase bass eect button

12. LED mode and switch button

13. TWS Function button: Two unit both on Wireless BT mode, press this TWS button

to start TWS pairing.

14. 4 kinds of DJ eect selecting button

15. Microphone volume knob

16. Microphone echo knob

17. Press and hold to increase music volume, short press to choose next channel

www.PyleUSA.com

2www.PyleUSA.com 3

MIC VOL.

MIC ECHO

TROUBLESHOOTING

Wireless BT Connectivity:

• Built-in BT for Wireless Music Streaming

• Simple & Hassle-Free Pairing

• Works with All of Today’s Latest Devices

• Smartphones, Tablets, Laptops, Computers, etc.

• Wireless BT Version: 5.0

• Wireless BT Network Name: ‘PYLEUSA’

• Wireless Range: Up to 32’ ft.

REMOTE CONTROL FUNCTIONS

1. Standby button

2. Choose input AUX/FM/BT/USB signal

3. Mute button

4. Play/Stop button on Mp3 mode, scan function on FM mode

5. Next song on USB/Micro SD Card, next channel on FM mode

6. Previous song of USB/Micro SD Card, last channel on FM mode

7. EQ eect on Mp3 mode

8. Increase speaker volume

9. Choose song number directly on Mp3 mode

10. Stop button

11. Decrease music volume

12. Repeat song on USB/Micro SD Card

www.PyleUSA.com

4www.PyleUSA.com 5

This product can expose you to a chemical or group of chemicals, which may include

“Lead and lead compounds” which is known in the state of California to cause cancer, birth

defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.

1. The audio format in the USB

is incorrect.

2. Improper operation has caused

a process disorder.

3. USB disc is disconnected.

1. Convert audio format into Mp3

format.

2. Reboot the machine.

3. Insert USB disc properly.

MP3

does not

play

Fault Possible Cause Solution

No sound

Distortion

of sound

Karaoke

does not

work

1. No input sound source.

2. Volume is too low.

1. Volume too high.

2. Speaker may be damaged

1. Microphone plug is not fully

inserted.

2. Microphone switch is not on.

3. Microphone volume knob is at

the lowest position.

1. Use a better music signal.

2. Adjust volume.

1. Turn down the volume.

2. If speaker is damaged, repair

or replace it.

1. Plug microphone properly into

the socket.

2. Turn on microphone switch.

3. Adjust microphone volume

properly.

Features:

• True Wireless Stereo System

• High-Powered Speaker System

• Wireless & Portable BoomBox Stereo

• Wireless BT Music Streaming Ability

• Includes Wired Microphone for Karaoke Fun

• Multi-Color Flashing Full Panel LED Lights

• Built-in LED Lights for Stunning Visuals

• FM Radio with Digital LED Display

• Built-in Rechargeable Battery

• Aux (3.5mm) Input

• MP3 Digital Audio File Support

• Connect & Stream Audio from External Devices

• USB Flash Drive Memory Reader

• Micro SD card reader

• 1/4’’Input Jacks for Microphone

• Ported Enclosure for Extended Bass Response

• Integrated Extending Carry Handle

• Treble & Bass Sound Performance Adjustment

• Convenient carrying strap

• X-Bass button for more powerful bass

• 4x18 kinds of DJ sound eects selection for more fun

• Perfect for the Backyard or Park Visits - Instant Party Anytime, Anywhere!

What's in the Box:

• Speaker System

• Wired Microphone

• Remote Control

• Power Adapter

• Carrying Strap

Technical Specs:

• Max Power Output: 600 Watts MAX

• Sound System: 6.5'' Subwoofer x 2 + 1.5”Tweeter

• Selectable LED Light Modes: Three kinds of LED lights modes

• Digital Media File Compatibility: MP3, WMA (USB 2.0)

• Maximum USB Flash Drive Support: Up to 64GB

• Housing Construction Material: Engineered PP + ABS+ Iron Net

• Built-in Rechargeable Battery: Li-ion 3600mAh, 7.4V

• Battery Operated Remote Control:

1 Piece Button Cell Battery CR-2025 (Included)

• Power Supply: 110/240V (9V Power Adapter)

• Dimensions (L x W x H): 18.5’’ x 8.9’’ x 9.4’’ -inches

www.PyleUSA.com

6www.PyleUSA.com 7
