Pyle PLMRF65MW Manuel utilisateur

PLMRF65MB

PLMRF65MW

PLMRF65MW / PLMRF65MB

Dual 6.5’’ Waterproof-Rated Bluetooth Marine Speakers

2-Way Coaxial Full Range Amplied Speaker System with Wireless RF Streaming (600 Watt)

Features:

• Includes (2) 6.5'' Coaxial Speakers (Active + Passive)

• Bluetooth Wireless Music Streaming Ability

• Wireless Radio Frequency (RF) Streaming Ability

• RF Audio Module Supports Additional Speaker

Connectivity

• Extended Range Streaming Performance

• Marine Grade Waterproof-Rated Construction

• Water-Resistant & Weatherproof Design

• Amplied Master Speaker with Built-in 2-Ch.

Digital Amplier

• 2-Way Active Powered Speaker System

• Impressive Wide-Bass Response

• Full Range Stereo Sound Reproduction

• Universal Standard OEM Replacement Size

• RCA Audio Aux (L/R) Connectors

• Hassle-Free Easy Access Speaker Terminals

• Daisy-Chain Ability (Active to Passive Speaker)

as Stereo System

• *Each Speaker Has the Ability to Serve as a Passive

Type Speaker

• Reinforced Surround with Dense Speaker Cone

• Rugged Machined Basket & Grill

with UV Resistant Housing

• Used For Car, Boat, O-Road & Marine Vehicle Applications

Technical Specs:

• Power Output: 600 Watt MAX (300 Watt RMS)

• Marine Grade Rating: IP-X4

• Speaker Composition: Polypropylene Cone,

Butyl Rubber Surround

• Voice Coil: 1.0'', Aluminum (x2)

• Tweeters: 0.5'', Neodymium Dome (x2)

• Impedance: 4 Ohm

• Sensitivity: 90 dB

• Circuit Magnet: 20 oz.

• Frequency Response: 85Hz-20kHz

• Active Speaker Weight: 1.71 lbs.

• Passive Speaker Weight: 1.67 lbs.

• Power Supply: DC 12V

• Sold as: Kit

What’s in the Box:

• (1) 6.5’’ -inch Active Speaker

• (1) 6.5’’ -inch Passive Speaker

• Cut-Out Template

• Mounting Screws

Bluetooth Connectivity:

• Receiver Built-into Active / Master Speaker

• Allows Instant Wireless Music Streaming

• Simple Setup & Hassle-Free Pairing Ability

• Works with All of Today’s Latest Devices

(Smartphones, Tablets, Laptops, Computers)

• Bluetooth Version: 4.2

• Bluetooth Network Name: ‘PyleUSA’

• Wireless Range: 30’+ ft. BT

(100’+ ft. RF Streaming)

Sizes / Dimensions:

• Total Diameter: 6.9’’-inches

• Cut-Out Diameter: 6.75’’ -inches

• Total Depth: 3.97’’-inches

• Mounting Depth: 3.1’’ -inches

www.PyleUSA.com

Dual6.5’’Waterproof-RatedBluetooth

MarineSpeakers

2-Way Coaxial Full Range Amplified Speaker System

with Wireless RF Streaming (600 Watt)

PLMRF65MW-PLMRF65MB

www.PyleUSA.com www.PyleUSA.com

PLMRF65MW - PLMRF65MB

Installation Guide

PLMRF65MW/PLMRF6MB Installation

Ways to Connect

• RF Wireless Audio Connection:

Install both speakers, as active powered speakers. Connect L and R Channel speakers, each to a 12V

power source. Then use pins to press the "CH Set" buttons, simultaneously to pair the speakers.

Upon successful power connection, the R Channel speaker LED indicator light will shine red -- and the

L Channel speaker LED indicator light will shine blue.

*Note: Recommended power installation should include a 10 amp fuse between the power source

and speakers, ensure a proper and adequate power connection is established.

Bluetooth Audio Connection:

Once the speakers are installed and powered, the Bluetooth network name from your device list will

appear as 'PyleUSA'. Upon successful Bluetooth pairing connection you will hear a connection tone

and the speakers will shine with a blue LED indicator light.

Aux-in (External Audio Source) Connection:

The R Channel speaker features low-level audio input connectors to stream audio from external

devices. Upon successful aux audio input connection, the R Channel speaker LED indicator light will

shine green.

*Note: The speakers must not be paired via Bluetooth wireless connection to allow Aux-in audio

mode.

Passive Speaker Connection:

Each speaker also has the ability to be used as a Passive-Type (un-powered) speaker. Ensure a proper

audio source connection is made via each speaker's 'Input Radio Speakers' connectors.

LED INDICATOR

Status

POWER ON

RCA AUX-IN Connection

Bluetooth Connection

Main Speaker ( R Channel) 2nd Speaker (L Channel)

BLUE

RED

GREEN

RED

BLUE

RED

RF Wireless Connection

III

Signal connection

as passive speaker

Signal connection

Using pins to push “CH Set” simultaneously

to get RF Wireless connection

as passive speaker

Audio Signal

Aux-In

(Follow on

Ways to Connect

)

III

(Follow on

Ways to Connect

)

III

“ Bluetooth

Pairing Tone”

1.“Turn on Bluetooth”

2.“Choose PyleUSA”

CH Set CH Set
