Pyle PHP18DJT Manuel utilisateur

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: suppor[email protected]

PHP18DJT

8” Portable Wireless BT Speaker System

TWS Function, Built-in Rechargeable Battery, LED Display,

FM/Aux/MP3/USB/SD w/ ¼’’ Input Jack for Microphone

WARNING

Illegal operation may cause personal injury, which could be fatal and may cause

damage to property. For safety, we do not suggest to charge unit and use micro-

phone together.

1. DO NOT place objects on top of the device, as objects may

scratch the device.

2. DO NOT expose the device to dirty or dusty environments.

3. DO NOT insert any foreign objects into the device.

4. DO NOT expose the device to strong magnetic or electrical ﬁeld.

5. DO NOT use the device in the rain

6. Please check with your Local Authority or retailer for proper

disposaI of electronic products.

7. DO NOT disassemble the device. Only a certiﬁed service

technician should perform repair.

8. The device has apertures to disperse heat. DO NOT block the

device ventilation, the device may become hot and malfunction

as a result.

CONTROL BOARD FUNCTIONS

1. Play/stop music on USB/Micro SD/BT mode, scan FM channel on FM mode

2. USB and micro SD memory card input jack

3. Press and hold to decrease music volume, short press to choose last channel

4. 3.5MM AUX input jack

5. 6.5MM microphone input jack

6. Power switch button

7. Mode button: short press to select USB/Micro SD/AUX/BT/FM mode

8. Menu button: short press to select Bass (b) or Treble ( ) or main volume (U),

and then use Prev (-) or Next (+) button to decrease or increase

9. Charge LED indicator: Red light in charge, blue light full charge

10. DC 9V charge input jack

11. Increase bass eﬀect button

12. Front LED light mode button

(Top mushroom LED light swift button at the back of unit)

13. TWS Function button: Two unit both on Wireless BT mode, press this TWS button

to start TWS pairing.

14. 4 kinds of DJ eﬀect selecting button

15. Microphone volume knob

16. Microphone echo knob

17. Press and hold to increase music volume, short press to choose next channel

www.PyleUSA.com

2www.PyleUSA.com 3

429

TROUBLESHOOTING

Wireless BT Connectivity:

• Built-in BT for Wireless Music Streaming

• Simple & Hassle-Free Pairing

• Works with All of Today’s Latest Devices

• Smartphones, Tablets, Laptops, Computers, etc.

• Wireless BT Version: 5.0

• Wireless BT Network Name: ‘PYLEUSA’

• Wireless Range: Up to 32’ ft.

REMOTE CONTROL FUNCTIONS

1. Standby button

2. Choose input AUX/FM/BT/USB signal

3. Mute button

4. Play/Stop button on Mp3 mode, scan function on FM mode

5. Next song on USB/Micro SD Card, next channel on FM mode

6. Previous song of USB/Micro SD Card, last channel on FM mode

7. EQ eﬀect on Mp3 mode

8. Increase speaker volume

9. Choose song number directly on Mp3 mode

10. Stop button

11. Decrease music volume

12. Repeat song on USB/Micro SD Card

www.PyleUSA.com

4www.PyleUSA.com 5

1. The audio format in the USB

is incorrect.

2. Improper operation has caused

a process disorder.

3. USB disc is disconnected.

1. Convert audio format into Mp3

format.

2. Reboot the machine.

3. Insert USB disc properly.

MP3

does not

play

Fault Possible Cause Solution

No sound

Distortion

of sound

Karaoke

does not

work

1. No input sound source.

2. Volume is too low.

1. Volume too high.

2. Speaker may be damaged

1. Microphone plug is not fully

inserted.

2. Microphone switch is not on.

3. Microphone volume knob is at

the lowest position.

1. Use a better music signal.

2. Adjust volume.

1. Turn down the volume.

2. If speaker is damaged, repair

or replace it.

1. Plug microphone properly into

the socket.

2. Turn on microphone switch.

3. Adjust microphone volume

properly.

Features:

• True Wireless Stereo System

• High-Powered Speaker System

• Wireless & Portable Speaker System

• Wireless BTMusic Streaming Ability

• Includes Wireless Microphone for Karaoke Fun

• Multi-Color Flashing Ring LED Lights

• Built-in LED Lights for Stunning Visuals

• FM Radio with Digital LED Display

• Built-in Rechargeable Battery

• Aux (3.5mm) Input

• MP3 Digital Audio File Support

• Connect & Stream Audio from External Devices

• USB Flash Drive Memory Reader

• Micro SD card reader

• 1/4’’Input Jacks for Microphone

• Ported Enclosure for Extended Bass Response

• Integrated Extending Carry Handle

• Treble & Bass sound performance adjustment

• Convenient trolley and wheels

• X-Bass button for more powerful bass

• Many kinds of DJ sound eﬀects selection for more fun

• Perfect for the Backyard or Park Visits - Instant Party Anytime, Anywhere!

What's in the Box:

• Speaker System

• Wireless Microphone

• Remote Control

• Power Adapter

• AUX Cable

• Tablet stand

Technical Specs:

• Power: 600 Watts MAX

• Sound System: 8'' Subwoofer + 1.5”Tweeter

• Selectable LED Light Modes: Many kinds of LED lights modes

• Digital Media File Compatibility: MP3, WMA (USB 2.0)

• Maximum USB Flash Drive Support: Up to 64GB

• Housing Construction Material: ABS + Iron Net + Wooden

• Built-in Rechargeable Battery: Li-ion 3600mAh, 7.4V

• Battery Operated Remote Control: 1 Piece Button Cell Battery CR-2025 (Included)

• Power Supply: 110/240V (9V Power Adapter)

• AUX Cable Length: 3.94 ft.

• Dimensions (L x W x H): 11.8’’ x 11.6’’ x 20.7 ’’ -inches

• Tablet Stand Dimensions (L x W x H): 6.9’’ x 4.3’’ x 2.7’’ -inches

www.PyleUSA.com

6www.PyleUSA.com 7

This product can expose you to a chemical or group of chemicals, which may include

“Lead and lead compounds” which is known in the state of California to cause cancer, birth

defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that

interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-- Consult the dealer or an experienced radio/TV technician for help.

Warning: changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment

The devices has been evaluated to meet general RF exposure requirement，the device can be

used in portable exposure condition without estriction
