Pyle PLDHR926KT Manuel utilisateur
TouchscreenMultimedia
DiscPlayerBundleKit
PLDHR926KT
Dual Vehicle Headrest Mount Multimedia Entertainment
Systems with Wireless Headphones (9.4’’-inch Displays)
www.PyleUSA.com
2
FRONT PANEL
MULTIMEDIA PLAYER
1. LCD Panel
2. MENU
3. RETURN
4. POWER
5. Pre/rewind forward
6. Next/Fast
7. DC 12V
8. AV2 In jack
9. Earphone jack
10. Micro SD Memory Card Slot
11. USB read port
SIDE PANEL
1. Power
2. Earphone/AV2 jack
3. USB TF port
4. DC 12v Jacket
2 3 654
1
7
9
8
10
11
3
www.PyleUSA.com
1. Main Menu
You can choose DVD disc, USB, Micro SD Memory Card, AV1 and AV2.
2. DVD disc menu
www.PyleUSA.com
4
3. Second main menu, you should touch middle of panel from right to
left to move.
You can simply access all features by tapping on the touch screen buttons.
Tap the icons to enter a desired mode.
Select Language/Beep/Car Logo/Background/Aspect ratio and IR setup
5
www.PyleUSA.com
4. Infrared Setup
5. FM Setup
www.PyleUSA.com
6
6. USB Card Read
7. SD Card Read
7
www.PyleUSA.com
INSTALLATION
1. Take out the machine, remove the bracket.
2. Remove the screws from bracket.
3. Put the plastic bracket parts in between two metal poles ,at the same
time, push 2 screws to x up bracket.
4. Hold up unit, insert the metal plate in black of the unit into plastic bracket
parts, then adjust it to the right angle and x it tightly, at last lower the
orignal car headrest to the appropriate position.
www.PyleUSA.com
8
WIRING
Attention
1. Do not put the machine in the rain or damp environment lest outbreak of
re or any damage to machine.
2. Do not repair the machine by youself. Please turn o the machine and
inform us if any problem found, the factory or the agent will arrange
specialized personnel to disassemble and repair the machine for you .
3. Please keep the machine away from dampness, dust, oil and straight
sunlight.
4. Do not use diluents or other chemical cleaner when cleaning the machine.
Please clean the machine by soft cloth with special cleaner.
5. Please keep the machine in a good environment. The storage temperature
for this machine is from 68 °F to 70T and the operating temperature for
this machine is from -10T to 140 °F.
6. This machine supports 1080P and most video le like DIVX/MPEG4 /
MP3/WMAR/JPEG
7. Please prevent the machine from the inuence of other equipment.
8. For your safty,please do not turn or operate this machine when driving as
it may be ileagal in some countries and regions.
9. Safe power supply: DC12V (voltage range:10V-14V)
10. There may be some small and bright spots on the screen. This is a
common technical matter and does not indicate any quality problem of
this machine.
Audio Out Right (Red)
Audio Output Left (White)
Video Output (Yellow)
VIdeo Input (Yellow)
Audio Input Right (Red)
Audio Input Left (White)
DC + 12V (Red)
GND (Black)
9
www.PyleUSA.com
TROUBLESHOOTING
CLEANING
• Do not leave this product submerged in water
• When cleaning the device, use a clean dry cloth to wipe the device clean.
(Do not use solvents).
• Clean only with a clean and dry cloth.
TROUBLES
No sound
and image
No image
No sound
Color cast
No power
SOLUTIONS
Power is disconnected;
the machine is not turned ON
signal wire is disconnected
Volume too low or the volume setup is not workable
function menu setup is incorrect; weak signal
Voltage is not accurate: check interconnect circuit;
Fuse is disconnected: change fuse specication
Black screen Incorrect setup of image luminance and contrast;
Undervoltage
Blurring and
unstable image Disc is scratched
No image after
loading the disc
Only audio frequency for the disc;disa is scratched;
disc for format is not supported
Instable sound
caused by
vibration
DVD is dirty or seriously damaged
Instable sound
even with no
vibration
Disc is dirty or scratched clean or replace the disc
www.PyleUSA.com
10
PLDHR926KT
Touchscreen Multimedia Disc Player Bundle Kit
Dual Vehicle Headrest Mount Multimedia Entertainment Systems
with Wireless Headphones (9.4’’ -inch Displays)
Features:
• Dual Universal Vehicle Headrest Mount Displays
• Audio & Video Car Entertainment System
• Touchscreen Display Panel
• Top-Loading CD/DVD Players
• Hi-Res LCD Wide-Screen Video
• Full HD 1080 Support
• User-Friendly Control Interface
• Built-in Stereo Speakers
• FM Radio Transmitter
• Front Panel Button Controls
• Connect & Stream External Devices
• USB Flash & Micro SD Memory Card Readers
• Digital File Playback: Audio, Image & Video Files
• Headphone Jack, 3.5mm
• RCA (Audio/Video) Wiring Harness
• Convenient Removable Leather Screen Cover
• Built-in IR Transmitter Support for Wireless IR Headphones
• Easily Attaches to Front-Seat / Back-Seat Headrests
• Includes All Necessary Hardware & Cables for Installation
• *Can be Hard-Wired or Powered via Included Plug-in Cigarette Lighter
Power Cable
