Pyle view PLMD7 Manuel utilisateur
WIRING CONNECTION
PLMD7
Installation
To DVD player
RCA Line Output
White Red RED
+12v Power
RED
+12v Power
Car Antenna
Off On
Wor.2
BLACK
GROUND
BLACK
GROUND
NO
1
3
7 Channel FM Stereo
Transmitter
PLMD7
24
FM TRANSMITTER
This device complies 15 the rules
FCCID:RJX93FMT07
R
R
INSTRUCTION MANUAL
PLL FM Stereo Transmitter
BEFORE INSTALLING THE TRANSMITTER
INSTALLATION
FM RADIO FREQUENCY PRESET
Do not install the unit in the following locations.
Locations exposed to direct sunlight.
Where hot air is discharged from the car heater.
In areas subject to extreme temperatures.
Do not install the unit in the following locations.
Locations exposed to direct sunlight.
Where hot air is discharged from the car heater.
In areas subject to extreme temperatures.
The FM Stereo Transmitter must be mounted within 24inches of your radio so
that its power cable can reach the radio power antenna lead.
The FM Station Frequency Selector Switch is located in the face and you may
wish to change it after your initial checkout or somtime in the future.
The FM Stereo Transmitter must be mounted within 24inches of your radio so
that its power cable can reach the radio power antenna lead.
The FM Station Frequency Selector Switch is located in the face and you may
wish to change it after your initial checkout or somtime in the future.
The FM Stereo Transmitter can operate on from 87.7MHz to 88.9MHz.
(7channel-200KHz Step)
The Frequency Selector Slide Switch is on one channel of the Transmitter
and was set 87.7MHz at the factory. Assuming it is still there, turn on the car
stereo and select FM band operation.Tune the radio to 87.7MHz ( depending
on frequency towhich the installer has set the unit),or push the pre-set memory
button.
The FM Stereo Transmitter can operate on from 87.7MHz to 88.9MHz.
(7channel-200KHz Step)
The Frequency Selector Slide Switch is on one channel of the Transmitter
and was set 87.7MHz at the factory. Assuming it is still there, turn on the car
stereo and select FM band operation.Tune the radio to 87.7MHz ( depending
on frequency towhich the installer has set the unit),or push the pre-set memory
button.
INTERFERENCE ON 87.7MHz:
If interference experienced is on 87.7MHz,change the position of the
frequency select switch in the face of the FM Stereo transmitter and
tune the radio 87.7-88.9MHz.
If interference experienced is on 87.7MHz,change the position of the
frequency select switch in the face of the FM Stereo transmitter and
tune the radio 87.7-88.9MHz.
SPECIFICATIONS:
Frequency: 87.7MHz to 88.9MHz(7channel-200KHz Step)
RF Output Level: 60dB Max
S/N Ratio: 65dB
Stereo Separation: 40dB
FM Modulation Depth: 75KHz at L+R+Pilot
Operating Voltage: 10 V~16VDC
Dimensions: 44R 23Hmm
Weight: 123g
Frequency: 87.7MHz to 88.9MHz(7channel-200KHz Step)
RF Output Level: 60dB Max
S/N Ratio: 65dB
Stereo Separation: 40dB
FM Modulation Depth: 75KHz at L+R+Pilot
Operating Voltage: 10 V~16VDC
Dimensions: 44R 23Hmm
Weight: 123g
Specifications and design are subject to change without noticeSpecifications and design are subject to change without notice
FREQUENCY SELECTOR SWITCH
Frequency(MHz)
87.7MHz
87.9MHz
88.1MHz
88.3MHz
88.5MHz
88.7MHz
88.9MHz
Frequency(MHz)
87.7MHz
87.9MHz
88.1MHz
88.3MHz
88.5MHz
88.7MHz
88.9MHz
1234
