PROAIM Fly 22 Manuel utilisateur

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Fly 22’ Crane with LW-100 Stand (P-FLY-22-S)

Assembly Manua l

LW-100 Jib Stand Spreader

2X Red Cables

2X Blue Cables

Weight Rod

Secon 1A

Secon 2B

Secon 3C

Secon 4D

Secon 5E

Weight Closer Weight Safety Ends Connecvity Plate

Cable Guide Support Rods

Packing

Safety Hints

ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT DAMAGE TO EQUIPMENT

& OPERATOR!

 The crane may not be assembled or operated under the inuence of alcohol, drugs or any other intoxi-

cang substances. Lack of aenon while connecng the components can cause substanal damage

to equipment/operator.

 The crane may only be operated on levelled horizontal posion. Make sure that the surface is stable.

 To prevent any harm or injury, properly join all secons of the crane. It is suggested to use the support

stand while telescoping the complete length.

 Do not exceed the maximum payload capacity of the Tripod. Do not adjust the tripod leg locks or move

the Tripod or remove the ground spreader while the crane is aached to the Tripod.

 Always connect the steel cables properly to provide stability to the system. They should not negavely

impact the movements of the crane in any way.

 Aer setup of the crane, the pan-lt head / gimbal head shall be posioned under the central pivot

secon. In the assembled state, when the pan-lt head / gimbal head is higher than the central pivot

secon, there should be someone to look aer the crane system.

 The complete panning & liing range around it must be kept free. Avoid anybody standing under the

crane. No loose objects may be stored or placed on it. Be very careful while using it indoors.

 Never operate the crane near high-voltage power cables. It holds danger to life.

 Parcular care is required when operang the crane in unfavourable weather condions. The crane

must be shut down in sucient me. When it is used on a rainy day, the pan-lt head / gimbal head

and controlling bar shall be protected against rain.

 When you want to transport the crane, lock the Pan & Tilt Axis for safety. Make sure that the

components do not rub together and cause any material wear.

 Take out the Spreader from Accessory Bag.

Spread the spreader on oor and open the

legs of spreader with help of provided knob.

Jib Stand Setup

 Open the legs of 100mm jib stand then aach

it to spreader, lock it in place with the rubber

grips.

 Now mount central fork onto tripod , then

aach boom clamp to secure it well.

Jib Secons Setup

 Slide the (1A Secon) into central fork

(secon 2B) and ghten with help of knob. Slide

 Before the counterweights are removed, ensure the remote head is resng on the support stand.

Then gradually remove the counterweights before the remote head, camera or other parts.

 In the interest of safe crane operaon, avoid abruptly swivelling or stopping the crane; otherwise, it

may cause severe damage to equipment.

FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE-FREE OPERATION.

SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS AVAILABLE ‘ONLINE’ BY

CONTACTING THE SALES REPRESENTATIVE.

 Insert connecng bars (secon 1A) aached

it with both the ends (weight bar & secon

2B) the both ends using the provided knob.

 Using the same approach insert 3rd, 4th and

remaining secons to joints and secure via

knobs as shown.

 Aach short cable guide rod on 3rd secon

properly. Insert knob onto the cable guide

rod and ghten the knob properly.

Cable Guide & Support Rod Setup

 Loosen the bolts on cable guide rod in order

to aach cable guide support rod to it.

Reghten the bolt.

 Using the same steps to and aach long

cable guide rod on 2nd secon as shown.

 Insert weight rod on (1 secon) and ghten

the bolt with help of allen key as shown in

the picture.

Connecon Bar

Knob

 Then insert safety ends at both sides onto

the weight rod.

Cable Code (Red)

Stability Cables Setup

 Aach (Red) cable to (2B secon) & (secon

3C) & align it properly with help of cable

guide clamp and aached with (5E secon).

 Aach cables and insert the hook onto the

weight rod.

 Align it to the cable guide side rod and aach

it to the end (secon 5th).

NOTE: You can adjust the cable with help of

wire tensioner.

 Now aach both red cable hook onto the

provided bolts properly as shown.

Cable Code (Blue)

NOTE: Both the red cables are following same steps.

 Aach your head plate properly and ghten

the knob.

 Loosen the knob and adjust the height and

then reghten the knob.

 Now slide in weight to it as per your

requirement and screw in weight closer

properly. (Counter weight not included)

YOUR PROAIM FLY 22’ CAMERA CRANE PRODUCTION PACKAGE

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
