PROAIM CINEMA Series Manuel utilisateur

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything

that is listed below.

Polaris Portable Dolly with Universal Track Ends (DL-PLRS-01)

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Assembly Manual

Polaris Dolly with 16 wheels (Part-1)

Conversion Ring

(Part-7)

75mm Bowl Adapter

(Part-5)

100mm Bowl Adapter

(Part-6)

Break System

(Part-4)

2 x Universal Track Ends (Part-2) Center Support (Part-3)

Wheel color may be vary according to availability

Safety Hints

ATTENTION: PLEASE READ THIS BEFORE USING TO PREVENT SERIOUS DAMAGE TO THE GEAR!

BE HIGHLY VIGILANT OF SURROUNDINGS

Check the area you will be shooting in, before shooting. Make sure your path is clear. Look for

obstacles and note anything you might run into or trip over. Extra care is also necessary when

tackling stairs and other kinds of uneven ground.

ALWAYS WEAR PROTECTIVE GEAR

If you intend to shoot while moving fast or while traversing uneven terrain, do not hesitate to

wear protective gear as knee or elbow pads, or a helmet.

DO NOT SHOOT IN UNSAFE CONDITIONS

Avoid situations where one commonly falls like skis, skates or running in muddy fields.

ADULT SUPERVISION IS RECOMMENDED

Minors using this product should have adult supervision.

FOLLOWING THESE GUIDELINES WILL PROVIDE BETTER SHOTS AND TROUBLE-FREE OPERATION.

SHOULD YOU NEED ADDITIONAL INFORMATION, TECHNICAL ASSISTANCE IS AVAILABLE

‘ONLINE’ BY CONTACTING YOUR SALES REPRESENTATIVE

SpeciﬁcaƟons

Polaris Dolly

‐Construcon: Dolly Platform: High-grade CNC Aluminum

Track Wheels: High-density Polyurethane

Bearings: High-Speed Stainless Steel

‐Load Capacity: up to 200kg/440lb, Rest depends on track capacity

‐Camera Mount: Incorporated Mitchell Mount

75mm & 100mm Bowl Adapters

Optional Mitchell to 150mm adapter is available for purchase.

‐Compatible Track: 1.5'' to 2'' (38 – 50.8mm)

‐Track Distance: 12'' Center distance

‐Accessory Mounting: 2 x 3/8" Through Holes

2 x 1/4"-20 Threaded

2 x 3/8"-16 Threaded

‐Temperature Maximum: 100°F (37.8°C)

‐Dimensions (L X W) Dolly: 10" x 14" / 25.4 x 35.5 cm

‐Package Weight: 28.4 kg / 62.6 lb

‐Box Dimensions (L X W X H): 86 x 60 x 35 cm

Here we have used 8ft track (not included) for

assembling purpose. So, for longer track, you

need to place the central support (Part-3) in

the middle of the track, as shown in photo.

Polaris Dolly Setup

1Now place the dolly (Part-1) onto the track.

The handles part of the dolly platform

(Part-1) should be inside of the track

(not included) as shown. Make sure all wheels

are aligned correctly on the track (not

included) and dolly runs smoothly.

5Mount the break bracket (Part-4) on side of the

dolly platform (Part-1) & tighten the knob.

Adjust the position of the bracket (Part-4) so it

goes under the track to prevent the platform

(Part-1) from tilting out.

2Insert the universal track ends (Part-2) on the

track (not included).

Use the supplied long thumb screws to lock

the track into position.

7.Now, mount the 75mm bowl adapter (Part-5)

onto the dolly platform (Part-1)

Note: Assembly steps for 75mm

(Part-5) and 100mm (Part-6) Bowl are same.

2. 3.

5. 6.

Now, mount the fluid head (Not Included) onto

the portable dolly (Part-1)

Insert the conversion ring (Part-7) from the

bottom side of dolly through the fluid head

screw.

Note: To prevent the 75mm/100mm or any other fluid head from slipping through the dolly platform's

centre hole, we use a conversion ring, Conversion Ring reduces the gaping of the hole size of the dolly

platform. If the size of fluid head locking base is smaller than the center hole of the dolly platform, then we

have to remove the bolts and use the conversion ring to lock the fluid head in place. But if the size of fluid

head locking base matches the center hole of the dolly platform, then we do not need a conversion ring.

We can directly lock the fluid head with the locking lever.

13 Attach the Centre Support Bar (Part-3) under

the centre of the track (Part-1) system.

Help of a Support stand (not included).

15 Now mount your Fluid Head (not included)

onto the Platform (Part-1).

Tighten the knob Properly.

17 Then mount your camera setup.

Note: If you need higher level shots, then you

can put universal track end (Part-2) on C-Stands

(not included).

11. Mount the Universal track ends (Part-2) onto

C-stand (not included)

Tighten the provided knob to secure it

properly.

11. 12.

10.

15.

14.

13.

17.

16.

10. Then tighten properly to secure with it.

YOUR PROAIM POLARIS PORTABLE CAMERA DOLLY

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
