The Ultimate In Style & Performance

Owners Manual

21 Healey Road

Dandenong, 3175

Victoria, Australia ACN # 088 09 1

www.pridemobility.com

SAFETY GUIDELINES

NOTE: This owners manual is compiled from the latest specifications and product information avail-

able at the time of publication. We reserve the right to make changes as the become necessar . An

changes to our products ma cause slight variations between the illustrations and explanations in this

manual and the product ou have purchased.

The symbols below are used throughout this owner's manual and on the scooter to identify warnings and important

information. It is very important for you to read them and understand them completely.

WARNING! Indicates a potentially hazardous condition/situation that can cause personal

injury, equipment and/or property damage.

ANDATORY! These actions should be performed as specified. Failure to perform

mandatory actions can cause injury to personnel and/or damage to equipment.

PROHIBITED! These actions are prohibited; do not perform at any time or in any situation.

Performing a prohibited action can cause personal injury and/or equipment damage.

Please fill out the following information for quick reference:

Pride Provider:______________________________________________________________________

Purchase ate:______________________________________________________________________

Address:___________________________________________________________________________

Phone Number:______________________________________________________________________

Serial Number:_______________________________________________________________________

Pride Mobility Products Pty. Ltd.

INFMANU2778/RevA/March 2005

088 609 661

Sonic www.pridemobility.com

CONTENTS

I. INTRODUCTION ......................................................................................................................... 4

II. SAFETY ......................................................................................................................................... 5

III. SPECIFICATIONS ................................................................................................................... 16

IV. YOUR SCOOTER ...................................................................................................................... 18

V. BATTERIES AND CHARGING ............................................................................................ 21

VI. OPERATION ............................................................................................................................... 26

VII. COMFORT ADJUSTMENTS................................................................................................ 28

VIII. DISASSEMBLY AND ASSEMBLY ..................................................................................... 30

IX. BASIC TROUBLESHOOTING ............................................................................................. 33

X. CARE AND MAINTENANCE ................................................................................................ 35

XI. WARRANTY ................................................................................................................................36

4www.pridemobility.com Sonic

I. INTRODUCTION

SAFETY

Welcome to Pride Mobility Products Australia Pty. Ltd

. (Pride). he product you have purchased combines state

of the art components with safety, comfort and styling in mind. We are confident the design features will provide

you with the conveniences you expect during your daily activities. Understanding how to safely operate and care

for this product should bring you years of trouble free operations and service.

Read and follow all instructions, warnings, and notes in this manual and all other accompanying literature before

attempting to operate this product for the first time. In addition, your safety depends upon you, as well as your

provider, caretaker, or healthcare professional in using good judgement.

If there is any information in this manual which you do not understand, or if you require additional assistance for

setup or operation, please contact your authorised Pride Provider. Failure to follow the instructions, warnings,

and notes in this manual and those located on your Pride product can result in personal injury or product

damage and will void Prides product warranty.

PURCHASER’S AGREEMENT

By accepting delivery of this product, you promise that you will not change, alter or modify this product or remove

or render inoperable or unsafe any guards, shields, or other safety features of this product; fail, refuse or neglect to

install any retrofit kits from time to time provided by Pride to enhance or preserve the safe use of this product.

INFORMATION EXCHANGE

We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about

the safety and reliability of your new scooter, and about the service you received from your authorised Pride

Provider. Please notify us of any change of address, so we can keep you apprised of important information about

safety, new products, and new options that can increase your ability to use and enjoy your scooter. Please feel free

to contact us at the address below:

Pride Mobility Products Australia Pty. Ltd.

21 Healey Road

Dandenong, 3175

Victoria, Australia

NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact

us and we will be glad to send you a new one immediately.

Sonic www.pridemobility.com

PRODUCT SAFETY SYMBOLS

he symbols below are used on the scooter to identify warnings, mandatory actions, and prohibited actions. It is

very important for you to read and understand them completely.

Read and follow the information in the owners manual.

Pinch/Crush points created during assembly.

Maximum seating weight.

II. SAFETY

Place unit on level ground and stand behind or to one side when changing from

drive mode to freewheel mode or freewheel mode to drive mode.

Loc ed and in drive mode.

Unloc ed and in freewheel mode.

Front-to-rear plug orientation.

EMI-RFI- This product has been tested and passed at an immunity

level of 20 V/m.

Do not use a cell phone, wal ie/tal ie, laptop or other radio transmitter while

operating.

6www.pridemobility.com Sonic

Do not remove anti-tip wheels.

Avoid exposure to rain, snow, ice, salt or standing water whenever possible.

Maintain and store in a clean and dry condition.

Removal of grounding prong can create electrical hazard. If necessary, properly

install an approved 3-pronged adapter to an electrical outlet having 2-pronged

plug access. Failure to heed could result in personal injury and/or property damage.

Prevent personal injury and equipment damage. Do not connect an extension

lead to the AC/DC converter or the battery charger.

Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to

reduce the ris of lea age or explosive conditions.

Explosive conditions.

Contact with tools can cause electrical shoc .

Use only AGM or Gel-Cell batteries.

II. SAFETY

Sonic www.pridemobility.com

II. SAFETY

GENERAL

Your scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an exten-

sive variety of products to best fit the individual needs of the scooter user. Please be aware that the final selection

and purchasing decision regarding the type of scooter to be used is the responsibility of the scooter user who is

capable of making such a decision and his/her healthcare professional (i.e., medical doctor, physical therapist, etc.).

he contents of this manual are based on the expectation that a mobility device expert has properly fitted the

scooter to the user and has assisted the prescribing healthcare professional and/or the authorised Pride Provider in

the instruction process for the use of the product.

here are certain situations, including some medical conditions, where the scooter user will need to practice

operating the scooter in the presence of a trained attendant. A trained attendant can be defined as a family member

or care professional specially trained in assisting a scooter user in various daily living activities.

As you begin using your scooter during daily activities, you will probably encounter situations in which you will

need some practice. Simply take your time and you will soon be in full and confident control as you manoeuvre

through doorways, on and off of lifts, up and down ramps, and over moderate terrain.

Below are some precautions, tips, and other safety considerations that will help the user become accustomed to

operating the scooter safely.

MODIFICATIONS

Pride has designed and engineered your scooter to provide maximum mobility and utility. However, under no

circumstances should you modify, add, remove or disable any feature, part or function of your scooter.

WARNING! Do not modify your scooter in any way not authorised by Pride. Unauthorised

modifications may result in personal injury and/or damage to your scooter.

REMOVABLE PARTS

WARNING! Do not attempt to lift or move your scooter by any of its removable parts.

Personal injury and damage to the scooter may result.

MANDATORY! Do not operate your new scooter for the first time without completely reading

and understanding this owners manual.

8www.pridemobility.com Sonic

II. SAFETY

PRE-RIDE SAFETY CHECK

Get to know the feel of your scooter and its capabilities. Pride recommends that you perform a safety check before

each use to make sure your scooter operates smoothly and safely. For details on how to perform these necessary

inspections, see X. Care and Maintenance.

Perform the following inspections prior to using your scooter:

nCheck for proper tyre inflation if equipped with pneumatic tyres.

nCheck all electrical connections. Make sure they are tight and not corroded.

nCheck all harness connections. Make sure they are secured properly.

nCheck the brakes.

nCheck battery charge.

If you discover a problem, contact your authorised Pride Provider for assistance.

TYRE INFLATION

If your scooter is equipped with pneumatic tyres, you should check or have the air pressure checked at least once a

week. Proper inflation pressures will prolong the life of your tyres and help ensure the smooth operation of your scooter.

WARNING! It is critically important that 2-2.4 bar (30-35 psi) tyre pressure be maintained

in pneumatic tyres at all times. Do not underinflate or overinflate your tyres. Low pressure

may result in loss of control, and overinflated tyres may burst. Failure to maintain 2-2.4

bar (30-35 psi) tyre pressure in pneumatic tyres at all times may result in tyre and/or wheel

failure, causing serious personal injury and/or damage to your scooter.

WARNING! Inflate your scooter tyres from a regulated air source with an available pressure

gauge. Inflating your tyres from an unregulated air source could overinflate them, resulting

in a burst tyre and/or personal injury.

WEIGHT LIMITATIONS

Your scooter is rated for a maximum weight capacity. Refer to the specifications table for this limit.

WARNING! Exceeding the weight capacity voids your warranty and may result in personal

injury and damage to your scooter. Pride will not be held responsible for injuries and/or

property damage resulting from failure to observe weight limitations.

WARNING! Do not carry passengers on your scooter. Carrying passengers may result in

personal injury and/or property damage.

INCLINE INFORMATION

More and more buildings have ramps with specified degrees of inclination, designed for easy and safe access.

Some ramps may have turning switchbacks (180-degree turns) that require you to have good cornering skills on

your scooter.

nProceed with extreme caution as you approach the downgrade of a ramp or other incline.

nake wide swings with your scooter around any tight corners. If you do that, the scooters rear wheels will

follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing corners.

nWhen driving down a ramp, keep the scooters speed adjustment set to the slowest speed setting to ensure a

safely controlled descent.

nAvoid sudden stops and starts.

Sonic www.pridemobility.com

II. SAFETY

When climbing an incline, try to keep your scooter moving. If you must stop, start up again slowly, and then

accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the slowest

setting and driving in the forward direction only. If your scooter starts to move down the incline faster than you

anticipated or desired, allow it to come to a complete stop by releasing the throttle control lever. hen push the

throttle control lever forward slightly to ensure a safely controlled descent.

WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the

incline. Drive your scooter straight up the incline. This greatly reduces the possibility of a

tip or a fall. Always exercise extreme caution when negotiating an incline.

WARNING! Do not drive your scooter across the side of an incline or diagonally up or down

an incline; do not stop, if possible, while driving up or down an incline.

WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas

covered with snow, ice, cut grass or wet leaves).

WARNING! When on any sort of an incline or decline, never place the scooter in freewheel

mode while seated on it or standing next to it.

WARNING! Even though your scooter is capable of climbing slopes greater than those

illustrated in figure 1. do not, under any circumstances, exceed the incline guidelines or

any other specifications presented in this manual. Doing so could cause instability in your

scooter, resulting in personal injury and/or damage to your scooter.

Handicap public access ramps are not subject to government regulation in all countries, and therefore do not

necessarily share the same standard percent of slope. Other inclines may be natural or, if man-made, not designed

specifically for scooters. Figure 1 illustrates your scooters stability and its ability to climb grades under various

weight loads and under controlled testing conditions.

hese tests were conducted with the scooters seat in the highest position and adjusted rearward on the seat base

to its farthest rearward position. Use this information as a guideline. Your scooters ability to travel up inclines is

affected by your weight, your scooters speed, your angle of approach to the incline, and your scooter setup.

WARNING! Any attempt to climb or descend a slope steeper than what is shown in figure

1 may put your scooter in an unstable position and cause it to tip, resulting in personal

injury.

113 kg

14.1%/8˚

136 kg

10.5%/6˚

90 kg

18.8%/9˚

68 kg

18.8%/9˚

Figure 1. Maximum Recommended Incline Angles

10 www.pridemobility.com Sonic

II. SAFETY

CORNERING INFORMATION

Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility of

tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning), uneven road

surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction (such as passing from

a grassy area to a paved area  especially at high speed while turning), and abrupt directional changes. High

cornering speeds are not recommended. If you feel that you may tip over in a corner, reduce your speed and

steering angle (i.e., lessen the sharpness of the turn) to prevent your scooter from tipping.

WARNING! When cornering sharply, reduce your speed. When using your scooter at higher

speeds, do not corner sharply. This greatly reduces the possibility of a tip or fall. To avoid

personal injury or property damage, always exercise common sense when cornering.

BRAKING INFORMATION

Your scooter is equipped with these powerful brake systems:

nRegenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/

stop position.

nDisc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or when

power is removed from the system for any reason.

Figure 2A. Increased Stability Driving Position

Figure 2. Normal Driving Position

When you approach an incline, it is best to lean forward. See figures 2 and 2A. his shifts the center of gravity of

you and your scooter toward the front of the scooter for improved stability.

NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the

powered scooter may rollback approximately 30.5 cm before the brake engages. If the throttle con-

trol lever is released while moving in reverse, the powered scooter may rollback approximately one

metre before the brake engages.

Autres manuels pour Sonic

Table des matières

Autres manuels Pride Mobility Scooter

Pride Mobility

Pride Mobility Celebrity DX Manuel utilisateur

Pride Mobility

Pride Mobility PMV Series Manuel utilisateur

Pride Mobility

Pride Mobility Go-Go Elite traveller Manuel utilisateur

Pride Mobility

Pride Mobility KOLJA ELITE Manuel utilisateur

Pride Mobility

Pride Mobility TRAVEL SCOOTER Series Manuel utilisateur

Pride Mobility

Pride Mobility Legend SC3000 Manuel utilisateur

Pride Mobility

Pride Mobility Colt Twin Manuel utilisateur

Pride Mobility

Pride Mobility scooter Manuel utilisateur

Pride Mobility

Pride Mobility The Ultimate In Style & Performance Manuel utilisateur

Pride Mobility

Pride Mobility Wrangler Manuel utilisateur

Pride Mobility

Pride Mobility raptor series Manuel utilisateur

Pride Mobility

Pride Mobility INFINFB2311 Manuel utilisateur

Pride Mobility

Pride Mobility Go-Go Ultra X Manuel utilisateur

Pride Mobility

Pride Mobility Sidekick Manuel utilisateur

Pride Mobility

Pride Mobility Maxima Scooter SC940 Manuel utilisateur

Pride Mobility

Pride Mobility Rally SC151 Manuel utilisateur

Pride Mobility

Pride Mobility Sidekick Manuel utilisateur

Pride Mobility

Pride Mobility Hurricane Manuel utilisateur

Pride Mobility

Pride Mobility VICTORY 10 Manuel utilisateur

Pride Mobility

Pride Mobility Celebrity XL deluxe Manuel utilisateur

Pride Mobility

Pride Mobility SPORTRIDER SR-XL3 Manuel utilisateur

Pride Mobility

Pride Mobility Legend XL Manuel utilisateur

Pride Mobility

Pride Mobility Victory XL Manuel utilisateur

Pride Mobility

Pride Mobility Legend 3-Wheel Scooter Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
