Prestigio MultiPad PMP5070 Manuel utilisateur

PMP5070 EN - 1

USER MANUAL

Prestigio MultiPad

PMP5070

1. Packing List

1. Prestigio MultiPad 4. USB Cable

2. Quick Start Guide 5. Warranty Card

3. AC Adapter 6. Legal and Safety notice

2. Device Overview

Earphone Jack

arphones connection

DC Port

AC adapter

connection for charging.

Micro USB Port

USB connect

ion

Power\Lock

Switch Press the switch left to turn on the device.

Press the switch right to turn off the screen.

When the device is on, but the screen is off,

press the switch left to turn on the screen.

EN – 2PMP5070

USER MANUAL

Prestigio MultiPad

PMP5070

Press and hold to select one of the following

options:

Power off: Turn off the device.

Suspend: Activate sleep mode.

Cancel: Return to the home screen.

Micro SD Card

Slot

Insert

the SD card

Charge Indicator

harging status indicator

Reset Button

Reboot

the device when it fails to operate

normally.

Leg Stand

Open to comfortably position the device on

the vertical surface

Getting Started

3. Charging

The battery may not be fully charged when first unpacked.

It is recommended to fully change the device before first use.

Insert the DC connector to the DC port on the device and connect the

power adapter to the wall socket for charging. The battery can NOT be

charged via USB.

The indicator glows in red while charging, and in yellow, when the

battery is fully charged.

Normally it takes approximately 3 hours to fully charge the device.

Operating the device while charging with the AC adapter may extend

the time of full charging.

Note:

It is recommended to extract the DC adapter from the wall socket when

not in use, since it consumes energy all the time when connected to the

wall socket.

4. Power on/Power off

Press and hold the Power\Lock switch to turn on the device. It will

automatically enter the Home screen after the start-up screen. The

device is ready for use when the home screen is displayed.

Slide on the left and hold the Power\Lock switch to select the

PMP5070 EN - 3

USER MANUAL

Prestigio MultiPad

PMP5070

turning off option.

Power off: Turn off the device.

Suspend: Activate sleep mode.

Cancel: Return to the home screen

Press the switch left to turn on the device. Press the switch right to

turn off the screen. When the device is on, but the screen is off, press

the switch left to turn on the screen.

5. Startup wizard

When using the device for the first time (or after resetting all user’s

personalized settings) the device will automatically launch the

Startup Wizard.

As a first step the device’s accelerometer will be calibrated. To

perform the calibration, please, follow the on-screen instructions.

Press to select the desired system language from

the list. Startup wizard interface will offer various time and date

settings.

If you wish to enable all preinstalled programs, press Install 3rd

party applications. The preinstalled programs and applications will

be activated during several minutes after the Startup Wizard has

finished.

After the Startup Wizard you will be directed to home screen.

EN – 4PMP5070

USER MANUAL

Prestigio MultiPad

PMP5070

Home screen

6. Home screen

Your device has a resistive sensitive screen. It is operated by touching

the screen surface with your finger.

Status bar

The status bar displays the home button, time, battery status, alarm,

WiFi and controls area.

Home Button

Touch the home button to return to the

home screen.

Touch and hold the home button to display

recently opened items.

Time and WiFi area Displays the current time and the alarm symbol,

when Alarm is activated.

Connected to a WiFi network.

Battery status Displays the battery power or charging progress.

PMP5070 EN - 5

USER MANUAL

Prestigio MultiPad

PMP5070

Battery is full

Battery is low and must be recharged

Battery is extremely low and must be

recharged immediately

Battery is empty and must be recharged

immediately

Battery is charging

Controls area Contains volume controls , return

button and menu button .

Applications drawer By pressing you can open the list of all

applications, folders and shortcuts on the device.

For optimal viewing experience, the screen orientation changes

automatically to portrait or landscape depending on how you hold the

device.

Downloaded applications may not support automatic screen

orientation to portrait or landscape.

To modify the default behavior, open the orientation settings by

touching →Settings →Sound & display→Orientation.

Prestigio home screen allows to adjust it according to the user’s

preferences.

EN – 6PMP5070

USER MANUAL

Prestigio MultiPad

PMP5070

Prestigio home screen is made up of four individual rooms. Each room

fits the physical display border and can be set to have its own

shortcuts and widgets. You can move around the home screen in two

ways:

1. Flick the Home screen horizontally until the desired room is

displayed.

2. Touch the dots at the bottom right and left of the screen to

move to the desired room of the home screen.

All the space of the main screen can be used for installing applications,

widgets and shortcuts.

7. Customizing the home screen

To add an item to the home screen:

Press the button, choose the desired item, touch it and hold, until the

home screen appears. Choose the desired location on the home

screen and release the item, or

Press , then Add, and choose the item you wish to add from the

list.

To change wallpapers:

Press , then Wallpaper, and choose the wallpaper you wish to

add from the list; or

Press , then Add, and choose the wallpaper you wish to add from

the list.

To move a Home screen item:

Touch and hold the item you want to reposition until it magnifies and

becomes movable.

With your finger remaining in contact with the item on the screen,

drag the item to another location on the screen.

Release the item in the desired location.

PMP5070 EN - 7

USER MANUAL

Prestigio MultiPad

PMP5070

To remove a Home screen item:

Touch and hold an item such as a widget, shortcut, or folder that you

want to remove, until it magnifies and becomes movable.

Drag the item onto the top of the delete icon , and when the item

becomes red release it.

8. Pop-up menu

Touch the Menu button to open or close the pop-up menu that lists

available options for the current application, or actions that you can

perform on the current screen.

To select an option or item on the pop-up menu:

Touch the Menu button to open the pop-up menu.

Touch the desired item on the pop-up menu.

If the menu has a scroll bar on the right side, you can flick the menu

until the desired item is found.

Touch the Menu button again to close the pop-up menu.

9. On-screen Google search bar

EN – 8PMP5070

USER MANUAL

Prestigio MultiPad

PMP5070

You can access the Google Search tool directly from home screen by

tapping anywhere on the Google search bar.

Note:

Please, make sure your device is connected to the Internet.

Keyboard controls for inserting text:

Touch to type letters into the field where the cursor appears.

Touch and hold to type accented letters for applicable languages.

Based on the letters being typed, the keyboard shows suggested

words along the top of the keyboard, the most probable one

highlighted in color.

You can touch a suggested word to enter it into the text field.

Touch once to show the uppercase keyboard for typing a capital

letter.

Touch twice to enable the Caps Lock mode.



Touch to change back to the lowercase keyboard.

Touch to show the keyboard for typing numbers, punctuation

marks, and symbols other than the period.

Touch to switch back to the alphabet keyboard.

Touch to delete a typed character, symbol, or a space.

Touch and hold to quickly delete typed text.

Touch to search the input word.

Keyboard settings:

4 5

PMP5070 EN - 9

USER MANUAL

Prestigio MultiPad

PMP5070

Touch the Menu button →Settings →Language & keyboard→

Android keyboard.

To enable a setting, touch the setting option to select the check box

; to disable a setting, touch the setting option to clear the check

box .

Available keyboard settings:

Sound on keypress

The device beeps when you touch a key.

NOTE: To activate this item, you also need to

select Settings→Sound & display→Audible

selection.

Auto-capitalization The first letter of the word in a new sentence is

capitalized.

Quick fixes Mark and correct wrong spellings and typos.

Show suggestions Show suggested words as you type.

Auto-complete If this mode is enabled, touching the spacebar

or a punctuation key automatically inserts a

highlighted word suggestion.

Creating personal dictionary:

The keyboard uses the default dictionary to display suggested words as

you type. You can create a personal dictionary to include words not found

in the main dictionary. The keyboard will also use the words that are

added to your personal dictionary to make word suggestions.

To add a word to the dictionary:

Touch the Menu button →Settings →Language & keyboard→

User dictionary.

Touch the Menu button →Add.

Type a desired word into the Add to dictionary text field.

EN – 10 PMP5070

USER MANUAL

Prestigio MultiPad

PMP5070

Touch OK.

To edit a word in the dictionary:

Touch the Menu button →Settings →Language & keyboard→

User dictionary.

Touch a desired word.

Touch Edit.

Edit the spelling of the word in the Edit word text field.

Touch OK.

To delete a word from the dictionary:

Touch the Menu button →Settings →Language & keyboard→

User dictionary.

Touch a desired word.

Touch Delete.

10. Settings

To check storage spaces:

Touch Menu button →Settings →SD card & phone storage. The

screen displays the total and available space on the device and on the

micro SD card.

To erase unwanted application data and to free storage space:

Touch Menu button →Settings →Applications→Manage

applications.

From the Manage applications list, touch the application whose

cache or data you want to remove.

In the Application info screen, touch Clear data under Storage to

erase unwanted application data; touch Clear cache under Cache to

erase unwanted cache.

To format the microSD card:

Autres manuels pour MultiPad PMP5070

Table des matières

Autres manuels Prestigio Comprimé

Prestigio

Prestigio Multipad 4 Quantum 10.1 Manuel utilisateur

Prestigio

Prestigio MUZE 3708 3G Manuel utilisateur

Prestigio

Prestigio MultiPad ES-PMT5877C DUO Manuel utilisateur

Prestigio

Prestigio MultiPad 2 PRO DUO 7.0 Manuel utilisateur

Prestigio

Prestigio PMP5780D_DUO Manuel utilisateur

Prestigio

Prestigio multipad Manuel utilisateur

Prestigio

Prestigio MultiPad MUZE PMT5008 3G Manuel utilisateur

Prestigio

Prestigio PMP7170B3G DUO Manuel d'utilisation

Prestigio

Prestigio Libretto PER3362B Manuel utilisateur

Prestigio

Prestigio MultiPad PMP5785C3G QUAD Manuel utilisateur

Prestigio

Prestigio PMP7280C3G-Duo Manuel utilisateur

Prestigio

Prestigio MULTIPAD WIZE 3027 Manuel utilisateur

Prestigio

Prestigio MultiPad 7.0 PRIME+ Manuel utilisateur

Prestigio

Prestigio MultiPad PMT3037 3G Manuel utilisateur

Prestigio

Prestigio MULTIPAD WIZE 34084G Manuel utilisateur

Prestigio

Prestigio multipad Manuel utilisateur

Prestigio

Prestigio MultiPad Visconte Quad PMP880TD Manuel utilisateur

Prestigio

Prestigio MultiPad 7.0 Ultra Manuel utilisateur

Prestigio

Prestigio MultiPad PMT7008 4G Manuel utilisateur

Prestigio

Prestigio MultiPad 4 Quantum 9.7 Manuel utilisateur

Prestigio

Prestigio MultiPad PMP5597D DUO Manuel utilisateur

Prestigio

Prestigio PMP5197D-Ultra Manuel utilisateur

Prestigio

Prestigio MultiPad PMT-3377 Manuel utilisateur

Prestigio

Prestigio MultiPad 4 Quantum Manuel utilisateur

Manuels Comprimé populaires d'autres marques

Laser

Laser MID-1060 Guide de l'utilisateur

MUNBYN

MUNBYN IRT09J Guide de démarrage rapide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manuel utilisateur

Dell

Dell Latitude ST Manuel du propriétaire

Lenovo

Lenovo IdeaTab S6000L Manuel du propriétaire

Venturer

Venturer WT9L11 Manuel utilisateur

EDUGEAR

EDUGEAR UnoBook Manuel utilisateur

Philips

Philips PI3210G/58 Manuel utilisateur

ADLINK Technology

ADLINK Technology IMT-BT Manuel utilisateur

TwinMOS

TwinMOS TwinTAB-T102D1 Manuel utilisateur

Archos

Archos 9.7 xenon Manuel utilisateur

Getac

Getac E100 Manuel utilisateur

HANNspree

HANNspree HANNspad SN70T3 Manuel utilisateur

Philips

Philips PI3105W2/55 Manuel utilisateur

LG LG-V935 Manuel utilisateur

Zeki

Zeki TBDB763B Manuel utilisateur

Ricoh

Ricoh eQuill Manuel utilisateur

DT Research

DT Research DT365CT Instructions de montage
