PP3DP-2013-V4
UP! 3D Printer User Manual 1
Legal Notice
The information in this document is subject to change without notice.
DELTA MICRO FACTORY CO. MAKES NO WARRANTY OF ANY KIND WITH REGARD
TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Delta Micro
Factory Co. shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this
Material. Changes or modifications to the system not expressly approved by Delta
Micro Factory Co., the party responsible for compliance, could void the user’s
authority for use. This document is protected by copyright. All rights reserved. Its use,
disclosure, and possession are restricted by an agreement with Delta Micro Factory
Co. per software copyright. No part of this document may be photocopied,
reproduced or translated into another language without the prior written consent of
Delta Micro Factory Co.
© Copyright 2013Delta Micro Factory Corporation. All rights reserved.
UP! 3D Printer User Manual 2
1. INTRODUCTION..................................................................................................................................................................3
1.1 HOW TO USE THIS MANUAL ................................................................................................................................................... 3
1.2 PRECAUTIONS ........................................................................................................................................................................... 3
1.2.1 Safety............................................................................................................................................................................... 3
1.2.2 Protection ..................................................................................................................................................................... 4
2. OVERVIEW............................................................................................................................................................................5
2.1 APPEARANCE ............................................................................................................................................................................ 5
2.2 SPECIFICATIONS ........................................................................................................................................................................ 8
2.2.1 Printer Physical Characteristics ....................................................................................................................... 8
2.2.2 Specifications .............................................................................................................................................................. 8
2.2.3 Environmental specifications............................................................................................................................... 8
3. OPERATION.......................................................................................................................................................................... 9
3.1 PREPARATION ........................................................................................................................................................................... 9
3.1.1 Installing the printer................................................................................................................................................. 9
3.1.2 Installing the software ......................................................................................................................................... 12
3.1.3 Installing drivers...................................................................................................................................................... 12
3.2 USING THE BASIC FUNCTIONS............................................................................................................................................. 14
3.2.1 Start the program ................................................................................................................................................. 14
3.2.2 Loading a 3D model.............................................................................................................................................. 14
3.2.3 View Options ............................................................................................................................................................. 17
3.2.4 Model transformations ....................................................................................................................................... 18
3.2.5 Placing models onto the build platform ...................................................................................................... 20
3.3 GETTING READY TO PRINT................................................................................................................................................... 21
3.3.1 Initializing the Printer............................................................................................................................................ 21
3.3.2 Calibrating the Level of Platform.................................................................................................................... 22
3.3.3 Calibrating the Nozzle Height........................................................................................................................... 24
3.3.4 Other Maintenance Options ............................................................................................................................. 28
3.3.5 Preparing the Platform....................................................................................................................................... 30
3.3.6 Print Setup Options............................................................................................................................................... 31
4. PRINTING...........................................................................................................................................................................37
5. MODEL REMOVAL..........................................................................................................................................................40
REMOVING SUPPORT MATERIAL................................................................................................................................................ 40
6. MAINTENANCE................................................................................................................................................................ 42
CHANGING THE MATERIAL........................................................................................................................................................... 42
VERTICAL CALIBRATION................................................................................................................................................................ 42
CLEANING THE NOZZLE................................................................................................................................................................. 44
REMOVING /CHANGING THE NOZZLE ...................................................................................................................................... 45
CLEANING THE PLATFORM ........................................................................................................................................................... 46
LUBRICATION OF BEARINGS ......................................................................................................................................................... 46
SPARE PARTS.................................................................................................................................................................................. 46
7. TIPS & TRICKS................................................................................................................................................................. 47
8. TROUBLESHOOTING...................................................................................................................................................... 49
SOLUTION FOR "USB.DLL NOT FOUND"PROBLEM ................................................................................................................. 49
UP! 3D Printer User Manual 3
1. Introduction
1.1 How to use this manual
This User Manual is divided into four sections which cover the Introduction, Overview,
Operation, and Troubleshooting. Please study this manual carefully before installation,
and use the printer according to these instructions. Keep this manual handy and
refer to it when necessary.
1.2 Precautions
Please read this section carefully before using the printer.
1.2.1 Safety
The printer can only be used with the power adapters supplied by this company,
or the product may be damaged, with a risk of fire.
To avoid burning, or model deformation, do not touch the model, nozzle, or the
platform by hand, or any other part of the body, while the printer is working or
immediately after it has finished printing.
Protective glasses should always be worn when removing support material,
especially PLA.
The brown sections of the currently supplied gloves melt at around 200 degrees,
therefore please do not hold the extruder block with the gloves.
There is a slight smell from ABS when it is being extruded. The smell is, however,
not too unpleasant. A well ventilated room is recommended by most people to
be safe, however when printing keep the printer away from any draughts as this
can affect the warping of ABS prints. When ABS is burnt is releases toxic fumes.
UP! 3D Printer User Manual 4
The following classifications are used in this manual.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, may result in serious injury.
Gloves: When performing certain maintenance procedures, the
machine may be hot and gloves are required to avoid burns.
Safety Glasses: Wear safety glasses to avoid injury to your eyes.
1.2.2 Protection
The printer must not be exposed to water or rain, or damage may occur.
Do not shut down the UP! System or pull out the USB cable when loading a digital
model, or the model data may be lost.
When using the “Extrude” function, keep at least 50mm between the nozzle and
the platform. If too close, the nozzle may get blocked.
The printer is designed to work properly at an ambient temperature of between
15°C and 30°C and humidity of between 20% and 50%;Operating outside these
limits may result in low quality models.
UP! 3D Printer User Manual 5
2. Overview
The UP! Printer is designed with ultimate portability and simplicity in mind. The
system and software allow you to print great models with only a few keystrokes,
even if you have never used a 3D printer before. The system uses a nozzle to
deposit molten plastic, so printed parts are strong and durable Congratulations on
purchasing an UP! Printer.
2.1 Appearance
Figure 1.Front view of printer
(1) Pedestal (2) Platform (3) Nozzle
(4) Extruder Guard (5) Filament Tube (6) Roller Shaft
(7) Material Filament (8) Pilot Lamp (9) Initialize Button
(10) Platform Level Calibration Device (11) Nozzle Height Detect Device
(12) 3.5mm cable
⑸
⑹
⑺
⑻
⑼
⑴
⑿
⑵
⑾
⑽
⑶
⑷
UP! 3D Printer User Manual 6
Figure 2. Accessories
USB cable Power adapter (19 V) Filament tube
Screws Cell board 3.5mm Cable
Platform Level Calibration Device Nozzle Height Detect Device
Figure3. Tool kit
Pen Knives Tweezers Hex wrench Shovel
Pliers Gloves Nozzle wrench Clip
⑤
UP! 3D Printer User Manual 7
Figure 4.Axis
Figure 5. Back view of printer
Extruder axis
Z axis
Platform axis
Power on/off Button
Power Interface
USB Interface
3.5mm Interface
UP! 3D Printer User Manual 8
2.2 Specifications
2.2.1Printer Physical Characteristics
Printing Material
ABS or PLA
Material Color
White default (5 other colors)
Layer Thickness
0.2–0.4 or 0.15 －0.4mm,
depending on model
Print Speed
10－100 cm3/h
Print Size
140× 140× 135mm
Printer Weight
5 KG (11 lb)
Printer Size
245 × 260 × 350 mm
2.2.2 Specifications
Power Requirements
100-240VAC, 50-60Hz, 200W
Model Support
Auto-generated support
Input Format
STL
Workstation compatibility
Windows XP/Vista/7/8; Mac
2.2.3 Environmental specifications
Ambient temperature
15°C～30°C
Relative humidity
20%～50%
UP! 3D Printer User Manual 9
3. Operation
3.1 Preparation
3.1.1Installation the printer
Assemble the two parts first following the diagram above.
Perfboard:Fix the perfboard on the platform with 8 springs around platform.
Roller shaft: Insert the block of the roller shaft into the slot between a and b, then
press down and fix.
