Powerfix Profi 96475 Manuel utilisateur
IAN 96475
DIY VICE
Operation and Safety Notes
RUUVIPENKKI
Käyttö- ja turvallisuusohjeet
UNIVERSALSKRUVSTÄD
Bruksanvisning och säkerhetsanvisningar
UNIVERSAL-SKRUESTIK
Betjenings- og sikkerhetshenvisninger
UNIVERSAL-SCHRAUBSTOCK
Bedienungs- und Sicherheitshinweise
DIY VICE
ÉTAU UNIVERSEL
Instructions d‘utilisation et consignes de sécurité
UNIVERSELE BANKSCHROEf
Bedienings- en veiligheidsinstructies
GB/IE Operation and Safety Notes Page 4
FI Käyttö- ja turvallisuusohjeet Sivu 9
SE Bruksanvisning och säkerhetsanvisningar Sidan 14
DK Brugs- og sikkerhedsanvisninger Side 19
FR/BE Instructions d‘utilisation et consignes de sécurité Page 24
NL/BE Bedienings- en veiligheidsinstructies Pagina 29
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 34
3
8
9
10
11
13
1
2
3
5
4
6
7
12
4 GB/IE
Introduction
Intended Use .................................................................... Page 5
Description of parts and features.................................... Page 5
Technical data.................................................................. Page 6
Included items .................................................................. Page 6
Safety advice............................................................ Page 6
Fixing in place.......................................................... Page 7
Use
Clamping and releasing a workpiece ............................ Page 7
Mounting the tube attachment ........................................ Page 8
Cleaning and care................................................. Page 8
Disposal......................................................................... Page 8
5GB/IE
DIY vice
Introduction
The instructions for use are to be considered as part of the
product. They contain important information concerning
safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety information and
instructions for use. The product must only be used as described
and for the stated fields of application. If you pass the product on
to third parties, please give them all of the documentation as well.
Intended Use
The product is intended for clamping small, light workpieces made
of wood or metal, e.g. for model-making, to hold them still while
further work is performed on them. Other uses or changes to the
product are considered to be contrary to the intended use and
may harbour risks of injury and damage. The manufacturer does
not accept any liability for injury or damage resulting from use of
this product contrary to its intended use. The product is not intended
to be used for commercial purposes.
Description of parts and features
1Jaw protectors
2Jaws with V-grooves
3Hexagonal socket head screw
4Hexagonal socket head screw
5Ball joint
6Ball joint tommy bar
7Clamping screw
8Hexagonal socket head screw
9Vice jaws tommy bar
10 Spindle
11 Vice base
6 GB/IE
12 Hexagon socket screw key
13 Tube attachment
Technical data
Maximum jaw opening width: approx. 50mm
Length of jaws: approx. 78mm
Maximum bench top thickness: approx. 50mm
Weight: approx. 865g
Dimensions height: approx. 15.5 x 7.4 x 25.5cm
(l x w x h)
Height from top of bench: approx. 15.5cm
Tube attachment: ø approx. 38-43 mm
Max. tube weight: 2 kg
Max. tube length: 30cm
Included items
1 Diy vice
1 Hexagon socket screw key
1 Tube attachment
1 Operating instructions
Safety advice
KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN A
SAFE PLACE FOR FUTURE REFERENCE.
CAUTION! DANGER OF INJURY! When working with
hand-held electrical power tools, you can be seriously injured
if the clamped workpiece slips or becomes loose. Never work
on a clamped workpiece using hand-held electrical power tools.
Check the product before each use for any damage. Do not
use the product if you discover it is damaged in any way.
Check all threaded connections on the product for proper
seating before each use.
7GB/IE
Use the product on a stable, flat, undamaged surface (e.g.
a workbench).
Place circular workpieces in the vertical or horizontal V-groove
and clamp them tightly in place. By doing this you will prevent
the workpiece from slipping.
The vice is an aluminium injection casting and therefore is only
impact resistant to limited extent.
Do not use extension tubes on the tommy bars. There is the
danger of overloading (fracturing) the spindle.
Wear safety gloves and glasses.
Fixing in place
Attach the vice on to a smooth, flat surface.
To do this turn the clamping screw 7anticlockwise until the
clamp opening has widened enough.
Push the vice on the supporting surface (table-top, work-
bench) and fix it in place on the supporting surface by turning
the clamping screw 7.
Use
Clamping and releasing a workpiece
1. Turn the vice base 11 into the desired position and fix the ball
joint 5in position with the ball joint tommy bar 6.
Note: Turn the vice base 11 so that the ends of the jaws 2
project out over the supporting surface. This allows you to
clamp even long workpieces (in the limiting case with one end
on the floor) to work on their ends.
2. Turn the vice jaws tommy bar 9anticlockwise to open the
jaws 2.
3. Place the workpiece between the jaws 2and clamp it by
turning the vice jaws tommy bar 9clockwise. Ensure that the
workpiece is tightly clamped.
You can now work on the workpiece.
After completing work on the workpiece, release it by turning
the vice jaws tommy bar 9anticlockwise.
8 GB/IE
Mounting the tube attachment
The tube attachment is intended for clamping tubes with a diameter
of 38-43mm.
1. Release the hexagonal socket head screw 3at the end of
the spindle using the supplied hexagon socket screw key 12 .
2. Turn the vice jaws tommy bar 9anticlockwise until the
spindle 10 is turned out of the rear jaw 2.
3. Using the supplied hexagon socket screw key 12 , release the
hexagonal socket head screw 8on the underside of the vice
base 11 and remove the spindle 10 from the vice.
4. Now that the hexagonal socket head screw 4is accessible,
remove it and take the vice base off the ball joint 5.
5. Place the tube attachment 13 on to the ball joint 5and
fasten it in place with the hexagonal socket head screw 4.
6. Turn and tilt the ball joint 5to achieve the right position.
Cleaning and care
Clean the product with a dry, fluff-free cloth.
Never use aggressive or corrosive cleaning agents, as they
may damage the product.
Disposal
The packaging is made entirely of recyclable materials,
which you may dispose of at local recycling facilities.
Contact your local refuse disposal authority fo r more details of
how to dispose of your worn-out product.
9FI
Johdanto
Tarkoituksenmukainen käyttö........................................... Sivu 10
Osien kuvaus.................................................................... Sivu 10
Tekniset tiedot................................................................... Sivu 11
Toimitukseen kuuluu.......................................................... Sivu 11
Turvallisuusohjeet................................................. Sivu 11
Asennus......................................................................... Sivu 12
Käyttö
Työkappaleen kiinnittäminen/irrottaminen.................... Sivu 12
Putken pidikkeen asennus................................................ Sivu 13
Puhdistus ja hoito.................................................. Sivu 13
Jätehuolto ................................................................... Sivu 13
10 FI
Ruuvipenkki
Johdanto
Käyttöohje on osa tätä tuotetta. Se sisältää tärkeitä
turvallisuusohjeita sekä käyttöä ja hävitystä koskevia
ohjeita. Tutustu ennen tuotteen käyttöä huolellisesti
kaikkiin käyttö- ja turvallisuusohjeisiin. Käytä tuotetta vain kuvatulla
tavalla ja ilmoitetulla käyttöalalla. Anna kaikki ohjeet mukaan, jos
luovutat tuotteen edelleen.
Tarkoituksenmukainen käyttö
Tuote on tarkoitettu pienempien ja kevyiden puisten tai metallisten
työkappaleiden esim. pienoismallien kiinnittämiseen paikoilleen,
jotta niitä voitaisiin tämän jälkeen työstää. Tuotteen käyttö tai
sen muuttaminen muuhun kuin tässä mainittuun tarkoitukseen voi
aiheuttaa loukkaantumis- ja vaurioitumisvaaran. Valmistaja ei vastaa
virheellisestä käytöstä johtuneista vahingoista. Tuote ei ole tarkoitettu
ammattimaiseen käyttöön.
Osien kuvaus
1Kiinnitysleukojen suojapäällykset
2Kiinnitysleuat V-urilla
3Kuusiokoloruuvi
4Kuusiokoloruuvi
5Pallonivel
6Pallonivelen kiinnitystanko
7Kiristysruuvi
8Kuusiokoloruuvi
9Kiinnitysleukojen kiinnitystanko
10 Kara
11 Ruuvipuristimen kiinnitin
12 Kuusiokoloavain
13 Putken pidike
