Powerfix Profi 282447 Manuel utilisateur

DIY VICE

IAN 282447

DIY VICE

Operation and Safety Notes

UNIVERSAL-SCHRAUBSTOCK

Bedienungs- und Sicherheitshinweise

UNIVERSAL-SKRUESTIK

Brugs- og sikkerhedsanvisninger

ÉTAU UNIVERSEL

Instructions d‘utilisation et consignes de sécurité

UNIVERSELE BANKSCHROEF

Bedienings- en veiligheidsinstructies

GB/IE/NI Operation and Safety Notes Page 5

DK Brugs- og sikkerhedsanvisninger Side 10

FR/BE Instructions d‘utilisation et consignes

de sécurité Page 15

NL/BE Bedienings- en veiligheidsinstructies Pagina 20

DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 25

5GB/IE/NI

Table of contents

Introduction................................................................ Page 6

Intended Use .................................................................... Page 6

Description of parts and features.................................... Page 6

Technical data.................................................................. Page 7

Included items .................................................................. Page 7

Safety advice............................................................ Page 7

Fixing in place.......................................................... Page 8

Use..................................................................................... Page 8

Clamping and releasing a workpiece ............................ Page 8

Mounting the tube attachment ........................................ Page 9

Cleaning and care................................................. Page 9

Disposal......................................................................... Page 9

6 GB/IE/NI

Introduction

Diy vice

Introduction

We congratulate you on the purchase of your new product. You

have chosen a high quality product. Familiarise yourself with the

product before using it for the ﬁrst time. In addition, please carefully

refer to the operating instructions and the safety advice below.

Only use the product as instructed and only for the indicated ﬁeld

of application. Keep these instructions in a safe place. If you pass

the product on to anyone else, please ensure that you also pass

on all the documentation with it.

Intended Use

The product is intended for clamping small, light workpieces made

of wood or metal, e.g. for model-making, to hold them still while

further work is performed on them. Other uses or changes to the

product are considered to be contrary to the intended use and

may harbour risks of injury and damage. The manufacturer does

not accept any liability for injury or damage resulting from use of

this product contrary to its intended use. The product is not intended

to be used for commercial purposes.

Description of parts and features

1Jaw protectors

2Jaws with V-grooves

3Hexagonal socket head screw

4Hexagonal socket head screw

5Ball joint

6Ball joint tommy bar

7Clamping screw

8Hexagonal socket head screw

9Vice jaws tommy bar

10 Spindle

11 Vice base

7GB/IE/NI

Introduction/Safety advice

12 Hexagon socket screw key

13 Tube attachment

Technical data

Maximum jaw opening width: approx. 50mm

Length of jaws: approx. 78mm

Maximum bench top thickness: approx. 50mm

Weight: approx. 865g

Dimensions height: approx. 14.6 x 7.8 x 26cm

(l x w x h)

Height from top of bench: approx. 15.5cm

Tube attachment: ø approx. 38-43mm

Max. tube weight: 2kg

Max. tube length: 30cm

Included items

1 Diy vice

1 Hexagon socket screw key

1 Tube attachment

1 Operating instructions

Safety advice

KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN A

SAFE PLACE FOR FUTURE REFERENCE.

CAUTION! DANGER OF INJURY! When working with

hand-held electrical power tools, you can be seriously injured

if the clamped workpiece slips or becomes loose. Never work

on a clamped workpiece using hand-held electrical power tools.

J Check the product before each use for any damage. Do not

use the product if you discover it is damaged in any way.

J Check all threaded connections on the product for proper

seating before each use.

8 GB/IE/NI

Safety advice/Fixing in place/ Use

J Use the product on a stable, ﬂat, undamaged surface (e.g.

a workbench).

J Place circular workpieces in the vertical or horizontal V-groove

and clamp them tightly in place. By doing this you will prevent

the workpiece from slipping.

J The vice is an aluminium injection casting and therefore is only

impact resistant to limited extent.

J Do not use extension tubes on the tommy bars. There is the

danger of overloading (fracturing) the spindle.

J Wear safety gloves and glasses.

Fixing in place

j Attach the vice on to a smooth, ﬂat surface.

j To do this turn the clamping screw 7anticlockwise until the

clamp opening has widened enough.

j Push the vice on the supporting surface (table-top, workbench)

and ﬁx it in place on the supporting surface by turning the

clamping screw 7.

Use

Clamping and releasing a workpiece

1. Turn the vice base 11 into the desired position and ﬁx the ball

joint 5in position with the ball joint tommy bar 6.

Note: Turn the vice base 11 so that the ends of the jaws 2

project out over the supporting surface. This allows you to

clamp even long workpieces (in the limiting case with one end

on the ﬂoor) to work on their ends.

2. Turn the vice jaws tommy bar 9anticlockwise to open the

jaws 2.

3. Place the workpiece between the jaws 2and clamp it by

turning the vice jaws tommy bar 9clockwise. Ensure that the

workpiece is tightly clamped.

j You can now work on the workpiece.

j After completing work on the workpiece, release it by turning

the vice jaws tommy bar 9anticlockwise.

9GB/IE/NI

Use/Cleaning and care/ Disposal

Mounting the tube attachment

The tube attachment is intended for clamping tubes with a diameter

of 38-43mm.

1. Release the hexagonal socket head screw 3at the end of

the spindle using the supplied hexagon socket screw key 12 .

2. Turn the vice jaws tommy bar 9anticlockwise until the

spindle 10 is turned out of the rear jaw 2.

3. Using the supplied hexagon socket screw key 12 , release the

hexagonal socket head screw 8on the underside of the vice

base 11 and remove the spindle 10 from the vice.

4. Now that the hexagonal socket head screw 4is accessible,

remove it and take the vice base oﬀ the ball joint 5.

5. Place the tube attachment 13 on to the ball joint 5and

fasten it in place with the hexagonal socket head screw 4.

6. Turn and tilt the ball joint 5to achieve the right position.

Cleaning and care

j Clean the product with a dry, ﬂuﬀ-free cloth.

j Never use aggressive or corrosive cleaning agents, as they

may damage the product.

Disposal

The packaging is made entirely of recyclable materials,

which you may dispose of at local recycling facilities.

Contact your local refuse disposal authority for more details of

how to dispose of your worn-out product.

10 DK

Indholdsfortegnelse

Indledning ....................................................................Side 11

Formålsbestemt anvendelse .............................................Side 11

Beskrivelse af delene ........................................................Side 11

Tekniske Data....................................................................Side 12

Leveringsomfang...............................................................Side 12

Sikkerhedshenvisninger..................................Side 12

Montering.....................................................................Side 13

Anvendelse..................................................................Side 13

Et værkstykke spændes fast/løsnes ................................Side 13

Rørholder monteres...........................................................Side 14

Rensning og pleje...................................................Side 14

Bortskaffelse..............................................................Side 14

11DK

Indledning

Universal-skruestik

Indledning

Hjerteligt tillykke med købet af deres nye produkt. Du har besluttet

dig for et produkt af høj kvalitet. Gør Dem fortrolig med apparatet

inden første ibrugtagning. Læs derfor den efterfølgende brugsvej-

ledning og sikkerhedsanvisningerne omhyggeligt. Brug kun pro-

duktet som beskrevet og kun til de angivne anvendelsesområder.

Denne vejledning bør opbevares. Hvis De giver produktet videre til

andre, skal alle dokumenter følge med.

Formålsbestemt anvendelse

Produktet er beregnet til indspænding af små lette værkstykker

af træ eller metal, f. eks. indenfor modelbygning, til efterfølgende

bearbejdelse. Anden anvendelse eller ændringer på produktet

gælder som ikke formålsbestemte og kan medføre fare for person-

skader eller andre skader. Producenten hæfter ikke for skader, der

er opstået ved anvendelse i strid med produktets bestemmelse.

Produktet må ikke anvendes til erhvervsmæssige formål.

Beskrivelse af delene

1Beskyttelseshætter til spændebakker

2Spændebakker med V-nut

3Unbrakoskrue

4Unbrakoskrue

5Kugleled

6Fastgørelsesspændepind til kugleleddet

7Klemskrue

8Unbrakoskrue

9Fastgørelsesspændepind til spændebakkerne

10 Spindel

11 Skruestikopsats

12 Unbrakonøgle

13 Rørholder
