Powerfix Profi PMDL 5 B1 Manuel utilisateur

IAN 273624

MULTI-PURPOSE DETECTOR PMDL 5 B1

MULTI-PURPOSE DETECTOR

Operating instructions

MULTIFUNKTIONS-

DETEKTOR

Bedienungsanleitung

MULTIFUNKCIÓS DETEKTOR

Használati utasítás

MULTIFUNKCIJSKI

DETEKTOR

Navodila za uporabo

MULTIFUNKČNÍ DETEKTOR

Návod k obsluze

MULTIFUNKČNÝ DETEKTOR

Návod na obsluhu

GB Operating instructions Page 1

HU Használati utasítás Oldal 13

SI Navodila za uporabo Stran 25

CZ Návod k obsluze Strana 37

SK Návod na obsluhu Strana 49

DE / AT / CH Bedienungsanleitung Seite 61

Before reading, unfold the page containing the illustrations and familiarise

yourself with all functions of the device.

Olvasás előtt kattintson az ábrát tartalmazó oldalra és végezetül ismerje meg a

készülék mindegyik funkcióját.

Pred branjem odprite stran s slikami in se nato seznanite z vsemi funkcijami

naprave.

Před čtením si otevřete stranu s obrázky a potom se seznamte se všemi funkcemi

přístroje.

Pred čítaním si odklopte stranu s obrázkami a potom sa oboznámte so všetkými

funkciami prístroja.

Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie

sich anschließend mit allen Funktionen des Gerätes vertraut.

- 1 -

CONTENT PAGE

Intended use 2

Safety instructions 2

Technical data 4

Description of the appliance 4

Items supplied 4

Unpacking 4

Inserting the battery 5

Measuring distances 5

Measuring areas 7

Measuring volumes 8

Locating concealed objects 8

Laser marking 10

Battery display 11

Cleaning and storage 11

Disposal 11

Warranty & Service 12

Importer 12

Read the operating instructions carefully before using the device for the first time and

preserve this booklet for later reference. Pass this manual on to whoever might acquire

the device at a future date.

MULTI-PURPOSE DETECTOR

PMDL 5 B1

Intended use

The Multi-Purpose Detector is designed for the locating of electrical cables, of

wood and metal objects, for the projecting of laser lines, for the measuring of

areas and volumes as well as for the measuring of distances. The appliance is

intended for domestic use only. Do not use it for commercial purposes.

A different or any other usage is regarded as unintended use and can lead

to damages and injuries. No liabity will be accepted for damage caused by

manipulation of the laser equipment, as well as of the ultrasound transmitter/

receiver, or through disregard of these safety instructions.

Safety instructions

Optimal and safe working with the Multi-Purpose Detector is only possible if

you read these operating and safety instructions completely and strictly fol-

low their instructions.

Risk of injury!

• Do not use the appliance at locations where there is a risk of fire or

explosion, e.g. close to inflammable liquids or gases.

• This appliance may be used by children aged 8 over and by persons

with reduced physical, sensory or mental capabilities or lack of experience

and knowledge, provided that they are under supervision or have been

told how to use of the appliance safely and are aware of the

potential risks. Children must not play with the appliance. Cleaning and

user maintenance tasks must not be carried out by children unless they

are supervised.

• Exercise caution with the holding pins. They are sharp and can cause

injuries.

Caution regarding damage to the appliance!

• Do not expose the appliance to rainfall. Do not use the appliance in

moist or wet environments.

• Do not place objects containing liquids, e. g. flower vases, on the appli-

ance.

• Do not place any open sources of fire, like candles, on the device.

- 2 -

This appliance contains a Class 2 laser. NEVER direct the laser beam at

people or animals. NEVER look directly into the laser. The laser can cause

serious eye damage.

• Do NOT direct the laser beam at strongly reflective material.

Reflected laser beams are also dangerous.

• Do NOT use the appliance to determine the alternating voltage level in

exposed or non-insulated power cables.

• Do NOT use the appliance as a substitute for a voltmeter.

Notes regarding inaccurate measurement results

The appliance does not always recognise all pipes and power cables.

The following conditions can contribute to inaccurate results:

– very thick walls

– weak battery

– deeply laid power cables or pipework

– shielded cables

– thick walls with thin pipes or power cables

– walls panelled with metal sheets

– very moist conditions

• This appliance is not suitable for detecting power cables in circuits,

– which are isolated from the mains power supply.

– through which direct current flows.

– which are used for computer or telecommunications systems.

• With this appliance pipework made of plastic or similar materials

cannot be detected, only pipework made of metal.

Interaction with batteries

• Leaking batteries can cause damage to the appliance. If you do not in-

tend to use the appliance for an extended period, remove the batteries.

• Should the batteries leak, wear protective gloves and clean the battery

compartment with a dry cloth.

• Keep batteries away from children. Children can put batteries into their

mouths and swallow them. Should a battery ever be swallowed, seek

medical attention IMMEDIATELY.

LASER

- 3 -

Technical data

Distance measurement by means of Ultrasound

Locating of: power cables, metal, wood

Laser class: 2

Max. output power (P.max): <1 mW

Wave length (λ): 650 nm

according EN60825-1:2014

Power supply: 9 V block battery

Description of the appliance

1Measurement point

2Display

3Material switch (STUD/AC WIRE/METAL)

4Button M (Memory)

5Button – Holding pin

6Button – READ

7Button – MODE

8Spirit level

9Laser beam exit opening

0Ultrasound sender/receiver

qFunction switch (LASER/DETECTOR/DISTANCE)

wButton – RM (Read Memory)

eButton – Holding pin

rButton +/=

tBattery compartment

zButton – PUSH

Items supplied

• Multi-Purpose Detector

• 9 V block battery

• Operating instructions

Unpacking

Take the Multi-Purpose Detector from its packaging. Remove all transport re-

straints and packaging materials. Remove the protective foil from the display 2.

- 4 -

Inserting the battery

1. Open the battery compartment ton the rear side of the Multi-Purpose

Detector.

2. Place the 9V block battery onto the contacts. Pay heed to the correct

polarity.

3. Lay the tape for removal of the battery underneath the 9 V block battery

and press it into the battery compartment t.

Important!

Ensure that the wires are not trapped in any way.

This would lead to irreparable damage to the appliance.

4. Close the battery compartment t. The battery compartment lid must close

with an audible click.

Measuring distances

1. Slide the function switch qto „DISTANCE“. The display 2switches itself on.

To switch between the metric and the Anglo-American units of measurement,

press and hold the button MODE 7. Then press the button READ 6and

release both buttons simultaneously. When you release the buttons, the mea-

surement units change.

Note:

Measurements start at the measurement point 1!

Should the measurement lie outside the measurement range, „Err“ or an

illogical number appear in the display. The measurement range lies between

0,6 m (2’) and 16 m (53’).

2. Hold the appliance upright towards the wall to which you wish to measure

the distance. The ultrasound sender/receiver 0must be at a right-angle

to the wall. For this, use the spirit level: The bubble in the glass 8must

stand between the marking lines (see Fig. 1).

3. Press the button READ 6. The distance measured appears in the display 2.

When you hold the button READ 6pressed down and slowly move the

appliance over the surface to be measured, the appliance continually

measures the distances. These are shown on the display 2.

- 5 -

Take note of the following illustrations:

Fig. 1 Fig. 2

The further you are from the wall, the wider is the area (a) that the Multi-Purpose

Detector must measure by ultrasound (Fig. 2). Therefore take care that the

Multi-Purpose Detector is always directed at a right angle towards a level

surface (Fig. 1 and 3). Ensure that there are no objects positioned within the

measurement area.

False!

(Fig. 3)

The display illumination glows during the measurement. If a button is not pressed

within ca. 15 seconds, the illumination extinguishes. After a further ca. 15 se-

conds the diplay itself switches off. Press the button READ 6, to reactivate the

display and the illumination.

Note:

Inaccurate measurements can also occur through a weak battery.

If the battery is too weak, the battery symbol appears in the display.

- 6 -

Adding distances together

You can add the measured distances together:

1. Measure the first distance as described.

2. Press the button +/= r. In the display 2, „+“ appears and the distance

measured carries itself over to the lower line.

3. Measure the next distance. The newly measured distance is shown in the

upper line.

4. Once again, press the button +/= r. The new measurement is added

to the old measurement in the lower line.

5. Repeat steps 2 to 4 to add further measurements.

6. When you wish to leave the addition mode, press the button MODE 7.

All values are erased.

Measuring areas

1. Slide the function switch qto „DISTANCE“.

The display 2switches itself on.

2. Press the button MODE 7once. In the display 2flashes „L“ (Length).

3. Press the button READ 6, to measure the length. In the upper line

the measured length appears and „W“ (Width) starts to flash.

4. Press the button READ 6to measure the width. The measured width

appears on the upper line and the result of the area calculation in the

lower line.

Adding areas together

1. Measure an area as described in the section „Measuring areas“.

2. Press the button M 4. „M+“ appears in the display 2. The area measured

is now saved.

3. Press the button MODE 7. The appliance is now ready for the second

measurement.

4. Measure the next area.

5. Press the button +/= r. A „+“ appears in the display 2.

6. Press the button RM w. The result of the first measurement is shown in

the lower line.

7. Press the button +/= r. Both measurements are added together and

the result is shown in the lower line.

8. Repeat the steps 2 to 7 to add in further measurement values.

9. When you wish to leave the addition mode, press the button MODE 7.

All values are erased.

- 7 -

Autres manuels pour PMDL 5 B1

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Powerfix Profi Capteur de sécurité

Powerfix Profi

Powerfix Profi HG00384B Manuel utilisateur

Powerfix Profi

Powerfix Profi 288019 Manuel utilisateur

Powerfix Profi

Powerfix Profi KH 2927-2 Manuel utilisateur

Powerfix Profi

Powerfix Profi IAN 40111 Manuel utilisateur

Powerfix Profi

Powerfix Profi 97003 Manuel utilisateur

Powerfix Profi

Powerfix Profi PMDL 5 B1 Manuel utilisateur

Powerfix Profi

Powerfix Profi PMDL 5 B1 Manuel utilisateur

Powerfix Profi

Powerfix Profi Z31385 Manuel utilisateur

Powerfix Profi

Powerfix Profi 40111 Manuel utilisateur

Powerfix Profi

Powerfix Profi 298736 Manuel utilisateur

Powerfix Profi

Powerfix Profi KH 2927-2 Manuel utilisateur

Powerfix Profi

Powerfix Profi 91252 Manuel utilisateur

Powerfix Profi

Powerfix Profi 271367 Manuel utilisateur

Powerfix Profi

Powerfix Profi PMDL 5 B1 Manuel utilisateur

Powerfix Profi

Powerfix Profi Z31385 Manuel utilisateur

Powerfix Profi

Powerfix Profi 288019 Manuel utilisateur

Powerfix Profi

Powerfix Profi Z31712A/C Manuel utilisateur

Powerfix Profi

Powerfix Profi KH 3236 Manuel utilisateur

Powerfix Profi

Powerfix Profi 278296 Manuel utilisateur

Powerfix Profi

Powerfix Profi 77287 Manuel utilisateur

Powerfix Profi

Powerfix Profi 288019 Manuel utilisateur

Powerfix Profi

Powerfix Profi 273599 Manuel utilisateur

Powerfix Profi

Powerfix Profi 107555 Manuel utilisateur

Powerfix Profi

Powerfix Profi IAN 40111 Manuel utilisateur

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur
