Porsche 924 Mode d’emploi
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
01
Illustration
001-00
Restrictions UPD
248
12:06
Remark
PET
Page: 001 KAT 9
accessories
1 477 011 033 scissors type jack 1
2 944 721 027 05 tool bag
with contents
comprising:
tool bag
angular screw driver
1
1
1
3 477 012 233 spark plug wrench
rim wrench
operating rod
for
rim wrench
double-end spanner
10 X 13
handle
insert
for
cross-recess screw
and
slotted screw
universal pliers
1
1
1
1
1
1
1
- 928 361 311 00 hook
for
cover
wheel nut
1
use also:
4 996 721 151 00 towing lug 1
(4) 928 722 101 05 towing lug 1 M058
- 944 721 101 00 key
for
emergency operation
lifting roof
1
- 900 029 010 40 plastic nut
for
emergency operation
lifting roof
2
et_bt1.frm
PET
Model
924S Year
1988 23.01.2010
MG
Pos Part Number Description Qty Model
Page: 001
0SG
01 Illustration
001-05 Restrictions UPD
248 12:06
Remark
KAT 9
stickers
- 477 000 257 G sticker
tyre pressure
185/70 - HR 14
1
- 477 000 257 L sticker
tyre pressure
195/65 - VR 15
(AUS) 1
- 477 000 260 sticker
tyre pressure
205/55 - VR 16
(AUS) 1
- 937 701 127 00 sticker
tyre pressure 1
- 944 006 113 03 sticker
engine specifications (S) 1
et_text.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
02
Illustration
002-00
Restrictions UPD
248
12:07
Remark
PET
Page: 001 KAT 9
accessories
1 928 361 047 03 wheel nut
lockable
1 set
1
1A 965 361 167 00 cap 1
1B 928 361 306 03 wheel nut
lockable without lock
4
snow chains
2 911 361 909 00 snow chains
1 set
for
tyre
195/65 R 15
1
vertical seat adjustment
3 911 521 493 00 spacer
13 MM
X
4 900 067 089 02 pan-head screw
M 6 X 25
for
13 MM
elevation
X
(4) N 014 749 2 pan-head screw
M 6 X 40
for
26 MM
elevation
X
- 477 821 161 A mud flap /L 1
- 477 821 162 A mud flap /R 1
- N 010 264 4 hexagon-head bolt
M 5 X 20
6
- N 011 692 3 washer 6
- N 012 005 3 lock ring
B 5
6
- N 011 005 14 hexagon nut
M 5
6
trailer coupling
5 477 800 805 D trailer coupling
installation set
complete
1
et_bt1.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
02
Illustration
002-00
Restrictions UPD
248
12:07
Remark
PET
Page: 002 KAT 9
Pos Part Number Description Qty ModelRemark
(5) 477 800 805 E trailer coupling
installation set
complete
1 M058
- 928 006 901 00 sticker
drawbar load
1
- 111 919 209 A indicator light 1
- 900 631 132 90 bulb
12 V, 1,2 W
1
- 431 953 231 relay 1
et_bt2.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
02
Illustration
002-06
Restrictions UPD
248
12:07
Remark
PET
Page: 001 KAT 9
roof transport system
1 944 801 005 00 main support 1
2 928 801 061 02 retaining strip
1 set
1
2A 928 801 903 02 rubber support for skis X
2B 928 801 193 02 retaining strap X
3 928 801 063 02 ski box /L 1
(3) 928 801 064 02 ski box /R 1
5 928 801 081 02 roof luggage rack set 1
6 999 119 012 07 pan-head screw 4
8 928 801 011 02 cylinder lock
with keys
only for replacement
state lock number
1
9 477 091 145 protection cap 2
10 477 091 151 A protective rubber /L 1
(10) 477 091 152 A protective rubber /R 1
11 928 801 267 02 rubber plate
front
2
12 928 801 111 02 protection cap 4
13 928 801 107 02 lid 2
14 944 801 901 01 parts kit
comprising:
bolt
screw
lock
X
1
1
2
15 944 801 901 00 parts kit
comprising:
tension shackle
desk pad
screw
washer
key
X
2
2
2
2
1
et_bt1.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
02
Illustration
002-07
Restrictions UPD
248
12:07
Remark
PET
Page: 001 KAT 9
roof transport system M 388
1 928 801 019 02 set of surf board supports 1
2 928 801 017 02 set - canoe carrier 1
3 928 801 085 02 ladder support mandrel X
4 928 801 093 02 set - bike carrier
racing bike
1
5 928 801 095 02 set - bike carrier
standard bike
1
6 928 801 079 02 safety rope 1
7 928 801 097 02 support for bicycle 1
et_bt1.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
02
Illustration
002-10
Restrictions UPD
248
12:07
Remark
PET
Page: 001 KAT 9
accessories
1 477 863 539 luggage net 1
2 000 043 002 00 car basket
foldable
1
3 944 522 051 01 child car seat
up to 4 years
1
4 928 522 050 00 child car seat
older than 4 years
only together with
child car seat cushion
1
5 944 522 159 00 child car seat cushion /L 1
4CR black
for
back seat
6 944 522 160 00 child car seat cushion /R 1
4CR black
for
back seat
et_bt1.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
03
Illustration
003-00
Restrictions UPD
248
12:07
Remark
PET
Page: 001 KAT 9
radio
accessories
(1) > 911 645 139 00 radio
TORONTO SQR 45
w/o motorist radio information
1
(1) > 911 645 157 00 radio
HAMBURG SQM 24
1
(1) > 911 645 158 00 radio
BOSTON SQM 23
1
(1) > 911 645 168 00 radio
LUDWIGSBURG SQM 26
1
(1) > 911 645 159 01 radio
BREMEN SQR 46
1
(1) > 911 645 139 02 radio
TORONTO SQR 46
1
2 911 645 173 02 retaining frame 1
3 477 867 081 loudspeaker grille /V 2
01C black
4RB brown
4 944 645 451 00 loudspeaker /V 2
(4) 944 645 461 01 loudspeaker /H 2
5 900 145 041 07 tapping screw
B 3,5 X 16
/V 8
(5) N 013 962 2 tapping screw
B 3,9 X 16
/H 8
6 900 151 028 02 washer /H 8
7 477 867 373 bush /V 8
(7) 477 035 375 bush /H 8
8 944 645 015 00 water protection /V 2
9 477 035 999 gasket /H 2
10 944 645 053 00 fader 1
11 477 035 463 A rosette 1
12 944 612 145 00 wiring harness 1
(13) 944 615 103 00 switch unit 1
et_bt1.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
03
Illustration
003-00
Restrictions UPD
248
12:07
Remark
PET
Page: 002 KAT 9
Pos Part Number Description Qty ModelRemark
14 944 645 101 00 antenna
manually
1
15 > 944 645 911 00 automatic antenna 1
16 944 645 913 00 antenna rod
for
automatic antenna
1
et_bt2.frm
Model
924S
Year
1988
23.01.2010
MG
Pos Part Number Description Qty Model
0
SG
04
Illustration
004-00
Restrictions UPD
248
12:08
Remark
PET
Page: 001 KAT 9
lacquers
basic materials
- 911 096 050 00 polyester filler
1 KG
GLASSIT-NON-FERRO 839-10
X
- 911 096 051 00 hardener
30 GR
GLASSIT 948-36
red
X
- 911 096 052 00 primer filler
1 LTR
GLASSOFIX 238-150
X
- 911 096 053 00 hardener
500 ML
GLASSOFIX 352-228
X
- 911 096 054 00 primer filler
1 LTR
GLASSODUR 285-100
white
X
- 911 096 055 00 hardener
500 ML
GLASSODUR 929-28/1
X
- 911 096 056 00 wash primer
2 LTR
GLASSOFIX 2K 934-200
X
- 911 096 057 00 hardener
1 LTR
GLASSOFIX 934-100
X
- 911 096 058 00 polyurethane plastic putty
1 KG
GLASSODUR 995-20
X
- 911 096 059 00 hardener
1 KG
GLASSODUR 929-13
X
- 911 096 060 00 thinner
1 LTR
GLASSODUR 352-91
X
- 911 096 061 00 hardener
500 ML
GLASSODUR 929-73
X
- 911 096 062 00 additional lacquer
1 LTR
GLASSODUR 521-111
X
et_bt1.frm
