LEARN MORE

M55™

VOLUME BUTTON

• Volumepresets (1 tap per level change)

INDICATOR LIGHT (LED)

• Charging(solid red until charged)

• Verylowbattery(3 red ﬂashes at powering on)

• Pairingmode(repeating red/white ﬂashes)

MICRO USB CHARGING PORT

• UsewiththeACwallcharger

1 hour before ﬁrst use

2 hours (full charge)

• Donotuseheadsetwhilecharging

TAKE A GOOD LOOK

CALL BUTTON

• Takeacall(1 tap or say “Answer”)

• Rejectacall(1-second press or say “Ignore”)

• Redial (2 taps)

• Initiatephone’svoice-dialing

(2-second press until tone is heard)

• ReconnectlostBluetooth®connection(1 tap if

the headset doesn’t automatically reconnect)

• Activatepairingmodeafterinitialsetup

(press until red/white LED ﬂashes)

• ExitDeepSleep™mode(1 tap)

POWER SWITCH

• On(slide back)

• Off(slide forward)

Your headset may look slightly different than

the illustration, but will still work as described.

PLT_M55

CONNECT TO YOUR PHONE

“Pairing” is the set-up process of

introducing your headset to your

phone. Before using your headset

for the ﬁrst time, you must pair

it with your Bluetooth-enabled

phone.

“Multipoint” lets you pair this

headset with two phones so you

can answer a call from either

phone.

1. READY

FirstTime,RightOutoftheBox

Turn on the headset. The LED

ﬂashes red/white to indicate

pairing mode.

PairNeworSecondPhone

Turn on headset. Press Call

button until the LED ﬂashes red/

white.

2. SET

Activate the Bluetooth feature

on your phone, then use phone

menus to “add,” “search” or “scan”

new Bluetooth devices.

For Example:

iPhone: Settings > General >

Bluetooth: On (starts the search

for devices)

BlackBerry®: Settings/options >

Bluetooth: On > Search for devices

Android™: Settings > Wireless &

Networks > Bluetooth: On > Scan

for devices

3. CONNECT

Select “PLT_M55” from the list of

Bluetooth devices shown on your

phone.

If phone asks for a passcode, enter

four zeros (0000). You may see ****

on screen.

Some phones also ask to conﬁrm

headset connection after pairing.

Headset LED will stop ﬂashing red/

white once successfully paired/

connected.

You can now make a call using your

phone’s keypad or voice-dialing

feature.

For Right Ear

For Left Ear

TRY IT ON

The loop of the gel eartip tucks into the back

curve of your ear for a stable ﬁt.

Try on the headset. The eartip is positioned to

suit most people, but you may want to rotate

it to best ﬁt your left or right ear.

The gel eartip and speaker click into matching

grooves so the eartip doesn’t move out of

place during use.

For best voice pickup, always check that the

headset points towards the corner of your

mouth.

TIPS

Stay Near Your Phone

Bluetooth has a working “range” of up to 33

feet between the phone and headset before

audio degrades and the connection is lost.

Try DeepSleep

If you leave your headset powered on but out

of range from your paired phone for more than

90 minutes, your headset will conserve its bat-

tery power by entering into DeepSleep mode.

This power-saving mode keeps your headset

charged for up to 5 months so it’s ready when

you need it.

Once back in range with your phone, tap the

Call button to exit DeepSleep mode. If your

phone is also ringing, tap the Call button again

to answer your call.

Know How to Reconnect

Your headset tries to reconnect a lost

connection. If it can’t, then tap the Call button

once or manually reconnect via the phone’s

Bluetooth device menu.

If your headset remains out of range for more

than 90 minutes, the DeepSleep mode will acti-

vate.

Turn Off Voice Commands

If you prefer not to use the voice-answer fea-

ture, you can disable it and just use the Call

button.

With the headset powered on, simultaneously

press the Call button and Volume button until

you see the white LED ﬂash twice. To reactivate

the feature, just repeat the steps and you will

see the white LED ﬂash twice.

Use an iPhone to Check Headset Battery

An icon representing the battery level of your

headset is automatically displayed on-screen

beside the phone’s battery level icon.

Listen to Music and More

If your phone also has the Bluetooth “A2DP”

stereo music feature, then your music,

podcasts, favorite internet radio and other

streaming audio can be heard through this

headset.

Use Multipoint One Call at a Time

Once you have activated multipoint and paired

your two phones, it’s easy to answer calls from

either phone.

When already on a call, you will hear a ringtone

notiﬁcation of the incoming call from the

second paired phone.

To answer a second call from the other phone,

you must end the current call (tap Call button)

so new call automatically answers.

If you choose not to answer the second call, it

will go to voicemail.

SPECIFICATIONS

TalkTime Up to 11 hours

StandbyTime Up to 16 days

DeepSleepMode Up to 150 days

OperatingDistance(Range) Up to 33 feet (10 meters), Class II

HeadsetWeight 8 grams

ChargeConnector Micro USB charging

BatteryType Rechargeable non-replaceable lithium ion polymer

ChargeTime(Maximum) 2 hours for full

PowerRequirements 5V DC – 180mA

BluetoothVersion Bluetooth v3.0

BluetoothProles A2DP, Hands-Free (HFP) Proﬁle 1.6 and Headset (HSP)

Proﬁle 1.2

OperatingTemperature 41°F - 104°F (5 - 40°C)

StorageTemperature 41°F - 104°F (5 - 40°C)

ChargingTemperature 41°F - 104°F (5 - 40°C)

NEED MORE HELP?

Read these guides for set up, use and safety tips. For more help,

don’t return to the store, call our team of problem solvers at

1-866-363-2583.

Bluetooth SIG, Inc. and any use by Plantronics is under license. All other trademarks

are the property of their respective owners.

Patents US 5,712,453; Patents Pending. 87608-06 (3-12) EN-US

Z302

N10687
