Explorer 100 Series

User Guide

Contents

What's in the box 3

Headset overview 4

Pair 5

Get paired 5

Pair mode 5

Basics 6

Answer or end a call 6

Adjust the volume 6

Mute 6

Redial 6

Voice control 6

Select language 6

Pair mode 6

Charge and ﬁt 7

Charge 7

Adjust the ﬁt 7

Headset Features 8

Music and more 8

Decipher the lights 8

Voice prompts 8

DeepSleep mode 8

Install the app 8

Speciﬁcations 9

Support 10

Headset Car vent clip*

Vehicle power charger* 2-in-1 combo cable*

Micro USB cable* Optional earloop

NOTE *Accessories may vary by product.

What's in the box

Call button

Charge port

Headset LED (indicator light)

Power button

Volume up

Volume down

Track back

Track forward

Play/pause

Mute

Headset overview

The ﬁrst time you power on your headset, the pairing process begins.

1Slide the power switch on. You hear "pairing" and the indicator light flashes red and blue.

2Activate Bluetooth®on your phone and set it to search for new devices.

•iPhone Settings > Bluetooth > On*

•Android Settings > Bluetooth: On > Scan for devices*

NOTE *Menus may vary by device.

3Select “PLT E100 Series.”

If necessary, enter four zeros (0000) for the passcode or accept the connection.

Once successfully paired, you hear “pairing successful” and the indicator light stops flashing.

While wearing your headset, power it on. Press and hold the Call button until you hear "pairing."

You can pair up to 2 devices to your headset.

Pair

Get paired

Pair mode

Tap the Call button.

Tap the Volume up or Volume down button.

During a conversation, press both the Volume up and Volume down buttons for 2 seconds

until you hear “mute on” or “mute off.”

Double-tap the Call button to call the last number you dialed.

Siri, Google Now™, Cortana Press the Call button for 2 seconds and wait for the phone prompt

to activate voice dialing, search, and other smartphone voice controls.

Press and hold the Volume up and down buttons together until you hear “welcome." Follow

the voice-guided prompts to select the headset language.*

NOTE *Language selection not available in Europe, Russia and Africa.

While wearing your headset, power it on. Press and hold the Call button until you hear "pairing."

You can pair up to 2 devices to your headset.

Basics

Answer or end a call

Adjust the volume

Mute

Redial

Voice control

Select language

Pair mode

It takes 2 hours to fully charge the headset; the indicator light turns off once charging is

complete.

The universal-fit eartip has a thin loop that bends to gently tuck into the contours of either ear. To

adjust the fit, you can rotate the eartip on the headset or add the optional clip-on earloop.

Charge and ﬁt

Charge

Adjust the fit

Listen to your music, podcasts, navigation and other streaming audio on your headset.

Play or pause audio

Press both Volume buttons at the same time.

Skip to next track

Press the Volume up button for 2 seconds.

Play previous track

Press the Volume down button for 2 seconds to restart current track. Press the button twice

(each button press 2 seconds) to go to previous track.

Your headset has an indicator light that ﬂashes in response to a change in status or after a

button press.

Some examples of what you will see are:

• Solid red until charging complete and then solid blue

• Flashing red and blue during pairing

• Double red ﬂash when battery low

• Double blue ﬂash at incoming call

Your headset tells you about status changes. For example:

“Power on”

“Pairing successful”

"Phone 1 connected"

“Talk time (x) hours”

“Mute on”

"Answering call"

“Recharge headset”

If you leave your headset powered on but out of range of your paired phone for more than 120

minutes, your headset will conserve its battery power by entering into a DeepSleep®mode.

Once back in range with your phone, press any button to exit DeepSleep mode. If your phone is

also ringing, tap the Call button again to answer your call.

Get the most from your headset by installing our free mobile app, Plantronics Hub for iOS/

Android. Explore all of your headset's features, view instructions, and contact Plantronics support

easily from your smartphone.

plantronics.com/apps

Headset Features

Music and more

Decipher the lights

Voice prompts

DeepSleep mode

Install the app

Talk Time Up to 7 hours

Standby Time Up to 11 days

Operating Distance

(Range)

Up to 33 feet (10 meters) from phone or table, Class II

Headset Weight 7.8 grams

Charge Connector Micro USB charging

Battery Type Rechargeable non-replaceable lithium ion polymer

Charge Time

(Maximum)

2 hours for full

DeepSleep mode Provides up to 180 days

Power

Requirements

5V DC – 150 mA

Bluetooth Version Bluetooth v4.1

Bluetooth Proﬁles Hands-Free Proﬁle v1.6 (HFP), Headset Proﬁle v1.2 (HSP), Simple Secure Pairing

(SSP)

Moisture Protection No

Operating

Temperature

32°F - 102°F (0 - 40°C)

Storage

Temperature

32°F - 102°F (0 - 40°C)

Charging

Temperature

32°F - 104°F (0 - 40°C)

Speciﬁcations

0800 410014

0800 117095

80011336

+44 (0)1793 842443*

0800 945770

+44 (0)1793 842443*

1800 551 896

800 84 45 17

80 88 46 10

+44 (0)1793 842443*

Deutschland 0800 9323 400

Österreich 0800 242 500

Schweiz 0800 932 340

+44 (0)1793 842443*

8-800-100-64-14

+44 (0)1793 842443*

800 950934

0200 21 46 81

900 803 666

NL 0800 7526876

BE 0800 39202

LUX 800 24870

+44 (0)1793 842443*

*Support in English

For warranty details, go to plantronics.com/warranty.

Support

NEED MORE HELP?

plantronics.com/support

Plantronics, Inc. Plantronics BV

345 Encinal Street

Santa Cruz, CA 95060

United States

South Point Building C

Scorpius 140

2132 LR Hoofddorp, Netherlands

Plantronics Hub and PLT are trademarks of Plantronics, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc. and any use by Plantronics is under

license. Apple, the Apple logo, iPhone, and Siri are trademarks of Apple Inc., registered in the U.S. and other countries. All other trademark are the

property of their respective owners.

Patents: US 9,264,792; D717,771; patents pending.

206923-06 (04.16)
