Planet IGS-5227-4MP2MT Manuel utilisateur

Industrial IP67-rated

4-Port 10/100/1000T 802.3at PoE

+ 2-Port 10/100/1000T

Managed Ethernet Switch (-40~75 degrees C, 24V)

IGS-5227-4MP2MT

Quick Installation Guide

Table of Contents

1. Package Contents ....................................................................................... 3

2. M12 A-coded Connector Pin Assignment ....................................................... 4

3. M12 (8-pin, A-coded Male) to RJ45 (8-pin) Straight-through UTP Cabling ........ 5

4. Connecting M12 Cable to the Industrial Managed Switch................................ 6

5. M23 DC Power Cable Pin Assignment ........................................................... 9

6. Requirements ............................................................................................10

7. Starting Web Management .........................................................................11

8. SavingCongurationviaWeb .....................................................................14

9. RecoveringBacktoDefaultConguration.....................................................15

10. Customer Support ....................................................................................16

1. Package Contents

Thank you for purchasing PLANET Industrial L2+ Managed Ethernet Switch.

“Industrial Managed Switch” is used as an alternative name in this Quick

Installation Guide. Open the box of the Industrial Managed Switch and carefully

unpack it. The box should contain the following items:

The Industrial Managed Switch x 1

Quick Installation Guide x 1

2m 8-pin A-coded M12-to-RJ45 UTP Cable x 1

DIN Rail Kit x 1

Wall-mount Kit x 1

If any item is found missing or damaged, please contact your local reseller for

replacement.

2. M12 A-coded Connector Pin Assignment

The industrial managed switch front panel provides six 10/100/1000BASE-T

Ethernet ports in the form of M12 8-pin A-coded female connector. These ports are

designed for Ethernet equipment connection through Cat5/5e UTP cables. The M12

8-pin A-coded input interface pinout is shown below:

Pin Con

1DA+

2DA

5DC

8DD

3DB+

6DB

7DD+

4DC+

8-pin M12 A-coded Female 10/100/1000T Connector Pin Assignment

3. M12 (8-pin, A-coded Male) to RJ45 (8-pin) Straight-

through UTP Cabling

M12 A-code Male

Connector Pin No.

MDI 1000BASE-T

Signal ID T568B Color RJ45 Connector

Pin No.

1BI_DA+ white/orange 1

2BI_DA- orange 2

3BI_DB+ white/green 3

4BI_DC+ blue 4

5BI_DC- white/blue 5

6BI_DB- green 6

7BI_DD+ white/brown 7

8BI_DD- brown 8

Note

As each Ethernet port of the Industrial Managed Switch is running

in auto negotiation mode, make sure the Ethernet ports of the

corresponding Ethernet devices are also running in auto negotiation

mode, otherwise, the Ethernet performance will be poor.

4. Connecting M12 Cable to the Industrial Managed

Switch

Step 1: Turn counterclockwise to remove the waterproof screw nuts of an M12

connector and M23 power input.

Step 2: Insert the M12 UTP male connector into the M12 female Gigabit Ethernet

port of the Industrial Managed Switch.

Step 3: Turn clockwise to tighten the screw nut of the M12 connector and make

sure the connection is tight.

Step 4: Insert the M23 power female connector into the M23 male port of the

power input.

Note

The box doesn’t contain the M23 5-pin A-coded female connector

power cable.

Step 5: Turn clockwise to tighten the screw nut of the M23 power connector.

Note

Before connecting the DC power cord, please check whether your

local DC power source is stable.

Note

Make sure to tightly close all interfaces to have waterproof effect.

5. M23 DC Power Cable Pin Assignment

The front panel of the Industrial Managed Switch provides one M23 DC power

5-pin male connector for DC power input. Please use the power cable with the M23

DC power 5-pin female connector from the Industrial Managed Switch package for

DC power input. The M23 DC power cable pin assignment is shown below:

Note

1. The box doesn’t contain the M23 5-pin A-coded female

connector power cable.

2. Please contact your local reseller to purchase CB-M23F5F-120

from PLANET.

V2-

V2+

V1-

V1+

CB-M23F5F-120 M23 DC power cable pin assignment and wiring code

V2-

V2+

V1-

V1+

V1 positive (+) pin = white cable

V1 negative (-) pin = brown cable

V2 positive (+) pin = black cable

V2 negative (-) pin = yellow cable

Note

A. Make sure you connect the correct power pin to your DC power

source.

1. The wire gauge for the power cable should be in the range of

12 ~ 24 AWG.

2. The DC power input range is 24 ~ 48V DC.

B. There are two methods to install the Industrial Managed Switch

– DIN-rail mounting and wall-mount plate mounting. For more

detailed information, please refer to Chapter 2 of the user’s

manual.

6. Requirements

Workstations running Windows XP/2003/Vista/7/8/10/2008, MAC OS X or later,

Linux, UNIX, or other platforms are compatible with TCP/IP Protocols.

Workstations are installed with Ethernet NIC (Network Interface Card)

Ethernet Port Connection

Network cables -- Use standard network (UTP) cables with RJ45 connectors.

The above PC is installed with Web browser and JAVA runtime environment plug-in.

Note

It is recommended to use Internet Explore 8.0 or above to access

the Industrial Managed Switch. If the Web interface of the Indus-

trial Managed Switch is not accessible, please turn off the anti-virus

software or firewall and then try it again.
