USER MANUAL OF SMART AC

CS374U-APP(OSK102)

16122000002774

20160524

Company will notbe liable forany issues

and problems causedby Internet, Wi-Fi

Router and SmartDevices. Please contact

the original providerto get furtherhelp.

NOTE:

IMPORTANT NOTE:

Read the manualcarefully before installing or

connecting your Smartkit. Make sureto save

this manual forfuture reference.

CONTENTS

Model: OSK102

Standard:IEEE 802.11b/g/n

Antenna Type:Wxternal omnidirectionalAntenna

Frequency:WIFI 2.4G

Maximum Transmitted Power: 15dBm Max

OOO O

Operation Temperature:0 C~45 C/32 F~113 F.

Operation Humidity:10%~85%

Power Input:DC 5V/300mA

SPECIFICATION

PRECAUTIONS

SPECIFICATION...................................................1

PRECAUTIONS....................................................1

DOWNLOAD AND INSTALL APP...........................2

INSTALL THE SMART KIT .....................................3

USER REGISTRATION.........................................4

NETWORK CONFIGURATION...............................5

HOW TO USEAPP ..............................................13

SPECIAL FUNCTIONS ........................................15

Applicable system: IOS, Android.

(Suggest:IOS 7.0, Android 4.0)

Note:

APP can not support the lastest software version of

Android and IOS system.

Due to special situation may be occured, we explicitly

claims below: Not all of the Andriod and IOS system

are compatible with APP. We will not be responsible

for any issue as a result of the incompatibility.

Wireless safety strategy

Smart kit only support WPA-PSK/WPA2-PSK encryption

and none encryption . WPA-PSK/WPA2-PSK encryption

is recommended.

Caution

Please Check The Service Website For More Information.

Smart Phone camera needs to be 5 million pixels or

above to make sure scan QR code well.

Due to different network situation, sometimes, request

Hereby, wedeclare that this AC is in compliance

with the essentialrequirements and other relevant

provisions of Directive1999/5/EC. The declaration

of conformity maybe consulted with sales agent.

DECLARATION OF CONFORMITY

DOWNLOAD AND INSTALL APP

INSTALL THE SMART KIT

Remove the protectivecap of thesmart kit

Open the frontpanel and insertthe smart kitinto

the reserved interface.

Insert

Attach the QRcode packed withSMART KITto the

side panel ofthe machine, ensureit is convenience

to be scannedby the mobilephone. Alternatively,

user can takepicture of theQR Code andsave in

into their ownphone.

Due to differentnetwork situation, control process may

return time-out sometimes.If this situationoccurs, the

display between boardand Appmay not bethe same,

please do notfeel confused.

NOTE:Company will notbe liable forany issues and

problems caused byInternet, Wi-Fi Routerand Smart

Devices. Please contactthe original providerto get

further help.

Android Phone users: scan QR Code A or go to google

play, search 'Nethome Plus' app and download it.

Iphone Users: scan QR Code B or go to App Store,

search 'Nethome Plus' app and download it.

Caution: QR CodeA and QR CodeB is onlyavailable

for downloadingAPP.

QR Code A

QR Code B

WARNING:This interface is only compatible with

SMART KITprovided by the manufacturer.

time-out could happen,thus, it is necessary to do

network configuration again.

USER REGISTRATION NETWORK CONFIGURATION

Click CreateAccount Enter your emailaddress

and password, andthen

click Registration .

08:42 20:14

VI50828_a

Creat Accout

Forgot password?

[email protected]

Enter your E-mail address

Password

I have read and agree to the terms of service

65% 61%

Registration

Please ensure your mobile device is connected to Wifi

router. Also, the Wifi router has already connected to

Internet before doing user registration and network

configuration.

It is better to log in your email box and active your

registration account by clicking link in case you forget

the password.

Caution:

It is necessary to forget any other around network and

make sure the Android or IOS device just connect to

the WIFI network you want to configure.

Make sure the Android or IOS device WIFI function

works well and can be connected back to your original

WIFI network automatically.

Kindly reminder:

When ACenters into AP mode, theair-conditioning

remote controller can'tcontrol it. It is necessary to

finish network configuration or power the AC again

in order tocontrol it. Alternatively, youneed to wait

8 minutes tolet the AC quit AP mode automatically.

Using Android device to do network configuration

Make sure your mobile device has already been

connected to the wifi network which you want to use.

Also, you need to forget other irrelative wifi network in

case it influences your cofiguration process.

Disconnect the power supply of AC.

Connect the power supply of AC, and continuously

press the digital display button or do not disturb button

seven times in 3 minutes.

When the AC displays AP , it means that the AC WIFI

has already entered into AP Mode.

Some type ofAC donot need the step to bein AP

mode

6 7

5Press +Add Device,

Scan QR Codewhich

is packed withsmart kit

Select your ownWiFi

network, for example

My Home (thepicture

is only forreference)

Enter your ownWiFi

router password and

click OK;

Configuration Success,

you can seethe device

on the list.

Home

Nong Jun

User name

Add Device

20:14

Align the QR code within the frame to scan

The first press of restart

61%

QR Code Pictures

My Home

Password

Cisco

Belkin

20:14

Air conditioner want to use your WiFi

61%

Network OK Home

User

Oasis

Add Device

8 9

6Scan QR Codewhich

is packed withsmart kit

5Press +Add Device,

7Read the instruction

above and pressthe

Home button toreturn

to the deviceinterface.

Click settings toenter

the setting page,select

WLAN/WIFI.

Search and connection

Settings

Airplane Mode

WLAN

Bluetooth

Cellular

Off

Connect to WIFI AC hot spot:

Return to the setting page of IOS Device > Click

WLAN > Select net_ac_xxxx > Return to the

current page.

Password: 12345678

SSID: net_ac_xxxx

Using IOS deviceto do networkconfiguration

Mak sure your mobile device has already been

connected to the wifi network which you want to use.

Also, you need to forget other irrelative wifi network in

case it influences your cofiguration process.

Disconnect the power supply of AC(some units).

Connect the power supply of AC, and continuously

press the digital display button or do not disturb button

seven times in 3 minutes.

When the AC displays AP , it means that the AC WIFI

has already entered into AP Mode.

20:14 61%

Settings

Airplane Mode

WLAN Smart

Bluetooth Off

Cellular Off

VPN

Notifications

Control Center

Do Not Disturb

General

Home

Nong Jun

User name

Add Device

20:14

Align the QR code within the frame to scan

The first press of restart

61%

QR Code Pictures

Type defultpassword:

12345678 and click

"Join "

Return to APP and

click Next

Choose net_ac_XXXX

Select your ownWiFi

network, for example

My Home (thepicture

is only forreference)

Enter your ownWiFi

router password and

click OK;

Settings WLAN

CHOOSE ANET WORK.....

ASUS-5GX

ASUS-2.4GX

bdptest1

bdptest1-5G

HIWIFI-22EF60

Midea

midea_fc_6866

MideaACIOT

net_ac_0010

zztest

20:14 61%

10 11

Search and connection

Settings

Airplane Mode

WLAN

Bluetooth

Cellular

Off

Connect to WIFI AC hot spot:

Return to the setting page of IOS Device > Click

WLAN > Select net_ac_xxxx > Return to the

current page.

Password: 12345678

SSID: net_ac_xxxx

Joining "net_ac_0010"....

20:14 61%

Cancel Join

Enter Password

Password

My Home

Password

Cisco

Belkin

20:14

Air conditioner want to use your WiFi

61%

Network OK

12 13

Configuration Success,

you can seethe device

on the list.

HOW TO USE APP

Please ensure bothyour mobile deviceand air

conditioner are connectedto the Internetbefore

using app tocontrol the airconditioner via internet,

please follow thenext steps:

Type yourown account

and password, Click

"Sign in "

Select the targetair

conditioner to enter

into the maincontrol

interface.

NOTE:

User

Oasis

Premier

Add Device

Home

User

Oasis

Add Device

08:42

VI50828_a

Creat Accout

Forgot password?

[email protected]

65%

When finishing networkconfiguration, APPwill

display success cuewords on thescreen.

Due to differentinternet environment, it is possible

that the devicestatus still display offline . Ifthis

situation occurs, itis necessary topull and refresh

the device liston theAPP and makesure the device

status become online . Alternatively, user can

turn off theAC power and turn on it again, the device

status will become online after fewminutes.

14 15

3Thus, user cancontrol

air conditioners on/off

status, operation mode,

temperature, fan speed

and so on.

SPECIAL FUNCTIONS

Timer on/ Timer off

Weekly, user can make an appointment toturn on or

off ACon specific time. User also can choose

circulation to keepthe ACunder schedule control

every week.

NOTE:

Not all thefunction of theAPP isavailable on air

conditioner. Forexample: ECO, Turbo, Left andRight

Swing, Up andDown swing function,please check

the user manualto find moreinformation.

Including: Timeron, Timeroff, 8 C Heat, Sleep,

Check.

NOTE: If the airconditioner do notsupport the above

function, the functionwill be hidedfrom the function

list.

Timer On

Mon. Tues.

18:00

Timer Off

Mon. Tues.

02:00

8 Heating

Sleep

Check

Timer On

Mon. Tues.

18:00

Timer Off

Mon. Tues.

02:00

8 Heating

Sleep

Check

16 17

8 CHeat

User can letthe ACrun under 8 C Heat by one-click.

When people gooutisde, this functioncan protect

your furniture fromfrost damage.

08 48

Repeat Mon,Tue

Monday

Tuesday

Wednesday

Thursday

Friday

Saturday

Sunday

Timer On

Mon. Tues.

18:00

Timer Off

Mon. Tues.

02:00

8 Heating

Sleep

Check

Table des matières

Autres manuels Pioneer Matériel informatique

Pioneer

Pioneer BDR-XD08EMB-S Manuel utilisateur

Pioneer

Pioneer DEQ-P7050 Manuel utilisateur

Pioneer

Pioneer DEQ-P8000 - DSP - External Manuel utilisateur

Pioneer

Pioneer RG-60 Manuel utilisateur

Pioneer

Pioneer DEQ-P800/UC Manuel utilisateur

Pioneer

Pioneer SP-700D Manuel utilisateur

Pioneer

Pioneer DEQ-P6600 Guide de démarrage rapide

Pioneer

Pioneer DEQ-7200 Manuel utilisateur

Pioneer

Pioneer DEQ-P7650 Manuel utilisateur

Pioneer

Pioneer AXY1153 Manuel utilisateur

Pioneer

Pioneer DEQ-7200 Manuel utilisateur

Pioneer

Pioneer DEQ-P7650 Manuel utilisateur

Pioneer

Pioneer RG-2 Manuel utilisateur

Pioneer

Pioneer SP-99D Manuel utilisateur

Pioneer

Pioneer RMD-V3000X Manuel utilisateur

Pioneer

Pioneer AVG-VDP1 Manuel utilisateur

Pioneer

Pioneer DEQ-P7050 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
