Philips MMS8085B/94 Manuel utilisateur

MMS8085B

2.1

General information

Safety instructions

Please read carefully the safetymark on the back side

This mark is intended to alert the user from

the non isolated dangerous voltage within the

constitute a risk of electric shock to persons.

This mark is intented to alert the user for

important operating and servicing instruction.

Warnings

•Avoid sustained periods on high-volume use, and

do not turn the volume to maximum level while using

high output signal, such as Mobile Phone or DVD,

etc., as this will cause distortion and may damage the

loudspeaker cones.

•

when not in use.

•Do not open the cover or back panel to avoid

electrical shock or any other accidents. No user-

serviceable parts are inside.

•Only for indoor use.

•Plug the system to the AC outlet with the right voltage

marked on the back panel of the Subwoofer.

•The MAINS plug is used as the disconnect device, the

disconnect device shall remain readily operable.

Care and safety information

Avoid high temperatures, moisture, water and dust

•Apparatus should not be exposed to dripping or

splashing of liquid.

•Do not place any source of danger on the Subwoofer,

•Do not install near heat sources.

Do not block any ventilation opening

•Place the apparatus in a location with adequate

ventilation to prevent internal heat build up. Allow at

least 100cm (4 inches) of free space all around the

apparatus for adequate ventilation.

•At high volume the back cover of Subwoofer becomes

hot. Do not touch it.

Care of the cabinet

•Use a soft cloth slightly moistened to clean the cabinet.

Do not use a solution containing alcohol, spirits,

ammonia or abrasives.

Accessories

Item 3.5mm stereo cable to 2RCA Remote control User manual FM Antenna cable

Quantity 1 1 1 1

Speaker Stand

The product shall not be exposed to dripping or splashing

and that no objects lled with liquids, such as vases, shall

be placed on the product.

•

•Attention should be drawn to the environmental

aspects of battery disposal.

•Batteries shall not be exposed to excessive heat such as

sunshine, re or the like.

Connections

Subwoofer back panel

FM Antenna Connection

Power On/Off Switch

Power Cord

SD Card Slot USB Slot

Top & Back panel operation

* AVAILABLE IF CONNECTED

2. SOURCE

SOURCE

5. VOLUME+/-

6. SD Slot

7. USB Slot

Audio, CD, FM, USB*,

SD* and Bluetooth.

5. Rotate the knob clockwise to increase volume

anti-clockwise to decrease volume.

6. SD* Slot:

Press the SOURCE key to go to SD* MODE.

7. USB* Slot:

Press the SOURCE key to go to USB* MODE. 4

(5)

(6) (7)

(4)

(3)

(2)

(1)

Remote controls

8. VOL+

10.

11.

12.VOL-

13.BASS+/-

2.MUTE

3.0~9

4.BT

5.AUD/ CD

6.FM

7.USB/ SD

(1)

(3)

(4)

(6) (7)

(9)

(12)

(2)

(5)

(8)

(10) (11)

(13) (13)

* AVAILABLE IF CONNECTED

1. ----- Turn on/Stand-by the speaker.

2. MUTE ------ Press “MUTE ” to activate or deactivate mute.

3. 0~9 ----- Numeric keys, with the help of these keys you select

song or track in USB, and in FM, you can key in station frequency,

i.e. for 927 key in 92.7.

4. BT------ Press “BT” to enter Bluetooth mode.

5. AUD/ CD ----- Press “AUD/ CD” to enter Audio in mode,

press again to enter CD mode.

6. FM ----- Press “FM” to enter FM mode.

7. USB/SD ----- Press “USB/SD” to enter USB*/SD* mode, insert

USB* to go for USB mode, while insert SD* card to go for SD* mode.

8. VOL+ ----- Volume up.

9. ----- Plays/pauses songs alternately in FM mode,

long press“ ”, it will enter into automatic search channel and

automatic save channel.

10. ----- Play the previous song by pressing “ ” in USB* mode.

Choose previous channel by pressing “ ” in FM mode.

11. ----- Play the next song by pressing “ ” in USB* mode.

Choose next channel by pressing “ ” in FM mode.

12. VOL- ----- Volume down.

13. BASS-/+ ----- To decrease/ increase the bass.

BT AUD/ CD

FM USB/ SD

Manual storage: press frequency like 91.1, the system will check if

station is available, suppose it is, then the system will judge whether

it had been stored or not,

if yes, it will start to play automatically,

if no, the system will store the station rst, with station number after

last station number from auto search, and start to play.

System positioning :

The subwoofer is recommended to be put

on the oor to get a better acoustic eect.

For best possible surround sound, all the

speakers (except subwoofer) should be

placed at the same distance from the

listening position.

Place the front left and right speakers at

equal distances from the TV and at an angle

of approximately 45 degrees (horizontal)

from the listening position.

Helpful Hint:

- To avoid magnetic interference, do not position

the speakers, too close to your TV.

Playing the speakers and subwoofer

Audio source / player

Bluetooth Operating Instruction

Troubleshooting

In case these measures do not work contact the nearest PHILIPS service center or call at customer care numbers.

Problem Solution

1. No power.

2. No sound or distorted sound.

3. The remote control does not

function properly.

4. Low hum or buzz sound.

drive cannot be read.

6. Slow operation of the USB / SD

8. FM reception not good.

Check if the AC power cord is properly inserted into the AC mains socket.

Adjust the volume / select the correct source to choose the equipment

that you want to hear through the system.

Reduce the distance between the remote control and the system. Replace

the batteries with new ones / Point the remote control directly towards the

IR sensor (located on front panel of the subwoofer) / Check that the batteries

Place the product as far away as possible from electrical devices that may be

causing interference / Check power supply voltage and consult electrician.

Drive is

7. FM not properly tuned. Match with local frequency.

9. BT not working. Reduce the distance or device is not paired.

Warning -

Under no circumstances should you try to repair the system yourself, as this will invalidate the warranty.

below before taking the system for repair. If you are unable to remedy the problem by following hints

mentioned in below table, Consult your dealer or PHILIPS APSC for help.

Big memory size USB / SD ash drive will take longer time to read

and play. / Take out USB / SD drive and insert it again properly.

Gibson Innovations India Private Limited 4th Floor, Block-1, Vatika Business Park, Sector 49, Sohna Road,

Gurgaon-122018, Haryana, India

This Philips 2.1 multimedia speakers system is warranted against any defect due to defective materials or

workmanship for 12 months from the date of purchase, should a defect develop during the period of warranty,

Gibson Innovations India Private Limited undertake to repair the apparatus FREE OF CHARGE through the dealer

from whom it has been purchased or at any of the Philips Authorised Service Centres.

The warranty is not valid in case :

1. Proof of purchase is not accompanied with this warranty card.

2. The warranty card is not completed immediately after purchase.

3. The apparatus is not used according to this manual.

4. Defects are caused by improper or reckless use.

5. Any repairs are done by persons other than Philips Authorised service centre.

7. The serial number is tampered with.

8. Defects due to causes beyond control like lightning, abnormal voltage, acts of God or while in

transit to the purchaser’s residence.

All consumables and parts susceptible to normal wear and tear are not covered under warranty.

Week/S.No.: ___________________________ Bill No. ___________________________

Date of purchase _________________________________________________________

Dealer’s name: ___________________________________________________________

Dealers stamp: __________________________________________________________

Customer’s name and address: _____________________________________________

Model No.: _____________________________________________________________

Dealer’s signature: ________________________________________________________

Warranty

Total system power 80W RMS

Satellite speaker power 17.5Wx2 RMS

Subwoofer power 45W RMS

Separation >40 dB

SNR >60 dB

Audio input socket RCA

Audio output socket RCA

Power consumption 80W

Subwoofer speaker 1 Way

Driver size 6.5 inches

Impedance 8 Ohm

Frequency range 20Hz - 4KHz

Dimension (mm) W x H x D 266 x 515 x 230

Weight 5.47 kgs

The Philips trademark and Philips shield emblem are

registered trademarks of koninklijke Philips N.V. used

under license.

This product has been manufactured by and sold

under the responsibility of Gibson Innovation India

Private Ltd. and Gibson Innovations India private Ltd.

is the warrantor in relation to this product.

Or [email protected]

www.india.philips.com

Question?

Contact

Philips

Satellite speaker

Driver size

Impedance

Frequency range

Dimension (mm) W x H x D

Weight

BT version

BT range

USB class support

USB capacity

USB playability

100 x 519 x 110

1 Way, 2 Speakers

3 inches

4 Ohm

120Hz - 20KHz

1.64 kgs

Up to 16GB

V3.0

UMS (USB mass

storage class)

Up to 10 meter

MP3 format le
