Philips CSP620 Manuel utilisateur

www.philips.com/welcome

CSP620 CSP6920

EN User manual

a b

f g

Amplifier

Right White lined White lined

Right

Left

Black

Left

CSP620

English

1. Important

Safety

Read and understand all instructions before you use the apparatus.•

If damage is caused by failure to follow instructions, the warranty does not apply.

Use only the supplied mounting hardware for a safe and secure installation.•

Do not continuously use the speaker system beyond the peak power handling capacity.•

Keep credit cards, watches, recorded tapes etc. with magnetic coding away from the speaker system to•

prevent damage caused by the magnets in the speakers.

Clean the apparatus with soft, damp cloth. Never use substances such as alcohol, chemicals or•

household cleaners on the apparatus.

Notice

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into

three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)

Your system consists of materials which can be recycled and reused if disassembled by a specialized company.

Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and

old equipment.

AnychangesormodicationsmadetothisdevicethatarenotexpresslyapprovedbyPhilipsConsumer

Lifestyle may void the user’s authority to operate the equipment.

Specicationsaresubjecttochangewithoutnotice.Trademarksaretheproper tyofKoninklijkePhilipsElectronicsN.V.ortheirrespectiveowners.

Philips reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly.

2.Your car stereo speakers

Congratulations on your purchase, and welcome to Philips!

TofullybenetfromthesupportthatPhilips

offers, register your product at www.philips.com/welcome.

Introduction

With the speakers, you can enjoy high power music with vivid sound.

What’s in the box A

Check and identify the contents of your package:

aSpeakers (x2)

bGrille net + Frame (x2)

cSpeaker wire (x2)

dScrew (x8)

eShrapnel (x8)

3. Installation

A depth of at least 46mm is required to mount the speaker. Measure the depth of the area where you are

to mount the speaker, and ensure that the speaker does not obstruct any other components of the car.

Option 1: Mount on door (front or rear) B

You can mount the speakers on the front/rear door of your car. a

Note

•Make sure that nothing obstructs around the mounting location of the door.

A hole for mounting may already be cut out of the inner panel of the door (front or rear). In this case, you need to

•

modify the board only.

Ensure that the speaker terminals, frame or magnet do not interfere with any inner parts, such as the window

•

mechanism in the door (when you open or close the window), etc. Also ensure that the speaker grille does not touch

anyinnerttings,suchasthewindowcranks,doorhandles,armrestsetc.

1 Turnoffthecarignitionkey.

If the power is on, the click noise generated by the connection may damage the speakers.•

2Cut out the mounting template from the packing box.

3Paste the template on the location selected for mounting the speaker.

4Mark the cut-off hole and the 4 bolt holes. b

5Cut out the marked area and drill the bolt holes. c

6Remove the grille net. d

7 Stripthespeakerwiresandconnectthemtotheamplier. e

Black wire: connect to “-“ (negative) terminal•

Black (white lined): connect to “+“ (positive) terminal•

Note

Match the “left”, “right”, “+” and “-” terminals correctly. Revised polarity may degrade sound quality.

•

Two4-ohmspeakers,wiredinstereo,presenta8ohmloadtoeachchanneloftheamplier.Mosttwochannel

•

ampliersworkwellinthisconguration.However,iftwo4-ohmspeakers,wiredinparalleltoabridgedtwo-channel

amplier,presenta2-ohmmonoloadtotheamplier.Most2-channelampliersdonotsupport2-ohmmono

operation!Amplierdamagemayresult!

8Mount on the speaker as shown below. f

9Press and insert the edges of the grille net. g

Tip

Thespeakergrillecanbemountedwithoutthegrillenet,ifyoulike.

•

Option 2: Mount on rear tray C

You can also mount the speakers into the surface of the rear tray.

Follow the steps in section “Option 1: Mount in door” to mount the speakers into the rear tray:

4. Product information

Note

Product information is subject to change without prior notice.•

Model CSP620 CSP6920

Speaker type 16.5cm, 3-way triaxial speaker 16x24cm, 5-way coaxial speaker

RMS power (Watts) 80W 80W

Peak music power (Watts) 400W 480W

Sensitivity (dB/W/m) 90dB 91dB

Frequency response (Hz) 35-32kHz 27-33kHz

Impedance (ohms) 4 ohms 4 ohms

Magnet mass (Oz) 8.6Oz 22Oz

Mounting depth (mm) 59mm 88.1 mm

5.Troubleshooting

Tokeepthewarrantyvalid,nevertrytorepairthesystemyourself.

If you encounter problems when using this apparatus, go to the Philips web site (www.philips.com/

welcome). When you contact Philips, ensure that the apparatus is nearby and the model number and

serial number are available.

CSP620_55_UM_V2.1
