Philips AW9000 Manuel utilisateur

www.philips.com/support

User manual

Always there to help you

AW9000

Question?

Contact

Philips

English

Contents

1 Important 2

Safety 2

Notice 3

2 Your Wireless Hi-Fi Speaker 4

Introduction 4

What's in the box 4

What else you need 4

Overview of the main unit 5

3 Prepare 6

Download Philips AirStudio+ Lite to

your smartphone or tablets 6

Connect speaker cables 7

Connect power and switch on 8

4 Connect AW9000 to your home

Wi-Fi network 9

Option 1: Set up wireless connection

to a non-WPS router through an

iOS device 9

Option 2: Set up through a non-WPS

Wi-Fi router and Android device 12

Option 3: Set up wireless connection

to a WPS router 14

Option 4: Set up wired connection

through an Ethernet cable 15

5 Play 17

Listen to Internet radio stations

through AW9000 17

Play from an external device 19

6 Upgradermware 21

7 Product information 22

Specications 22

8 Troubleshooting 23

9 Appendix: Understand meanings

of LED colors 25

2EN

1 Important

Safety

Information for Europe:

Know these safety symbols

The 'exclamation mark' calls attention to

features for which you should carefully read the

supplied literature to prevent operating and

maintenance problems.

The 'lightening bolt' symbol indicates

uninsulated components within the product

that can cause an electric shock.

Toreducetheriskofreorelectricshock,do

not expose the product to rain or moisture and

donotplaceanyobjectslledwithliquids,such

asvases,ontheproduct.

a Read these instructions.

b Keep these instructions.

c Heed all warnings.

d Follow all instructions.

e Do not use this product near water.

f Clean only with dry cloth.

g Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

h Do not remove the casing of this product.

i Do not expose the product to dripping /

splashing water, rain or high humidity.

j Keep this product away from direct

sunlight,nakedamesorheat.

k Do not install near any heat sources

such as radiators, heat registers, stoves,

or other electrical equipment (including

ampliers).

l Do not place any other electrical

equipment on the product.

m Do not place any sources of danger

on the product (e.g. objects containing

liquids,burningcandles).

n Where the mains plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

• Never remove the casing of this apparatus.

• Never lubricate any part of this apparatus.

• Never place this apparatus on other electrical

equipment.

• Keepthisapparatusawayfromdirectsunlight,naked

amesorheat.

• Ensure that you always have easy access to the power

cord,plugoradaptortodisconnectthisapparatusfrom

the power.

Risk of overheating! Never install this apparatus

inaconnedspace.Alwaysleaveaspaceof

at least four inches around this apparatus for

ventilation. Ensure curtains or other objects

never cover the ventilation slots on this

apparatus.

English

Notice

This product complies with the radio

interferencerequirementsoftheEuropean

Community.

Thisproductcomplieswiththerequirementof

the 1999/5/EC directive.

Modications

Modicationsnotauthorizedbythe

manufacturer may void user's authority to

operate this product.

Your product is designed and manufactured

withhighqualitymaterialsandcomponents,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is

attached to a product it means that the product

is covered by the European Directive 2002/96/

EC.

Please inform yourself about the local separate

collection system for electrical and electronic

products.

Please act according to your local rules and

do not dispose of your old products with your

normal household waste. Correct disposal of

your old product helps to prevent potential

negativeconsequencesfortheenvironmentand

human health.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separateintothreematerials:cardboard(box),

polystyrene foam (buffer) and polyethylene

(bags,protectivefoamsheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

aspecializedcompany.Pleaseobservethe

local regulations regarding the disposal of

packagingmaterials,exhaustedbatteriesandold

equipment.

Android is a trademark of Google Inc. Use of

this trademark is subject to Google permissions.

Class II equipment symbol:

CLASSIIapparatuswithdoubleinsulation,and

no protective earth provided.

Note

• The type plate is located on the bottom of the

apparatus.

4EN

2 Your Wireless

Hi-Fi Speaker

Congratulationsonyourpurchase,and

welcometoPhilips!Tofullybenetfromthe

supportthatPhilipsoffers,registeryourproduct

at www.philips.com/welcome.

IfyoucontactPhilips,youwillbeaskedforthe

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Introduction

WiththiswirelessHi-Fispeakersystem,youcan:

• Listen to music sent from a DLNA /

UPnP compatible APP.

• listen to Internet radio stations or

online music services.

• play music from other audio devices

through the MP3-LINK,OPTICAL,

COAXIAL or AUXIN(L/R) sockets.

What's in the box

Check and identify the contents of your

package:

• Wireless Hi-Fi speaker system with

built-in Wi-Fi

• 2 x AC power cords

• 1 x speaker cable

• Quick start guide

• Safety sheet

What else you need

TostreamaudiowirelesslytoAW9000,you

need:

• acertiedWi-Firouter

• aniOSorAndroiddevice,suchasan

iPod touch/iPhone/iPad; or an Android

phone or tablet

• the Philips AirStudio+ Lite app

available on Apple App Store (for iOS

devices) or Google Play Store (for

Android devices)

Your AW9000 should be connected to the

same local network as your iOS/Android device

or through the Wi-Fi router.

English

Overview of the main unit

a +/-

• Adjust volume.

b Numerickeys(1to5)

• Select an Internet radio station.

c AUX 1 button

• Select an auxiliary input source

connected to the OPTICAL or

COAXIAL socket.

d AUX 2 button

• Select an auxiliary input source

connected to the AUX IN L/R sockets.

e MP3-LINK button

• Select the MP3 link source.

f Power indicator/button

• Show the current status of the device.

• Switch the device on or to normal/Eco

standby mode.

g AUX IN L/R sockets

• Connect an external audio device

through RCA audio cables (red/white;

not supplied).

h MP3-LINK socket

• Connect an external audio player

through a 3.5mm audio cable (not

supplied).

i WI-FI SETUP button

• Connect the device to a Wi-Fi

network.

j ETHERNET socket

• (Optional) Connect to a wireless

router through an Ethernet cable (not

supplied).

k AC IN ~ socket

• Connect the power cord.

l OPTICAL socket

• Connect an external device through an

optical cable (not supplied).

m COAXIAL socket

• Connect an external audio device

through an coaxial cable (not supplied).

n Speaker connectors

• Connect the two speakers with each

other through the supplied speaker

cables.

6EN

3 Prepare

Always follow the instructions in this chapter

in sequence.

Download Philips AirStudio+

Lite to your smartphone or

tablets

1 (For iPod touch/iPhone/iPad users) Install

Philips AirStudio+ Lite from Apple App

Store,andthenruntheapp.

(For users of Android smartphones or tablets)

Install Philips AirStudio+ Lite from Google Play

Store and then run the app.

2 Flick right to view the introduction pages

and then go to the initial Setuppage,or

tap Skip intro to enter the initial Setup

page directly.

English

3 On the initial Setuppage,tapSetup a new

speaker.

4 Readthegeneralsetupsteps,thentap

Next.

Connect speaker cables

Note

• Insert the stripped portion of each speaker wire into

the socket completely.

• Foroptimalsound,usethesuppliedspeakersonly.

1 Unscrew the speaker connectors.

2 Insert fully the end of a speaker cable with

red mark into the left red (+) connector.

3 Screw the left red (+) connector to secure

the cable.

4 Insert fully the end of a speaker cable

without red mark into the left black (-)

connector.

5 Screw the left black (-) connector to

secure the cable.

6 Repeat steps 2-5 to insert the other

speaker cable into the right connectors.

21 3

8EN

Connect power and switch

Caution

• Risk of product damage! Make sure that the power

supply voltage matches the voltage printed on the

bottom of the device.

• Risk of electric shock! When you unplug the AC power

cord,alwayspulltheplugfromthesocket.Neverpull

the cord.

• BeforeyouconnecttheACpowercord,makesurethat

you have completed all the other connections.

1 Read the power connection instructions

on the app.

2 Connect the AC power cord to

• the AC IN ~ socket on the back of the

main speaker.

• the wall power socket.

» The device switches on automatically.

» The power/status indicator blinks

amber during boot-up.

» Afterawhile,forrst-timesetup,the

power/status indicator turns solid

amber.

3 Tap Next on the app screen to continue.

Switch between normal and Eco power

standby mode

• To switch the device to normal standby

mode,brieypressthepowerbutton/

indicator above .

» The power/status indicator turns green.

• To switch the device to Eco power standby

mode,pressandholdthepowerbutton/

indicator above for less than 3 seconds

and then release the button.

» The power/status indicator turns

amber for a short while and then turns

off.

• To switch the device on from normal or

Ecopowerstandbymode,brieypressthe

power button/indicator above again.

Operation LED status

On ->

Normal

standby

Brieypressthe

power button/indi-

cator above .

Amber/white

-> Green

On/Normal

standby ->

Eco power

standby

Press and hold the

power button/indi-

cator above for

less than 3 seconds

and then release

the button.

Amber/white

or green ->

Off

Normal

standby/

Eco power

standby ->

Brieypressthe

power button/

indicator above .

Green/Off ->

Amber/white

AC IN ~

Autres manuels pour AW9000

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Intervenants

Philips

Philips 2AANUBT50 Manuel utilisateur

Philips

Philips SPA4210/10 Manuel utilisateur

Philips

Philips SPA5162B Manuel utilisateur

Philips

Philips 3000 series Manuel utilisateur

Philips

Philips 7000 series Manuel utilisateur

Philips

Philips FB 603/00 Manuel utilisateur

Philips

Philips SD7220 Manuel utilisateur

Philips

Philips Fidelio HTL9100 Manuel utilisateur

Philips

Philips SPA7350/05 Manuel utilisateur

Philips

Philips SPA8210 Manuel utilisateur

Philips

Philips EverPlay BT3900 Manuel utilisateur

Philips

Philips CSP251/00 Manuel utilisateur

Philips

Philips SPA7380 Manuel utilisateur

Philips

Philips SPA8210 Manuel utilisateur

Philips

Philips HTL2163B Manuel utilisateur

Philips

Philips Fidelio DS3880W/10 Manuel utilisateur

Philips

Philips SPA3350/10 Manuel utilisateur

Philips

Philips SPA7360/05 Manuel utilisateur

Philips

Philips RWSS5510 Manuel utilisateur

Philips

Philips SPA5200 Manuel utilisateur

Philips

Philips Fidelio SoundRing DS3801W/37 Manuel utilisateur

Philips

Philips CSP652/51 Manuel utilisateur

Philips

Philips HTL5120 Manuel utilisateur

Philips

Philips EverPlay BT3900 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
