Philips HSB3280 Manuel utilisateur

HSB3280

Quick Start Guide

What’s in the Box?

You should ﬁnd these items upon opening the box.

Table stand Smart remote control

(with battery)

FM antenna

Wall mount bracket and screws

(x4)

Studs (x2) used to attach

speakers to main unit

Coaxial cable (orange)

Composite cable (yellow)

AV cable

AC adaptor

for main unit

User manual

Quick Start Guide

HSB3280_QSG_Eng.indd 1HSB3280_QSG_Eng.indd 1 2008-07-24 9:59:262008-07-24 9:59:26

Tips

– See the User Manual for how to mount

the main unit and speakers onto wall.

– See “Connect AV devices” for more AV

connection options.

– For connection and operation of your AV

devices, see the respective user manuals.

Note:

– If automatic setup of wireless connection

fails, see “Set up wireless connection

manually” in the User Manual for the

solution.

AUDIO VIDEO

AUDIO OUT

AUDIO VIDEO

AUDIO OUT

(DIGITAL)

AUDIO VIDEO

AUDIO OUT

Not used

AC Power

DVD player

Game console

Set-top box

FM antenna

123

AOR B

Attach the speakers to the main unit.

Slide the table stand onto the bottom of the main unit.

Place the main unit and speakers.

Connect the audio sockets of the system and TV with the supplied coaxial

cable Aor the white/red connectors of the supplied AV cable B.

Connect the FM antenna.

Connect the power cords of the main unit and wireless subwoofer.

➜

Wireless connection sets up automatically.

HSB3280_QSG_Eng.indd 2HSB3280_QSG_Eng.indd 2 2008-07-24 9:59:342008-07-24 9:59:34

IMPORTANT!

– To set clock in the Eco Power Standby mode, ﬁrst press and hold 2for more than 2

seconds to switch to the standby mode.

Setting the clock

In standby mode, press and hold SET TIME/PRO.

When the hour digits ﬂash, press VOL +/- to set the hours.

Press SET TIME/PRO.

When the minute digits ﬂash, press VOL +/- to set the minutes.

Press SET TIME/PRO again to conﬁrm the time setting.

Program remote control

Place the smart remote control (A) within 1mm-10mm distance from the other remote control

(B).

Press LEARN for 2 seconds to activate the learning mode.

➜

A blue indicator on the smart remote control (A) lights up.

Press the button on the other remote control (B) that is to be stored on the smart remote

control (A).

➜

If the code is received successfully, the blue indicator ﬂashes.

Press one of the 12 white learning buttons on the smart remote control (A) to store the code

of this button.

➜

If the code is stored successfully, the indicator ﬂashes green for 2 seconds, then turns blue

again.

Repeat steps 3 and 4 to program more buttons on the smart remote control (A).

Press LEARN to exit the learning mode.

Notes:

– If there is no operation within

8 seconds, the systme quits the

learning mode automatically

and the indicator turns off.

– During the learning process,

the normal remote control

functions are disabled.

– By default, the remote control

codes of a Philips TV are stored

in the smart remote control.

The available preset buttons

are POWER,AV, 3CH4, 3VOL4,

MUTE and SLEEP.

HSB3280_QSG_Eng.indd 3HSB3280_QSG_Eng.indd 3 2008-07-24 9:59:382008-07-24 9:59:38

Enjoy sound of a connected AV device through the soundbar system

Select an AV source.

Select the feature and settings you want.

Programming and tuning to radio stations

Press TUNER to select tuner (FM) source.

Press and hold SET TIME/ PROG for more than two seconds to program all available stations

in order of waveband.

Press PRESET/ALB/34 until the desired preset station is displayed.

Playing a USB mass storage device

PDCC-JS/JW-0828

Tip

Detailed playback features and additional functions are

described in the accompany owner's manual.

Flip open the cover on the front panel.

Insert the USB plug of a USB device into the socket.

Press USB to select the USB source.

➜

The total number of tracks is displayed.

Press PRESET/ALB/34 to select a folder.

Press ¡/ ™to select a ﬁle.

Press ÉÅ to start play.

HSB3280_QSG_Eng.indd 4HSB3280_QSG_Eng.indd 4 2008-07-24 9:59:392008-07-24 9:59:39
