Philips Fidelio b8 Manuel utilisateur

User manual

www.philips.com/support

1EN

Contents

1 Important 2

Safety 2

Care for your product 3

Care of the environment 3

Compliance 4

Help and support 4

2 Your product 5

Main unit 5

Remote control 5

Connectors 6

Wireless subwoofer 7

3 Connect 8

Placement 8

Pair up with the subwoofer 8

Connect audio from TV 9

Connect audio from other devices 10

Connect digital devices through

HDMI 11

4 Use your product 12

Set clock 12

Auto standby 12

Adjust the volume 12

Dolby Atmos® 13

Choose your sound 13

Play audio through Bluetooth 14

Connect Bluetooth via NFC 15

MP3 player 16

USB storage devices 16

Set display brightness 16

Apply factory settings 16

5 Update software 17

Check software version 17

Update software via USB 17

6 Wall mount 18

7 Product specications 19

8 Troubleshooting 20

2EN

1 Important

Read and understand all instructions

before you use your product. If

damage is caused by failure to follow

instructions, the warranty does not

apply.

Safety

Risk of electric shock or re!

• Before you make or change any

connections, make sure that all

devices are disconnected from the

power outlet.

• Never expose the product and

accessories to rain or water. Never

place liquid containers, such as

vases, near the product. If liquids

are spilt on or into the product,

disconnect it from the power outlet

immediately. Contact Consumer

Care to have the product checked

before use.

• Never place the product and

accessories near naked ames or

other heat sources, including direct

sunlight.

• Never insert objects into the

ventilation slots or other openings

on the product.

• Where the mains plug or an

appliance coupler is used as the

disconnect device, the disconnect

device shall remain readily

operable.

• Batteries (battery pack or batteries

installed) shall not be exposed to

excessive heat such as sunshine,

re or the like.

• Disconnect the product from the

power outlet before lightning

storms.

• When you disconnect the power

cord, always pull the plug, never the

cable.

• Use the product in tropical and/or

moderate climates.

Risk of short circuit or re!

• For identication and supply ratings,

see the type plate at the back or

bottom of the product.

• Before you connect the product to

the power outlet, ensure that the

power voltage matches the value

printed on the back or bottom of

the product. Never connect the

product to the power outlet if the

voltage is dierent.

Risk of injury or damage to this

product!

• For wall mounting, this product

must be securely attached to

the wall in accordance with the

installation instructions. Use only

the supplied wall mount bracket (if

available). Improper wall mounting

may result in accident, injury or

damage. If you have any query,

contact Consumer Care in your

country.

• Never place the product or any

objects on power cords or on other

electrical equipment.

• If the product is transported in

temperatures below 5°C, unpack

the product and wait until its

temperature matches room

temperature before connecting it to

the power outlet.

• Parts of this product can be made

of glass. Handle with care to avoid

injury and damage.

Risk of overheating!

• Never install this product in a

conned space. Always leave a

space of at least four inches around

the product for ventilation. Ensure

3EN

curtains or other objects never cover

the ventilation slots on the product.

Risk of contamination!

• Do not mix batteries (old and new

or carbon and alkaine, etc.).

• Danger of explosion if batteries are

incorrectly replaced. Replace only

with the same or equivalent type.

• Remove batteries if they are

exhausted or if the remote control is

not to be used for a long time.

• Batteries contain chemical

substances, they should be

disposed of properly.

Risk of swallowing batteries!

• The product/remote control may

contain a coin/button type battery,

which can be swallowed. Keep the

battery out of reach of children at

all times! If swallowed, the battery

can cause serious injury or death.

Severe internal burns can occur

within two hours of ingestion.

• If you suspect that a battery

has been swallowed or placed

inside any part of the body, seek

immediate medical attention.

• When you change the batteries,

always keep all new and

used batteries out of reach of

children. Ensure that the battery

compartment is completely secure

after you replace the battery.

• If the battery compartment cannot

be completely secured, discontinue

use of the product. Keep out of

reach of children and contact the

manufacturer.

This is CLASS II apparatus with double

insulation, and no protective earth

provided.

AC voltage

Use only the power supplies listed in

the user manual.

Care for your product

Use only microber cloth to clean the

product.

Care of the environment

Disposal of your old product and

battery

Your product is designed and

manufactured with high quality

materials and components, which can

be recycled and reused.

This symbol on a product means that

the product is covered by European

Directive 2012/19/EU.

This symbol means that the product

contains batteries covered by European

Directive 2013/56/EU which cannot be

disposed of with normal household

waste.

4EN

Inform yourself about the local separate

collection system for electrical and

electronic products and batteries.

Follow local rules and never dispose of

the product and batteries with normal

household waste. Correct disposal

of old products and batteries helps

prevent negative consequences for the

environment and human health.

Removing the disposable batteries

To remove the disposable batteries, see

battery installation section.

Compliance

This product complies with the radio

interference requirements of the

European Community.

Hereby, Gibson Innovations declares

that this product is in compliance with

the essential requirements and other

relevant provisions of Directive 1999/5/

EC. You can nd the Declaration of

Conformity on www.p4c.philips.com.

Help and support

For extensive online support, visit

www.philips.com/support to:

• download the user manual and the

quick start guide

• watch video tutorials (available only

for selected models)

• nd answers to frequently answered

questions (FAQs)

• email us a question

• chat with our support

representative.

Follow the instructions on the website

to select your language, and then enter

your product model number.

Alternatively, you can contact Consumer

Care in your country. Before you

contact, note down the model number

and serial number of your product. You

can nd this information on the back or

bottom of your product.

5EN

2 Your product

Congratulations on your purchase, and

welcome to Philips! To fully benet

from the support that Philips oers(e.g.

notication of product software

upgrade), register your product at

www.philips.com/welcome.

Main unit

This section includes an overview of the

main unit.

• Switch this product on or to

standby.

• When this product is in standby,

the standby indicator turns red.

Select an input source for this

product.

c +/- (Volume)

Increase or decrease volume.

d Display panel

e NFC tag

Tap the NFC-enabled device on the

tag for Bluetooth connection.

Remote control

This section includes an overview of the

remote control.

Switch this product on or to

standby.

6EN

b Source buttons

• HDMI ARC: Switch your source

to HDMI ARC connection.

• HDMI 1: Switch your source to

the HDMI IN 1 connection.

• HDMI 2: Switch your source to

the HDMI IN 2 connection.

• COAX: Switch your audio source

to the coaxial connection.

• OPTICAL: Switch your audio

source to the optical connection.

• AUDIO IN: Toggle audio source

between AUX and AUDIO IN

connection (3.5mm jack).

• USB: Switch to USB mode.

• : Switch to Bluetooth mode.

• : Select an input source for

this product.

c /

Skip to the previous or next track in

USB and Bluetooth mode.

Start, pause or resume play in USB

and Bluetooth mode.

e BASS +/-

Increase or decrease bass.

f Volume control

• +/-: Increase or decrease

volume.

• : Mute or restore volume.

g Sound mode control

• SMART: Automatically select a

predened sound mode to suit

your video or music.

• MUSIC: Select stereo sound

mode.

• VOICE: Select voice clarity

sound mode.

• MOVIE: Select surround sound

mode.

h HEIGHT +/-

Select a height eect level for Dolby

Atmos.

i AUDIO SYNC +/-

Increase or decrease audio delay.

j NIGHT

Turn night mode on or o.

k DIM

Set the brightness of the display

panel for this product.

Set clock or display clock.

m AUTO VOL.

Turn auto volume on or o.

n TREBLE +/-

Increase or decrease treble.

Connectors

This section includes an overview of the

connectors available on this product.

a HDMI OUT (ARC) - TO TV

Connect to the HDMI input on the

TV.

b HDMI IN1 / HDMI IN2

Connect to the HDMI output on a

digital device.

c USB

• Connect to a USB storage device

for audio media play.

• Upgrade software of this

product.

7EN

d DC IN

Connect to the power supply.

e AUDIO IN

Connect to an audio output on a

device via AUDIO IN or AUX source

(by pressing repeatedly AUDIO IN

on the remote control).

f OPTICAL IN

Connect to an optical audio output

on the TV or a digital device.

g COAXIAL IN

Connect to a coaxial audio output

on the TV or a digital device.

Wireless subwoofer

This product comes with a wireless

subwoofer.

a Connect (connect)

Press to to enter the pairing mode

for the subwoofer.

b Subwoofer indicator

• When the power is turned on,

the indicator lights up.

• During wireless pairing between

the subwoofer and the main

unit, the indicator blinks white

quickly.

• When the pairing succeeds, the

indicator lights up white.

• When the pairing fails, the

indicator blinks white slowly.

• When wireless connection is

disconnected for 1 minute, the

indicator turns o.

c AC MAINS~

Connect to the power supply.

8EN

3 Connect

This section helps you connect this

product to a TV and other devices.

For information about the basic

connections of this product and

accessories, see the quick start guide.

Note

• For identication and supply ratings, see

the type plate at the back or bottom of the

product.

• Before you make or change any

connections, make sure that all devices are

disconnected from the power outlet.

Placement

Place the subwoofer at least 1 meter

(3 feet) away from the main unit, and

10 centimeters (4 inches) away from the

wall.

For best results, place your subwoofer

as shown below.

10cm/4”

1m/3ft

Pair up with the

subwoofer

The wireless subwoofer automatically

pairs up with the main unit for wireless

connection when you turn on the main

unit and the subwoofer.

If no audio from the wireless subwoofer

can be heard, manually pair up the

subwoofer.

1 Turn on the main unit and the

subwoofer.

» If the connection to the main

unit is lost, the indicator on the

subwoofer blinks white slowly.

2 Press the CONNECT (connect)

button on the subwoofer to enter

the pairing mode.

» The indicator on the subwoofer

blinks white quickly.

3 In HDMI ARC mode (press HDMI

ARC), on the remote control, within

six seconds, press twice then

Volume + once, and then hold

down BASS +.

» If the pairing succeeds, the

indicator on the subwoofer lights

up white.

» If the pairing fails, the indicator

on the subwoofer blinks white

slowly.

4 If the pairing fails, repeat the steps

above.

Note

• If the wireless dis-connection or pairing up

lasts 1 minute, the subwoofer automatically

switches to standby and the LED on the

subwoofer turns o.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Intervenants

Philips

Philips SBCBA100/00 Manuel utilisateur

Philips

Philips AD6000W/10 Manuel utilisateur

Philips

Philips SPA7650/05 Manuel utilisateur

Philips

Philips SBCBC300/05 Manuel utilisateur

Philips

Philips Fidelio DS3800W/10 Manuel utilisateur

Philips

Philips HTL4110B Manuel utilisateur

Philips

Philips SB3300 Manuel utilisateur

Philips

Philips SBCBC735/00 Manuel utilisateur

Philips

Philips A2.310/25 Manuel utilisateur

Philips

Philips LSBS8000 Manuel utilisateur

Philips

Philips HTL2183B/93 Manuel utilisateur

Philips

Philips BT5580 Manuel utilisateur

Philips

Philips BTM2310/05 Manuel utilisateur

Philips

Philips AW9000 Manuel utilisateur

Philips

Philips SPA4270BT Manuel utilisateur

Philips

Philips SBC BP015 Manuel utilisateur

Philips

Philips SPA6350/10 Manuel utilisateur

Philips

Philips CSS2113/05 Manuel utilisateur

Philips

Philips 1000 Series Manuel utilisateur

Philips

Philips HTL2111A Manuel utilisateur

Philips

Philips SPA7355/77 Manuel utilisateur

Philips

Philips Fidelio DS3880W/10 Manuel utilisateur

Philips

Philips SBT30BLK/11 Manuel utilisateur

Philips

Philips BT7500B Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur

Philips fidelio b8 Manuel utilisateur

Manuels Intervenants populaires d'autres marques
