User manual

Always there to help you

BTM2280

Question?

Contact

Philips

1EN

Contents

1 Safety 2

Know these safety symbols 2

Important safety instructions 2

Hearing safety 3

2 Your micro music system 4

Introduction 4

What's in the box 4

Overview of the main unit 4

Overview of the remote control 5

3 Before use 7

Connect the FM antenna 7

Connect power 7

Install the remote control battery 7

4 Get started 8

Turn on 8

Set the clock 8

Select a source 8

Adjust the brightness of LCD display 9

5 Play from hard media 9

Play a disc 9

Play from a USB storage device 9

Control play 10

Program tracks 10

6 Use Bluetooth devices 11

Connect a device 11

Play audio via Bluetooth 11

Clear the pairing information 12

7 Listen to FM radio 12

Tune to an FM radio station 12

Program radio stations automatically 13

Program radio stations manually 13

Tune to a preset radio station 13

8 Adjust sound 13

Select a preset sound effect 13

Adjust volume level 13

Mute sound 13

9 Other features 14

Use the alarm timer 14

Use the sleep timer 14

Listen to an external device 15

Listen through headphone 15

Charge your USB device 15

10 Product information 16

Specications 16

USB playability information 17

Supported MP3 disc formats 17

Maintenance 17

11 Troubleshooting 18

12 Notice 19

Compliance 19

Care of the environment 20

Trademark notice 20

2EN

1 Safety

Read and understand all instructions before

you use this micro music system. If damage is

caused by failure to follow the instructions, the

warranty does not apply.

Know these safety symbols

This 'bolt of lightning' indicates uninsulated

material within your unit may cause an electric

shock. For the safety of everyone in your

household, please do not remove product

covering.

The 'exclamation mark' calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.

WARNING:Toreducetheriskofreorelectric

shock, this apparatus should not be exposed to

rainormoistureandobjectslledwithliquids,

such as vases, should not be placed on this

apparatus.

CAUTION:To prevent electric shock, fully

insert the plug. (For regions with polarized

plugs:To prevent electric shock, match wide

blade to wide slot.)

Important safety instructions

Risk of electric shock or re!

• Never expose the product and accessories

torainorwater.Neverplaceliquid

containers, such as vases, near the product.

Ifliquidsarespiltonorintotheproduct,

disconnect it from the power outlet

immediately. Contact Philips Consumer

Care to have the product checked before

use.

• Never place the product and accessories

nearnakedamesorotherheatsources,

including direct sunlight.

• Never insert objects into the ventilation

slots or other openings on the product.

• Where the mains plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

• Disconnect the product from the power

outlet before lightning storms.

• When you disconnect the power cord,

always pull the plug, never the cable.

Risk of short circuit or re!

• Before you connect the product to the

power outlet, make sure that the power

voltage matches the value printed on the

back of the product. Never connect the

product to the power outlet if the voltage

is different.

• Never expose the remote control or

batteries to rain, water, sunshine, or

excessive heat.

• Avoid force coming onto power plugs.

Loosepowerplugscancausearcingorre.

Risk of injury or damage to the product!

• Use only power supplies listed in the user

manual.

• Visible and invisible laser radiation when

open. Avoid exposure to beam.

• Do not touch the disc optical lens inside

the disc compartment.

• Never place the product or any objects

on power cords or on other electrical

equipment.

• If the product is transported in

temperatures below 5°C, unpack the

product and wait until its temperature

matches room temperature before

connecting it to the power outlet.

3EN

Risk of overheating!

• Neverinstallthisproductinaconned

space. Always leave a space of at least four

inches around the product for ventilation.

• Make sure that curtains or other objects

never cover the ventilation slots on the

product.

Risk of contamination!

• Remove the battery if it is exhausted or if

the remote control is not to be used for

an extended period of time.

• Batteries contain chemical substances, they

should be disposed of properly.

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never place this apparatus on other electrical

equipment.

•Keep this apparatus away from direct sunlight, naked

amesorheat.

•Never look into the laser beam inside this apparatus.

•Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect this apparatus from

the power.

Hearing safety

Listen at a moderate volume.

• Using headphones at a high volume can

impair your hearing.This product can

produce sounds in decibel ranges that may

cause hearing loss for a normal person,

even for exposure less than a minute.The

higher decibel ranges are offered for those

that may have already experienced some

hearing loss.

• Sound can be deceiving. Over time your

hearing 'comfort level' adapts to higher

volumes of sound. So after prolonged

listening, what sounds 'normal' can actually

be loud and harmful to your hearing.To

guard against this, set your volume to a safe

level before your hearing adapts and leave

it there.

To establish a safe volume level:

• Set your volume control at a low setting.

• Slowly increase the sound until you can

hear it comfortably and clearly, without

distortion.

Listen for reasonable periods of time:

• Prolonged exposure to sound, even

at normally 'safe' levels, can also cause

hearing loss.

• Besuretouseyourequipmentreasonably

and take appropriate breaks.

Be sure to observe the following guidelines

when using your headphones.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume as your

hearing adapts.

• Do not turn up the volume so high that

you can't hear what's around you.

• You should use caution or temporarily

discontinue use in potentially hazardous

situations.

Note

•The type plate is located on the back of the product.

4EN

2 Your micro

music system

Congratulations on your purchase, and

welcometoPhilips!Tofullybenetfromthe

support that Philips offers, register your product

at www.philips.com/welcome.

If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

rear of the apparatus.Write the numbers here:

Model No. __________________________

Serial No. ___________________________

Introduction

With this product, you can:

• enjoy audio from a disc or USB storage

device,

• enjoy audio from an external device via

Bluetooth,

• enjoy audio from an external device

through an audio input cable,

• listen to FM radio stations, and

• charge your USB devices.

What's in the box

Check and identify the contents of the package:

• Micro music system

• Remote control (with one AAA battery)

• AC power adaptor

• Wall mounting kit (2 dowels and 2 screws)

• FM antenna

• Safety sheet

• Short user manual

• Wall mounting instructions

Overview of the main unit

• Turn on the product.

• Switch the product to eco power

standby mode or normal standby

mode.

b SOURCE

• Press repeatedly to select a source.

Short User Manual

www.philips.com/welcome

Always there to help you

Question?

Contact

Philips

Wall Mounting

Instructions

www.philips.com/welcome

Always there to help you

Registeryour product and get support at

Question?

Contact

Philips

mnop

abcdef ghi

5EN

• Start, pause, or resume play.

• Stop the play of music.

• Connect a compatible USB storage

device for music play.

• Connect a compatible USB device for

charging.

f Disc compartment

• Press to eject the disc from the disc

compartment.

h /

• Skip to the previous or next track.

• Press and hold to search within a track.

• Tune to a radio station.

i VOL+/VOL-

• Increase or decrease the volume level.

j LED Indicator

• It lights red when the product is in eco

power standby mode.

• Indicate the Bluetooth connection

status.

k IR sensor

• Receive infrared signals from the

remote control.

l LCD screen

m DC IN

• Connect to the AC power adaptor.

• Connect to a headphone with 3.5-mm

connector.

o AUDIO IN

• Connect to the audio output socket

(usually the headphone socket) of an

external device.

p FM ANT

• Connect to the FM antenna.

Overview of the remote

control

• Turn on the product.

• Switch the product to eco power

standby mode or normal standby

mode.

• Eject the disc.

c CD

• Switch the source to the disc in the

disc compartment.

6EN

d FM/

• Switch the source to FM tuner or

the audio streamed from a Bluetooth

device.

e PRESET/ALBUM /

• Skip to the previous or next album.

• Select a preset radio station.

f /

• Skip to the previous or next track.

• Press and hold to search within a track.

• Tune to a radio station.

g + VOL -

• Increase or decrease the volume level.

• Stop the play of music.

i DISPLAY

• In working mode, press to display the

current time.

• In normal standby mode, press and

hold to adjust the brightness of LCD

display.

j MUTE

• Mute or restore volume.

k SOUND

• Select a preset sound effect.

l CLOCK

• Set the clock.

m TIMER/SLEEP

• Set the alarm timer.

• Set the sleep timer.

n PROG

• Program radio stations.

• Program tracks that are stored in a disc

or USB storage device.

o SHUFFLE

• Enableordisableshufeplayoftracks.

p REPEAT

• Select a repeat mode for tracks.

• Start, pause, or resume play.

r USB/AUDIO IN

• Switch the source to USB storage device

or the audio input that is transferred

through the AUDIO IN socket.

7EN

3 Before use

Connect the FM antenna

Note

•For optimal reception, fully extend the antenna and

adjust its position, or connect an outdoor antenna.

•This product does not support AM (amplitude

modulation) radio reception.

Connect the FM antenna to the product.

Connect power

Note

•Before you connect the AC power cord, make sure that

you have completed all other connections.

Connect the AC power adaptor between

• the DC IN socket on the back panel, and

• the power supply.

» blinks.

Install the remote control

battery

1 Open the battery compartment.

2 Insert one AAA battery with correct

polarity (+/-) as indicated.

3 Close the battery compartment.

DC IN

8EN

4 Get started

Caution

•Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

Turn on

Press .

» This product switches to the last selected

source.

Switch modes

Automatically switch the modes:

• After this product stays inactive for 15

minutes, it automatically switches to the

normal standby mode.

» The clock is displayed.

» If the clock is not set, blinks.

• After this product stays in the normal

standby mode for 15 minutes, it

automatically switches to the eco power

standby mode.

» scrolls, and then the

LCD screen lights off.

» The LED indicator beside the LCD

screen lights in red.

Manually switch the modes:

• Press and hold to switch this product

• from the working mode or normal

standby mode to the eco power

standby mode, or

• from the eco power standby mode to

the normal standby mode.

• Press to switch this product

• between the working mode and the

normal standby mode, or

• from the eco power standby mode to

the working mode.

Set the clock

Note

•During setting, if no action is made within 90 seconds,

the product exits clock setting without saving earlier

operations.

1 In standby mode, press and hold CLOCK

to enter the clock setting mode.

» or is displayed.

2 Press + VOL - or / to select

or , and then press CLOCK.

• : 24-hour time format

• : 12-hour time format

» The hour digits begin to blink.

3 Press + VOL -or / to set the hour,

and then press CLOCK.

» The minute digits begin to blink.

4 Press + VOL - or / to set the

minute, and then press CLOCK.

» The set clock is displayed.

Select a source

On the product, press SOURCE repeatedly to

select a source.

• : the audio streamed from a Bluetooth

device

• : the audio input through the

AUDIO IN socket

• : the disc in the disc compartment

• :.mp3lesstoredontheconnected

USB storage device

• : the FM tuner

Autres manuels pour BTM2280

Table des matières

Autres manuels Philips Système audio micro

Philips

Philips DCM276/55 Manuel utilisateur

Philips

Philips MCD183/98 Manuel utilisateur

Philips

Philips MC147/79 Manuel utilisateur

Philips

Philips MCM2300 Manuel utilisateur

Philips

Philips MCD137/98 Manuel utilisateur

Philips

Philips MCD139B/98 Manuel utilisateur

Philips

Philips DCB 2070 - Manuel utilisateur

Philips

Philips MCM277/12 Manuel utilisateur

Philips

Philips MCM2050/05 Manuel utilisateur

Philips

Philips DCM186B/79 Manuel utilisateur

Philips

Philips DCM105/61 Manuel utilisateur

Philips

Philips MCD122/12 Manuel utilisateur

Philips

Philips DualDock DCM3260 Manuel utilisateur

Philips

Philips DCM109/79 Manuel utilisateur

Philips

Philips BTD2336 Manuel utilisateur

Philips

Philips DCM3020/55 Manuel utilisateur

Philips

Philips MCB2305 Manuel utilisateur

Philips

Philips MCM2300 Manuel utilisateur

Philips

Philips BTB2515 Manuel utilisateur

Philips

Philips MCD355/98 Manuel utilisateur

Philips

Philips MC155/05 Manuel utilisateur

Philips

Philips DCM3100/12 Manuel utilisateur

Philips

Philips Harmony DCB8000 Manuel utilisateur

Philips

Philips DCM186/12 Manuel utilisateur

Manuels Système audio micro populaires d'autres marques

Rautz

Rautz MC-5100DU Manuel utilisateur

Sanyo

Sanyo DC-D9 Manuel utilisateur

Curtis

Curtis RCD744 Manuel utilisateur

Samsung

Samsung MM-UC8 Manuel utilisateur

Akai

Akai AMP300UCI Manuel utilisateur

Hyundai

Hyundai MS 132 DU3BL Manuel utilisateur

JVC

JVC UX-GP5 Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manuel utilisateur

Optimus

Optimus SYSTEM 731 Manuel utilisateur

Hitachi

Hitachi AXM209UK Manuel utilisateur

Sharp

Sharp XL-MP110DVD Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manuel utilisateur

ProAudio

ProAudio MC 9010 iP Manuel utilisateur

Samsung

Samsung MM-ZJ9 Manuel utilisateur

Sharp

Sharp MD-X7 Manuel utilisateur

Sharp

Sharp DK-KP95P Manuel utilisateur

Akura

Akura APTCDC832PR Manuel utilisateur

iLive

iLive IHB248B Manuel utilisateur
