Philips MCD297/12 Manuel utilisateur

USB/

MCD297

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

Composite Video Cable Remote control with

battery

MW antenna FM antenna

User Manual

Remove the plastic

protective sheet

MCD297 QUG_Eng 2008.6.24, 10:37 AM1

SPEAKER 4Ω

R L

FM aerial

75 Ω

LINE OUT

VIDEO OUT

VIDEO S-VIDEO

COAXIAL

SUB WOOFER

OUT

R L

MW aerial

–

AC power cord

FM wire

antenna

MW loop

antenna

Speaker

(right)

Speaker

(left)

Tip

See the User Manual for other TV

connection options.

Setting up the TV

Connect the speaker cables.

Connect the FM and MW antennas.

Connect the composite video cable to a TV.

Connect the power cords of the system and TV.

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correct Video In channel.

USB/USB/

AUDIO OUT

ATo listen to the sound of this DVD Player

through your TV, use the audio cables (white/

red-not supplied) to connect LINE OUT

(L/R) jacks of the DVD Player to the

corresponding AUDIO IN jacks on the TV.

B To listen to the sound of your TV through

this DVD player, use a cinch cable (not

supplied) to connect AUX-IN on the front

panel of the DVD player to the

corresponding AUDIO OUT jacks on the TV.

MCD297 QUG_Eng 2008.6.24, 10:37 AM2

Setting the clock

In standby mode, press and hold CLOCK on the system.

When the hour digits flash, turn the VOLUME -/+ control on the front panel or press

VOL +/- on the remote to set the hours.

Press CLOCK again and the minute digits flash.Then turn the VOLUME -/+ control on

the front panel or press VOL +/- on the remote to set the minutes.

Press CLOCK again to confirm the time setting.

Setting system menu options

Tip

See chapters "Preparations" and "System Menu Options" in the User

Manual for detailed descriptions.

USB/

LATIN

DIVX(R) VODDIVX(R) VOD

Important!

– To set clock in the Eco Power mode, press and hold ECO POWER/STANDBY ON on the set for 3 seconds

or more to switch to normal standby mode first before proceeding with the procedures below.

Before using the remote control

1 Pull out the plastic protective sheet.

2 Select the source you wish to control by pressing one of the source

select keys on the remote control (for example CD,TUNER).

3 Then select the desired function (for example ÉÅ , à, á)

Remove the plastic protective sheet

MCD297 QUG_Eng 2008.6.24, 10:37 AM3

Playing a disc

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROG/ANGLE for more than two seconds to program all available stations in

order of waveband.

Press PRESETí/ëuntil the desired preset station is displayed.

Press OPEN•CLOSE 0to open the disc tray and load in a disc, then press the same

button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press 9.

Insert the USB device’s USB plug into the socket on the front panel of the main set.

Press SOURCE (or USB/AUX on the remote control) once or more to select USB.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Play the USB’s audio files as you do with the albums/tracks on a CD.

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

PDCC-J.W.Wang 0746

CRoyal Philips Electronics N.V. 2007

http://www.philips.com

MCD297 QUG_Eng 2008.6.24, 10:37 AM4
