User manual

AZB200

1EN

Contents

1 Important 2

Safety 2

Notice 3

2 Your CD Soundmachine 4

Introduction 4

What's in the box 4

Overview of the main unit 5

3 Get started 6

Connect power 6

Power on 7

4 Play 8

Play from disc 8

Control play 8

Skip tracks 8

Program tracks 8

5 Listen to the radio 9

Listen to DAB+ radio 9

Listen to FM radio 10

6 Other features 11

Listen to an external device 11

7 Product information 12

Specications 12

8 Troubleshooting 13

2EN

1 Important

Safety

Read and understand all instructions

before you use this micro music system.

If damage is caused by failure to follow

the instructions, the warranty does not

apply.

This 'bolt of lightning' indicates

uninsulated material within the device

may cause an electrical shock. For the

safety of everyone in your household,

please do not remove the covering.

The 'exclamation mark' calls attention to

features for which you should read the

enclosed literature closely to prevent

operating and maintenance problems.

WARNING: To reduce the risk of re or

electric shock, the device should not be

exposed to rain or moisture and objects

lled with liquids, such as vases, should

not be placed on the device.

CAUTION: To prevent electric shock,

fully insert the plug. (For regions with

polarized plugs: To prevent electric

shock, match wide blade to wide slot.)

Warning

•Never remove the casing of this apparatus.

•Never lubricate any part of this apparatus.

•Never look into the laser beam inside this

apparatus.

•Never place this apparatus on other

electrical equipment.

•Keep this apparatus away from direct

sunlight, naked ames or heat.

•Ensure that you always have easy access

to the power cord, plug or adaptor to

disconnect the apparatus from the power.

• Make sure that there is enough

free space around the product for

ventilation.

• Only use attachments/accessories

specied by the manufacturer.

• Battery usage CAUTION – To

prevent battery leakage which may

result in bodily injury, property

damage, or damage to the product:

• Install all batteries correctly, +

and - as marked on the unit.

• Batteries (packed or installed)

shall not be exposed to

excessive heat such as sunshine,

re or the like.

• Remove batteries when the unit

is not used for a long time.

• The product shall not exposed to

dripping or splashing.

• Do no place any source of danger

on the product (e.g. liquid lled

objects. lit candles).

• Where the MAINS plug or an

appliance coupler is used as the

disconnect device, the disconnect

device shall remain readily

operable.

3EN

Notice

to this device that are not expressly

approved by MMD Hong Kong Holding

Limited may void the user’s authority to

operate the equipment.

Compliance

Hereby, MMD Hong Kong Holding Limited

declares that this product is in compliance

with the essential requirements

and other relevant provisions of

Declaration of Conformity on www.

philips.com/support.

Care of the environment

Disposal of your old product and

battery

Your product is designed and

manufactured with high quality

materials and components, which can

be recycled and reused.

This symbol on a product means that

the product is covered by European

Directive 2012/19/EU.

This symbol means that the product

contains batteries covered by European

Directive 2013/56/EU which cannot be

disposed of with normal household

waste.

Inform yourself about the local separate

collection system for electrical and

electronic products and batteries.

Follow local rules and never dispose of

the product and batteries with normal

household waste. Correct disposal

of old products and batteries helps

prevent negative consequences for the

environment and human health.

Removing the disposable batteries

To remove the disposable batteries, see

battery installation section.

Environmental information

All unnecessary packaging has been

omitted. We have tried to make the

packaging easy to separate into three

materials: cardboard (box), polystyrene

protective foam sheet.)

Your system consists of materials

which can be recycled and reused

if disassembled by a specialized

company. Please observe the local

regulations regarding the disposal

of packaging materials, exhausted

batteries and old equipment.

The making of unauthorized copies

of copy-protected material, including

and sound recordings, may be an

infringement of copyrights and

equipment should not be used for such

purposes.

Care for your product

•Do not insert any objects other than

discs into the disc compartment.

•Do not insert warped or cracked

discs into the disc compartment.

4EN

• Remove the discs from the disc

compartment if you are not using

the product for an extended period

of time.

• Only use microber cloth to clean

the product.

This apparatus includes this label:

Note

•The type plate is located on the back of the

product.

2 Your CD

Soundmachine

Congratulations on your purchase,

and welcome to Philips! To fully

benet from the support that Philips

oers, register your product at

www.philips.com/support.

Introduction

With this unit, you can:

• enjoy audio from CDs, and other

external devices;

• listen to FM and and Digital Audio

Broadcasting+ (DAB+) radio

The unit supports these media formats:

What's in the box

Check and identify the contents of your

package:

• Main unit

• 1 x AC power adapter

• Printed materials

5EN

• Connect external audio devices.

b Source selector

• Select a source: , , or

• Switch this product o.

c jack

• Connect to the supplied power

adapter.

• Adjust volume.

e ( / )

• Select a preset radio station.

• Select shue mode to play

tracks randomly.

• Select repeat mode to play a

track or all tracks repeatedly.

Overview of the main unit

6EN

• Program tracks.

• Program radio stations.

• Auto store radio stations.

• Stop play or erase a program.

• Enter or exit DAB+ menu.

• Display playback information, or

radio service information.

• Press to start, pause, or resume

play.

• Conrm or select a DAB+ option.

i Display panel

• Display current status.

• Skip to the previous/next track.

• Search within a track/disc.

• Tune to an FM station.

• Select a DAB+ station.

k Battery compartment

l Radio antenna

• Improve radio reception.

3 Get started

Caution

•Use of controls or adjustments or

performance of procedures other than

herein may result in hazardous radiation

exposure or other unsafe operation.

Always follow the instructions in this

chapter in sequence.

Connect power

This product can be powered by either

AC power or batteries.

Option 1: AC power

Caution

•Risk of product damage! Ensure that the

power supply voltage corresponds to

the voltage printed on the back or the

underside of the unit.

•Risk of electric shock! Before you plug

the AC power adaptor, make sure that the

adaptor plug converter is xed securely.

When you unplug the AC power adaptor,

always pull the plug, never the cord.

•Before you connect the AC power adaptor,

make sure that you have completed all the

other connections.

DC 9V

7EN

Connect the power cable to the wall

socket.

Option 2: Battery power

Batteries are not supplied with the

accessories.

1 Open the battery compartment.

2 Insert 6 batteries (type: R-14 or C

CELL) with correct polarity (+/-) as

indicated.

3 Close the battery compartment.

Power on

Push the source selector to , , or

» The selected source is displayed.

Switch o

Push the source selector to .

» is displayed briey.

Note

•The product switches to standby mode

after 15 minutes inactive.

•To power on again after switch-o,

make sure that is no longer

displayed.

4 Play

Play from disc

1 Push the source selector to .

2 Lift up the cover to open the disc

compartment.

3 Insert a disc with the label side up.

4 Close the disc compartment.

• Play starts automatically. If not,

press .

Control play

Start, pause, or resume play.

Stop play.

(

/ )

Play a track or all tracks

repeatedly.

Play tracks randomly.

/ Press to skip to the previous

or next track.

Press and hold to search

backward/forward within a

track.

Increase or decrease the

volume.

Show playback information.

8EN

Skip tracks

Press / to select tracks.

Program tracks

This function allows you to program

20 tracks in the desired sequence.

1 In stop mode, press to

activate the program mode.

» is displayed.

2 Press / to select a track, and

then press to conrm.

3 Repeat steps 2 to 3 to program

more tracks.

4 Press to play the programmed

tracks.

To erase the program

Press twice.

5 Listen to the

radio

With this product, you can listen to DAB

+ radio and FM radio.

Note

•Position the antenna as far as possible

from TV, or other radiation source.

•For optimal reception, fully extend and

adjust the position of the antenna.

Listen to DAB+ radio

Digital Audio Broadcasting+ (DAB+) is

a way of broadcasting radio digitally

through a network of transmitters. It

provides you with more choice, better

sound quality and more information.

Store DAB+ radio stations

automatically

Note

•New stations and services are added in

DAB+ broadcast from time to time. To make

new DAB+ stations and services available,

perform scan regularly.

1 Push the source selector to to

select DAB+ source.

• If you enter DAB+ source for the

rst time or no DAB+ service is

stored, is

prompted, then press

to trigger scan, and skip step 2

below.

9EN

2 Press and hold for

more than 2 seconds.

» The product scans and

stores all DAB+ radio stations

automatically.

» After scan, the rst available

station is broadcast.

Select a DAB+ radio station

After DAB+ radio stations are scanned

and stored, press / to select a

DAB+ station.

Store DAB+ radio stations

manually

1 Press / to select a DAB+ radio

station.

2 Press to activate

program mode.

3 Press to allocate a

number from 1–20 to this radio

station, and then press

to conrm.

4 Repeat steps 1-3 to program more

stations.

To select a preset DAB+ radio station:

In DAB+ mode, press .

Use DAB+ menu

1 In DAB+ mode, press to

access DAB+ menu.

2 Press to toggle the

menu options, then press to

select an option.

• (scan): Scan and store all

available DAB+ radio stations.

• (manual): Tune to a

DAB+ station manually.

• (dynamic range control):

Compress sound dynamics in

dierent levels.

• (prune): Remove invalid

stations from the station list.

• (system): Adjust

system settings.

3 If a sub-option is available, repeat

step 2.

• To return to the previous menu,

press .

• To exit the menu, press

again.

Under (system) menu

• (reset): reset all settings

to factory default.

• (software version):

show the software version of this

unit.

Display DAB+ information

While listening to DAB+ radio, press

repeatedly to display

various information (if available), such

as frequency, signal strength, time, etc.

Listen to FM radio

Tune to an FM radio station

1 Push the source selector to to

select FM source.

2 Press and hold / for more

than 2 seconds.

» The radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more

stations.

To tune to a weak station:

Press / repeatedly until you nd

optimal reception.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Système audio micro

Philips

Philips MZ110037 Manuel utilisateur

Philips

Philips MCD1060 Manuel utilisateur

Philips

Philips MCD712/12 Manuel utilisateur

Philips

Philips MCM204/96 Manuel utilisateur

Philips

Philips MC108C/05 Manuel utilisateur

Philips

Philips MCD750/93 Manuel utilisateur

Philips

Philips MCM2250 Manuel utilisateur

Philips

Philips DCM3120 Manuel utilisateur

Philips

Philips MCD1165 Manuel utilisateur

Philips

Philips MCM2300 Manuel utilisateur

Philips

Philips MCD183 Manuel utilisateur

Philips

Philips MCM206/12 Manuel utilisateur

Philips

Philips MCM119/05B Manuel utilisateur

Philips

Philips MCM2300 Fiche d'information produit

Philips

Philips DCM292 Manuel utilisateur

Philips

Philips MCD288/05 Manuel utilisateur

Philips

Philips MCM2350 Manuel utilisateur

Philips

Philips DCM276 Manuel utilisateur

Philips

Philips MC156/22 Manuel utilisateur

Philips

Philips MCD710/79 Manuel utilisateur

Philips

Philips MCM103B/77 Manuel utilisateur

Philips

Philips MCM1110/12 Manuel utilisateur

Philips

Philips MCD122/98 Manuel utilisateur

Philips

Philips BTM2355 Manuel utilisateur

Manuels Système audio micro populaires d'autres marques

Rautz

Rautz MC-5100DU Manuel utilisateur

Sanyo

Sanyo DC-D9 Manuel utilisateur

Curtis

Curtis RCD744 Manuel utilisateur

Samsung

Samsung MM-UC8 Manuel utilisateur

Akai

Akai AMP300UCI Manuel utilisateur

Hyundai

Hyundai MS 132 DU3BL Manuel utilisateur

JVC

JVC UX-GP5 Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Beat Bot 6000 Manuel utilisateur

Optimus

Optimus SYSTEM 731 Manuel utilisateur

Hitachi

Hitachi AXM209UK Manuel utilisateur

Sharp

Sharp XL-MP110DVD Manuel utilisateur

Tiger Electronics

Tiger Electronics Hitclips Micro Music Watch 59947 Manuel utilisateur

ProAudio

ProAudio MC 9010 iP Manuel utilisateur

Samsung

Samsung MM-ZJ9 Manuel utilisateur

Sharp

Sharp MD-X7 Manuel utilisateur

Sharp

Sharp DK-KP95P Manuel utilisateur

Akura

Akura APTCDC832PR Manuel utilisateur

iLive

iLive IHB248B Manuel utilisateur
