Philips MCD130/96 Manuel utilisateur

MCD130

EN User manual 3

ZH-TWԚʹ˫23

www.philips.com/welcome

English

Contents

1 Important 4

Safety 4

2 Your DVD Micro Theater 6

Introduction 6

What's in the box 6

Overview of the main unit 7

Overview of the remote control 8

3 Connect 9

Place the unit 9

Connect speakers 9

Connect video cables 10

Connect audio cables 11

Connect power 11

4 Get started 11

Prepare the remote control 11

Turn on 12

Find correct viewing channel 12

Select the correct TV system 12

Change system menu language 12

5 Play 13

Play a disc 13

Play from USB 14

Play mixed contents 14

Play control 14

6 Adjust settings 16

General setup 16

Video setup 16

Sound 17

Preference 17

7 Product information 18

 

8 Troubleshooting 19

9 Notice 20

4EN

1 Important

Safety

Know these safety symbols

This 'bolt of lightning' indicates uninsulated

material within your unit may cause an electrical

shock. For the safety of everyone in your

household, please do not remove product

covering.

The 'exclamation point' calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.



shock, this apparatus should not be exposed to



such as vases, should not be placed on this

apparatus.

CAUTION:To prevent electric shock, match

wide blade of plug to wide slot, fully insert.

Important Safety Instructions

 Follow all instructions.

 Heed all warnings.

 Do not use this apparatus near water.

 Clean only with dry cloth.

 Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

 Do not install near any heat sources such

as radiators, heat registers, stoves, or



produce heat.

 Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

 

by the manufacturer.

 Use only with the cart, stand, tripod,



manufacturer or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination to

avoid injury from tip-over.

 Unplug this apparatus during lightning

storms or when unused for long periods

of time.

 



the apparatus has been damaged in any

way, such as power-supply cord or plug



objects have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

 Battery usage CAUTION –To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

 Install all batteries correctly, + and - as

marked on the unit.

 Do not mix batteries (old and new or



 Remove batteries when the unit is not

used for a long time.

English

 Apparatus shall not be exposed to

dripping or splashing.

 Do not place any sources of danger on the





 Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

Warning

 Never remove the casing of this apparatus.

 Never lubricate any part of this apparatus.

 Never place this apparatus on other electrical



 Keep this apparatus away from direct sunlight, naked



 Never look into the laser beam inside the apparatus.

 Ensure that you always have easy access to the power

cord, plug or adapter to disconnect the apparatus from

the power.

Caution

 Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

6EN

2 Your DVD

Micro Theater

Congratulations on your purchase, and



support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With this apparatus, you can:

 Watch video from DVD/VCD/SVCD, or

USB storage devices

 Enjoy audio from discs, or USB storage

devices

 View pictures from discs or USB storage

devices

The apparatus supports these media/disc

formats:

You can play DVD discs marked with the

following region code:

DVD region code Countries

Taiwan

What's in the box

Check and identify the contents of your

package:

 Main unit

 2 speakers

 

 

 Ferrite core

 User manual

English

Overview of the main unit

a Disc compartment

b IR sensor

 Stop play.

 Turn on the unit.

 Switch to standby mode.

 Start or pause play.

f Volume knob

 Adjust volume.

DVD MICRO THEATER MCD130

 USB socket.

h /

 Skip to the previous/next track.

 Search within a track/disc/USB.

i Display panel

 Display current status.

 Open or close the disc compartment.

k COMPONENT VIDEO CABLE

 Connect component video cables.

8EN

l AUDIO OUT

 Connect audio cables.

m VIDEO

 connect video cable.

n SPEAKER

 Connect speakers.

Overview of the remote

control

a DISC MENU

 Access the disc menu.

b /

 Navigate the menus.

 Slow forward or backward.

 Flip the picture vertically or

horizontally.

c /

 Navigate the menus.

 Fast forward or backward.

 rotate a picture clockwise or counter-

clockwise during slideshow.

 Press repeatedly to change a search

speed.

d BACK

 Return to a previous display menu.

e /

 Skip to the previous or next track,



f SUBTITLE

 Select a subtitle language.

g DISC/USB

 Access the main menu of the disc.

h REPEAT/REPEAT A-B

 Select a repeat play option.

i AUDIO

 Select an audio language or channel.

j VOL +/-

 Adjust volume

 Start or pause play.

 Stop play.

m OK

 

n OPTIONS

 For CD: enter into GOTO option.

 During video play, enter into GOTO,

Zoom, and so on.

English

 Access the home menu.

p MUTE

 Mute or restore volume.

 Turn on the unit.

 Switch to standby mode.

3 Connect

Place the unit

1 Place the DVD micro theater near TV.

2 

distance from the TV and at an angle

of approximately 45 degrees from the

listening position.

Note

 To avoid magnetic interference or unwanted noise,

never place this apparatus and speakers too close to

any radiation devices.

 Place this unit on top of a table or mount it on the wall.

 Never place this unit in an enclosed cabinet.

 Install this unit near the AC outlet where the AC power

plug can be easily reached.

Connect speakers

Note

 Ensure that the colors of the speaker wires and

terminals are matched.

 For optimal sound, use the supplied speakers only.

 Connect only speakers with impedance that is the

same or higher than the supplied speakers. Refer to the



10 EN

1 

2 Insert the stripped part of the wire

completely.

 Insert the right speaker wires to "R",

left speaker wires to "L".

 Insert the red wires to "+", black wires

to "-".

3 

Connect video cables

You can select the best video connection that

your TV supports.

 Option 1: Connect through a composite



 Option 2: Connect through component

video cables (for a standard TV or



abc

Option 1: Connect through a

composite video cable



 the VIDEO socket on the back of the

unit.

 the video input socket on the TV.

Option 2: C onnect through

component video cables

Note

 

when a progressive scanTV is connected.

 If yourTV does not support progressive scan, you

cannot view the picture.

 For how to activate progressive scan on your TV, refer

to the TV user manual.

Connect a progressive scanTV through



Connect component video cables (red/blue/



 the component (Pr,Pb, and Y) sockets

on the back of the unit.

 the component input sockets on theTV.

LPb

COMPONENT VIDEO INPUT

Pb/CbPr/Cr Y

LPb

VIDEO

VIDEO IN

English

Connect audio cables

You can route the audio from this product to

other devices.

Connect the audio cables to:

 the AUDIO OUT jacks on this unit.the

AUDIO input jacks on the device.

Connect power

Caution

 Risk of product damage! Ensure that the power supply

voltage corresponds to the voltage printed on the back

or the underside of the unit.

 Before connecting the AC power cord, ensure you have

completed all other connections.

Connect the AC power cord to the wall outlet.

LPb

AUDIO OUT

L LINE IN R

4 Get started

Caution

 Use of controls or adjustments or performance of

procedures other than herein may result in hazardous

radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in



If you contact Philips, you will be asked for the

model and serial number of this apparatus.The

model number and serial number are on the

bottom of the apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Prepare the remote control

Caution

 Risk of explosion! Keep batteries away from heat,



To insert the remote control battery:

1 Open the battery compartment.

2 



3 Close the battery compartment.
