Philips HQ8100/16 Manuel utilisateur

HQ8100

ENGLISH 4

DEUTSCH 13

ESPAÑOL 22

FRANÇAIS 31

ITALIANO 40

NEDERLANDS 49

PORTUGUÊS 58

TÜRKÇE 67

Important

Read this user manual carefully before you use the

appliance and save it for future reference.

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience

and knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure that they

do not play with the appliance.

Only use the powerplug supplied.

The powerplug transforms 100-240 volts to a safe

low voltage of less than 24 volts.

The powerplug contains a transformer. Do not cut

off the powerplug to replace it with another plug,

as this causes a hazardous situation.

Do not use a damaged powerplug.

If the powerplug is damaged, always have it

replaced with one of the original type in order to

avoid a hazard.

Make sure the powerplug does not get wet.

Store the appliance at a temperature between

15°C and 35°C.

Always unplug the shaver before you clean it

under the tap.

The shaver complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

Be careful with hot water.Always check if the water

is not too hot, to prevent your hands from getting

burnt.

This washable shaver is not suitable for shaving in

the shower.

ENGLISH

Do not immerse the shaver in water.

Water may leak from the socket at the bottom

of the appliance, when you rinse it.This is normal

and not dangerous because all electronics are

enclosed in a sealed shell inside the shaver.

Electromagnetic elds (EMF)

This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.

Using the appliance

1 Put the appliance plug in the shaver.

2 Put the powerplug in the wall socket.

Shaving

1 Switch the shaver on by pressing the on/off

button once.

The green light ring round the on/off button goes on

to indicate that the motor is running.

ENGLISH 5

2 Move the shaving heads quickly over your skin,

making both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

3 Switch the shaver off by pressing the on/off

button once.

The green light ring around the on/off button goes

out.

4 Clean the shaver (see chapter ‘Cleaning and

maintenance’).

5 Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

1 Open the trimmer by pushing the slide

downwards.

The trimmer can be activated while the motor is

running.

2 Close the trimmer (‘click’).

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

ENGLISH6

The normal way to clean the appliance is to rinse

the shaving unit and the hair chamber with hot

water every time you have used the shaver.

Be careful with hot water.Always check if the

water is not too hot, to prevent your hands from

getting burnt.

Note:Water may leak from the socket at the bottom of

the appliance when you rinse it.This is normal and not

dangerous.

Every day: shaving unit and hair chamber

1 Switch the shaver off, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

2 Press the release button to open the shaving

unit.

3 Clean the shaving unit and the hair chamber by

rinsing them under a hot tap for some time.

Make sure you clean the inside as well as the

outside of the shaving unit.

4 Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue,

as this may damage the shaving heads.

ENGLISH 7

5 Open the shaving unit again and leave it open

to let the appliance dry completely.

You can also clean the hair chamber without water

by using the brush supplied.

Every six months: shaving heads

1 Open the shaving unit, turn the lock

anticlockwise (1) and remove the retaining

frame (2).

2 Clean the cutters and guards with the brush

supplied.

Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it

may take several weeks before optimal shaving

performance is restored.

3 Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit and turn the lock clockwise.

4 Close the shaving unit.

Trimmer

Clean the trimmer every time you have used it.

1 Switch the shaver off, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

ENGLISH8

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.

Storage

Put the protection cap on the shaver to prevent

damage.

The appliance can be stored in the pouch

supplied.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with HQ9

Philips shaving heads only.

Note: Do not mix up the cutters and the guards to

guarantee optimal shaving performance.

1 Switch the shaver off, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

2 Press the release button to open the shaving

unit.

ENGLISH 9

3 Turn the lock anticlockwise (1) and remove the

retaining frame (2).

4 Remove the shaving heads and place new ones

in the shaving unit. Put the retaining frame

back into the shaving unit and turn the lock

clockwise.

Make sure that the projections of the shaving

heads t exactly into the recesses.

5 Close the shaving unit.

Accessories

The following accessories are available:

HQ8500/HQ8000 powerplug.

HQ9 Philips Shaving Heads.

HQ110 Philips Shaving Head Cleaning Spray.

Environment

Do not throw away the appliance with the normal

household waste at the end of its life, but hand

it in at an ofcial collection point for recycling. By

doing this, you help to preserve the environment.

ENGLISH10

Guarantee & service

If you need information or if you have a problem,

please visit the Philips website at www.philips.com

or contact the Philips Customer Care Centre

in your country (you nd its phone number in

the worldwide guarantee leaet). If there is no

Customer Care Centre in your country, go to

your local Philips dealer or contact the Service

Department of Philips Domestic Appliances and

Personal Care BV.

Guarantee restrictions

The shaving heads (cutters and guards) are not

covered by the terms of the international guarantee

because they are subject to wear.

Troubleshooting

1 Reduced shaving performance.

Cause 1: the shaving heads are dirty.The shaver

has not been rinsed long enough or the water

used was not hot enough.

Clean the shaver thoroughly before you continue

shaving. See chapter ‘Cleaning and maintenance’.

Cause 2: long hairs are obstructing the shaving

heads.

Clean the cutters and guards with the brush

supplied. See chapter ‘Cleaning and maintenance’,

section ‘Every six months: shaving heads’.

Cause 3: the shaving heads are damaged or worn.

Replace the shaving heads. See chapter

‘Replacement’.

2 The shaver does not work when the on/off

button is pressed.

Cause: the appliance is not connected to the

mains.

ENGLISH 11

Put the powerplug in the wall socket.

3 The shaving unit has come off the shaver.

The shaving unit has not been placed correctly.

If the shaving unit becomes detached from the

shaver, you can easily put it back by inserting the

hinge into the slot in the rim of the hair chamber

and pushing it home until it locks into place

(‘click’).

ENGLISH12
