Philips HQ6735/01 Manuel utilisateur

ENGLISH 4

FRANÇAIS 18

ESPAÑOL 32

PORTUGUÊS 47

HQ6735

á«Hô©dG

ENGLISH4

Introduction

The shaver comes with two different kinds of

NIVEA FOR MEN cartridges:Extra Fresh Shaving

Gel for a fresh sensation during and after shaving

and Moisturising Shaving Lotion for sensitive skin.

This gives you the opportunity to try them out

and discover which one suits your skin type best.

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the HQ600 powerplug and the

charging stand supplied to charge the shaver.

◗Only the powerplug supplied guarantees

safety.

◗The HQ600 powerplug transforms 100-240

volts to a safe low voltage of less than

24 volts.

◗The powerplug contains a transformer.Do

not cut off the powerplug to replace it with

another plug,as this will cause a hazardous

situation.

C◗Never immerse the charging stand in water

nor rinse it under the tap when the charging

stand is plugged in.

C◗The shaver runs at a safe low voltage of less

than 24 volts.It is watertight and can be

cleaned under the tap.Rinse the shaver with

hot water.

Be careful with hot water.Always check if the

water isn't too hot,to prevent your hands from

burning.

◗Do not leave the charging stand with the

shaver in it plugged into the mains

continuously.

◗Check if the gel and lotion supplied with the

appliance contain ingredients (see back of

cartridge) to which you are allergic before

you start using the appliance.Do not use the

gel and/or lotion if you are allergic to one or

more ingredients!

◗If the mains cord of this appliance is damaged,

it must always be replaced by Philips or a

service centre authorised by Philips in order

to avoid hazardous situations.

Charging

Charge indications

C◗As soon as you start charging the empty

shaver,the green pilot light goes on.

◗The red pilot light blinks when the batteries

are almost empty.

◗When the batteries are almost empty,the red

pilot light blinks a few times after the shaver

has been switched off.

ENGLISH 5

ENGLISH6

Charging the appliance

Recharge,store and use the appliance at a

temperature between 5cC and 35cC.

1Insert the small plug into the charging

stand and put the powerplug in the wall

socket.

C2Place the shaver in the charging stand.

C3Press until you hear a click.

The shaver automatically switches off when

placed in the charging stand.

4When charging for the first time or after a

long period of disuse:leave the shaver to

charge continuously for 24 hours.

Charging normally takes approx.8 hour.

A fully charged shaver has a cordless shaving time

of up to approx.40 minutes.

Inserting the cartridge

Cartridges with moisturising NIVEA FOR MEN

shaving gel/lotion are available in boxes containing

five cartridges and one small plastic pump.

Do not throw the pump away when you replace

an empty cartridge.You will need it for all five

cartridges.

ENGLISH 7

One Philishave NIVEA FOR MEN Cool Skin

cartridge contains enough gel/lotion for approx.

10 shaves.

Remove the shaving gel/lotion cartridge from the

appliance when you are not going to use the

shaver for more than one week.

Use only Philishave NIVEA FOR MEN Cool Skin

(HQ160 or HQ161) cartridges.

For hygienic reasons,we advise you to insert a

new pump when you start using a new set of five

cartridges.

When you have run out of shaving gel/lotion

cartridges and you do not know where to buy

them,contact the Customer Care Centre in your

country (see 'Guarantee & service').

Inserting the cartridge

C1Take one cartridge from the box.Take the

pump (supplied in the same box) out of its

bag and push it into the cartridge until it

locks into position with a click.

C2Move the release slide downwards and

open the cover of the cartridge

compartment.

ENGLISH8

C3Slide the cartridge with the pump into the

shaver.It only fits properly if the white side

of the pump is pointing upwards.

4Close the cover (you will hear a click).

5Press the yellow pump button a few times

until the NIVEA FOR MEN shaving

emulsion appears.The shaver is now ready

for use.

BThe NIVEA FOR MEN shaving gel/lotion in the

cartridges will keep for 32 months when stored at

temperatures between 0cC and +40cC.

Using the appliance

Shaving

Switching on the shaver.

1Switch the shaver on by pressing the on/off

button once.

C2Press the yellow pump button to apply

NIVEA FOR MEN shaving gel/lotion to

your skin.

3Move the shaving heads over your skin,

making both straight and circular

movements.

4While shaving,press the pump button

frequently to apply more NIVEA FOR

MEN shaving gel/lotion so that the shaver

keeps gliding smoothly over your face.

Do not press the shaver too hard against your

skin while shaving.If you prefer,you can wet your

face before shaving.

◗When you have run out of shaving emulsion,

you can also use the shaver without it on a

dry face.

The shaver will not perform optimally when used

without shaving gel/lotion.

◗Your skin may need 2-3 weeks to get

accustomed to the Philishave system.

Switching of the shaver

1Switch the shaver off.

C2Put the protection cap on the shaver every

time you have used it,to prevent damage.

Remove the cartridge and clean the shaver if you

are not going to use the appliance for more than

one week.Rinse the shaver after each shave.

Trimming

The shaver has a separate trimmer for grooming

sideburns and moustache.

1Switch the shaver off.

Clean the shaver before you attach the trimmer.

ENGLISH 9

C2Press the release button to open the

shaving unit and pull the shaving unit off

the shaver.

C3Tilt the trimmer slightly backwards and fit

it onto the shaver.

4Remove the trimmer by pressing the

release button again and pulling the

trimmer off the shaver.

Cleaning and maintenance

Shaving unit

Rinse the shaving unit and the hair chamber with

hot water (60cC - 80cC) after every use.

1Switch the shaver off.

C2Press the release button to open the

shaving unit.

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

for some time.

Never dry the shaving unit with a towel or tissue

as this may damage the shaving heads.

ENGLISH10

C4Rinse the outside of the shaver.

Make sure the inside of the shaving unit and the

hair chamber have been cleaned properly.Close

the shaving unit and shake off excess water.

Charging stand

1Unplug the charging stand.

2Clean the charging stand with a moist

cloth.

Trimmer

1Clean the outside of the trimmer with the

brush supplied after every use.

C2Open the trimmer to clean it on the

inside.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

1Switch the shaver off.

ENGLISH 11

OIL

C2Press the release button to open the

shaving unit.

C3Turn the wheel anticlockwise and remove

the retaining frame.

C4Remove the shaving heads and place the

new ones in the shaving unit.

C5Put the retaining frame back onto the

shaving unit,press the wheel and turn it

clockwise.

Replace damaged or worn shaving heads with

Philishave HQ167 Cool Skin shaving heads only.

Storage

C◗After cleaning,the wet shaver can be placed in

the charging stand.

◗The appliance and the trimmer can be stored

in the pouch or cassette supplied.Whether

you have a pouch or a cassette depends on

your type of shaver.

ENGLISH12
