Philips HQ9190CC2 Manuel utilisateur

HQ9190CC2

ENGLISH 4

DEUTSCH 23

ESPAÑOL 44

FRANÇAIS 65

ITALIANO 84

NEDERLANDS 104

PORTUGUÊS 124

TÜRKÇE 144

Important

Read these instructions for use carefully before using

the appliances and save them for future reference.

Only use the powerplug supplied.

The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

The powerplug contains a transformer. Do not

cut off the powerplug to replace it with another

plug, as this will cause a hazardous situation.

Do not use a damaged powerplug.

If the powerplug is damaged, always have it

replaced by one of the original type in order to

avoid a hazard.

Make sure the powerplug does not get wet.

Charge and store the shaver at a temperature

between 5 cC and 35 cC.

Do not recharge the shaver in a closed pouch.

Always unplug the shaver before cleaning it

under the tap.

The shaver complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

Be careful with hot water.Always check if the

water is not too hot, to prevent your hands

from getting burnt.

Only use the washing machine with the original

HQ200 cleaning uid.

Empty the cleaning chamber and clean it

thoroughly by rinsing it with hot tap water every

15 days.

The washing machine thoroughly cleans but does

not disinfect your shaver, therefore do not share

the shaver with others.

ENGLISH

Never immerse the washing machine in water

nor rinse it under the tap.

Keep the washing machine out of the reach of

children.

Use and store the washing machine at a

temperature between 5 cC and 35 cC.

Always place the washing machine on a stable,

level and horizontal surface to prevent leakage.

When the washing machine is ready for use,

it must not be moved to prevent leakage of

cleaning uid.

The display

This appliance offers you the unique possibility to

choose the display layout you prefer: a number

layout or a battery symbol layout.

1 Press the on/off button approx. 3 seconds to

enter the menu.

The menu has three different modes: the travel lock

mode and two display layout modes.

You will enter the menu in the travel lock mode,

indicated by a rotating key symbol.

You can scroll through the three modes (travel

lock, battery symbol layout and number layout) by

pressing the on/off button briey in quick succession.

2 To select one of the two display layouts, stop

pressing the on/off button when the layout you

prefer appears on the display.

Wait a few seconds without pressing the on/off

button until you hear a beep.This beep indicates that

the display has been set to the selected layout.

Note: the rst mode you enter after pressing the on/off

button for 3 seconds is the travel lock mode (indicated

ENGLISH 5

by a rotating key symbol). If you do not press the on/off

button again within a few seconds, the travel lock is

activated and the display will not switch to the rst

display layout mode. To deactivate the travel lock, press

the on/off button for 3 seconds again (see chapter

‘Storage’).

You can change the display layout at any time.

Note: when you start using the shaver for the rst time

or after a long period of disuse, it could take several

minutes before anything appears on the display.

The display provides the following information:

Charging

Number layout:

When the shaver is being charged, the display shows

the minutes indication and the plug symbol with a

blinking power symbol.

Battery symbol layout:

When the shaver is being charged, the display shows

the battery symbol and the plug symbol with a

blinking power symbol.

Battery fully charged

As soon as the battery has been fully charged,

the word ‘FULL’ runs across the display.

After a few hours the word ‘FULL’ stops

appearing.The display shows the minutes

indication and the plug symbol or the battery

symbol.

Battery running low

Number layout:

When the battery is running low, the display shows a

blinking minutes indication and blinking plug symbol

when you switch the shaver off.You will also hear a

few short beeps.

ENGLISH6

Battery symbol layout:

When the battery is running low, the display shows

a blinking battery symbol and blinking plug symbol

when you switch the shaver off.You will also hear a

few short beeps.

Battery empty

To indicate that the battery voltage is too low

to operate the appliance,‘LO’ appears on the

display.

Recharge the battery. See chapter ‘Charging’.

Cleaning shaver

When the shaver is due to be cleaned, the tap

symbol with blinking water jet appears on the

display.

Replacing shaving heads

When the shaving heads need to be replaced

(every two years), the shaving unit symbol starts

blinking when you switch the shaver off.At the

same time you will hear a beep.

If you do not replace the shaving heads right away,

the shaving unit symbol remains visible during the

next 7 shaves.

You can reset the system by pressing the on/off

button for 3 seconds while the shaving unit

symbol is blinking.The shaving unit symbol then

disappears. You will hear a short conrming beep.

If you have not reset the system after these 7

shaves, the system will automatically reset itself.

Demonstration program

The shaver has a unique demonstration program.

ENGLISH 7

Press the on/off button for 6 seconds.

After 3 seconds the lock symbol appears; keep the

on/off button pressed.

The demonstration will start automatically. During

the demonstration the shaver will be automatically

switched on 2 times.You can interrupt the

demonstration by pressing the on/off button.

Charging

Make sure the shaver is switched off before you

start charging it.

Charging takes approx. 1 hour.

You can also shave without charging by connecting

the shaver to the mains.

A fully charged shaver has a cordless shaving time of

up to 30 days.

Charging by means of the powerplug

1 Put the appliance plug in the shaver.

2 Put the powerplug in the wall socket.

3 Remove the powerplug from the wall socket

and pull the appliance plug out of the shaver

when the battery has been fully charged.

Charging by means of the washing machine

1 Place the shaver in the holder and lock it into

place by pushing the lever down completely.

The charging light on the washing machine starts

blinking to indicate that the shaver is being charged.

ENGLISH8

When the charging light starts burning

continuously (after approx. 1 hour), the shaver is

fully charged.

2 Move the lever upwards until it won’t go any

further (1) and remove the shaver from the

washing machine (2).

The charging light goes out.

Using the shaver

Personal Comfort Control

The Personal Comfort Control system allows

you to adapt the shaver to your skin type.

You can set the shaver to ‘Normal’ for a fast and

comfortable close shave.

You can set the shaver to ‘Sensitive’ for a

comfortable close shave with optimal skin

comfort.

The ‘S’ position is best suited for sensitive skin.

ENGLISH 9

The ‘N’ position is best suited for normal skin.

The in-between positions are suitable for skin

types between normal and sensitive.

The display shows the position selected.

Shaving

1 Switch the shaver on by pressing the on/off

button once.

The display lights up for a few seconds.

2 Move the shaving heads quickly over your skin,

making both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

3 Switch the shaver off by pressing the on/off

button once.

Number layout:The display lights up for a few

seconds and then shows the number of minutes

the shaver has been used.

Battery symbol layout:The display lights up for

a few seconds and then shows the remaining

battery capacity.

ENGLISH10

4 Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

1 Open the trimmer by pushing the slide

downwards.

The trimmer can be activated while the motor is

running.

2 Close the trimmer with your index nger.

Cleaning and maintenance

The best and most hygienic way to clean the

shaver is in the washing machine, but you can

also clean the shaver by rinsing it under the tap

or with the brush supplied.

Clean the shaver when the tap symbol with blinking

water jet appears on the display.

Regular cleaning guarantees better shaving

performance.

ENGLISH 11

Cleaning the shaver in the washing machine

Preparing the washing machine for use

Fill the cleaning chamber before rst use and when

the cleaning light blinks to indicate that the uid

level is too low. When the uid level drops below

the minimum level, the cleaning light starts to blink

with intervals and the holder returns to its starting

position.

If you use the washing machine to clean your shaver

every day, you should rell the cleaning chamber

approx. every 15 days.

1 Simultaneously press the release buttons on

both sides of the cleaning chamber (1) and lift

the washing machine off the cleaning chamber

(2).

The cleaning chamber remains behind.

2 Unscrew the dosing cap from the bottle with

HQ200 Cleaning Fluid and remove the airtight

seal.

3 Fill the cleaning chamber with cleaning uid up

to the MAX indication.

4 Place the washing machine back onto the

cleaning chamber.

Make sure the release buttons snap back into place.

5 Connect the powerplug to the washing

machine.

The holder automatically moves to the highest

position.

The washing machine is now ready for use.

ENGLISH12

Autres manuels pour HQ9190CC2

Table des matières

Langues :

Autres manuels Philips Rasoir électrique

Philips

Philips BikiniPerfect HP6378/61 Manuel utilisateur

Philips

Philips HQ6646 Manuel utilisateur

Philips

Philips HP6345/00 Manuel utilisateur

Philips

Philips SmartTouch-XL HQ9199 Manuel utilisateur

Philips

Philips TT2021/32 Manuel utilisateur

Philips

Philips NORELCO AT815 Manuel utilisateur

Philips

Philips HQ7200 Manuel utilisateur

Philips

Philips HQ888/16 Manuel utilisateur

Philips

Philips HP6345 Manuel utilisateur

Philips

Philips QuadraAction 7864XL Manuel utilisateur

Philips

Philips OneBlade QP2521 Manuel utilisateur

Philips

Philips S3561 Manuel utilisateur

Philips

Philips QT4050/41 Manuel utilisateur

Philips

Philips TT2040 Manuel utilisateur

Philips

Philips RQ1160/21 Manuel utilisateur

Philips

Philips Norelco QT4000 Manuel utilisateur

Philips

Philips ladyshave HP6318/01 Manuel utilisateur

Philips

Philips S528 Manuel utilisateur

Philips

Philips Philishave HQ 30 Manuel utilisateur

Philips

Philips S7000 series Manuel utilisateur

Philips

Philips Philishave HQ 6715 Manuel utilisateur

Philips

Philips Essence 5000 Series Manuel utilisateur

Philips

Philips BT5520 Manuel utilisateur

Philips

Philips SW6710 Manuel utilisateur

Manuels Rasoir électrique populaires d'autres marques

Norelco

Norelco Quadra 7610X Manuel utilisateur

Braun

Braun WaterFlex WF2s Manuel utilisateur

Daga

Daga MT-400 Manuel

Remington

Remington BHT100 Manuel utilisateur

Kompernass

Kompernass KH 5537 Manuel utilisateur

Remington

Remington BHT6100 Manuel utilisateur

MIA

MIA Aqua Body Manuel utilisateur

Matheo

Matheo MLR 15 Manuel utilisateur

CTC Union

CTC Union Clatronic HSM 3441 NE Manuel utilisateur

Remington

Remington XR7000 Manuel utilisateur

Eldom

Eldom G47 Manuel utilisateur

Braun

Braun silk-epil 5 Manuel utilisateur

SEVERIN

SEVERIN SÉRIE E700 0533 Guide de l'utilisateur

Remington

Remington PR1355 Manuel utilisateur

Aurora

Aurora AU 3543 Manuel utilisateur

Braun

Braun InterFace 3614 Manuel utilisateur

Wahl

Wahl 8061 5-STAR Manuel utilisateur

Norelco

Norelco 4404LC Manuel utilisateur
