Philips CEM250/51 Manuel utilisateur

CEM250

www.philips.com/welcome

EN User manual

RU ǝȀǷǻǯǻǱǾǿǯǻ ǼǻǸȉǴǻǯǭǿǲǸȌ

English

Contents

1 Important 4

Safety 4

Notice 4

2 Your car audio system 6

Introduction 6

What’s in the box 6

Overview of the main unit 7

Overview of the remote control 9

3 Get started 11

Install the car audio 11

Install remote control battery 15

Turn on 16

Set clock 16

4 Listen to radio 17

Tune to a radio station 17

Store radio stations in memory 17

Tune to a preset station 17

Play with RDS 17

5 Use bluetooth devices 20

Pairing bluetooth devices 20

Adjust microphone position 20

Voice dialing 20

Make a call 20

Call waiting 21

Call transfer 21

Terminate call 21

Play audio ﬁles 21

6 Play audio ﬁles 22

Play a disc 22

Play from USB/SD/SDHC/MMC device 22

Control play 23

Search for an MP3/WMA track 23

View play information 23

Intro play 24

Shufﬂe play 24

Repeat play 24

Connect external sound source 24

7 Adjust sound 25

Adjust volume 25

Mute 25

Turn Dynamic Bass Boost (DBB) on/off 25

Select preset equalizer 25

Other sound settings 25

8 Adjust system settings 26

Set PIN code 26

Set bluetooth connection 26

Select blackout setting 26

Turn demo mode on/off 26

Change button backlight color 26

Select start volume 27

Turn beep sound on/off 27

Turn display scroll on/off 27

Select shock-protect setting 27

Reset 28

9 Additional information 29

Detach the front panel 29

Replace fuse 29

Remove the unit 29

10 Product information 30

11 Troubleshooting 31

About Bluetooth device 32

12 Glossary 33

Notice

The making of unauthorized copies of

copy-protected material, including computer

programs, ﬁles, broadcasts and sound

recordings, may be an infringement of

copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

This apparatus includes these labels:

Class II equipment symbol

This symbol indicates that the apparatus has a

double insulation system.

Recycling

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When you see the crossed-out wheel bin

symbol attached to a product, it means the

product is covered by the European Directive

2002/96/EC:

1 Important

Safety

Read and understand all instructions•

before you use your apparatus. If damage

is caused by failure to follow instructions,

the warranty does not apply.

This apparatus is designed for negative•

ground (earth) 12 V DC operation only.

To ensure safe driving, adjust the volume•

to a safe and comfortable level.

Improper fuses can cause damage or•

ﬁre. When you need to change the fuse,

consult a professional.

Use only the supplied mounting hardware•

for a safe and secure installation.

To avoid short circuit, do not expose the•

apparatus, remote control or remote

control batteries to rain or water.

Never insert objects into the ventilation•

slots or other openings on the apparatus.

Clean the apparatus and frame with a•

soft, damp cloth. Never use substances

such as alcohol, chemicals or household

cleaners on the apparatus.

Never place any objects other than discs•

into the apparatus.

Never use solvents such as benzene,•

thinner, cleaners available commercially,

or anti-static sprays intended for discs.

Visible and invisible laser radiation when•

open. Avoid exposure to beam.

Risk of damage to the apparatus screen!•

Never touch, push, rub or strike the

screen with any object.

Caution

Use of controls or adjustments or•

performance of procedures other than herein

may result in hazardous radiation exposure or

other unsafe operation.

2009 © Koninklijke Philips Electronics N.V. All

rights reserved.

Speciﬁcations are subject to change without

notice. Trademarks are the property of

Koninklijke Philips Electronics N.V. or their

respective owners. Philips reserves the right

to change products at any time without being

obliged to adjust earlier supplies accordingly.

Never dispose of your product with other

household waste. Please inform yourself about

the local rules on the separate collection of

electrical and electronic products. The correct

disposal of your old product helps prevent

potentially negative consequences on the

environment and human health.

Your product contains batteries covered by

the European Directive 2006/66/EC, which

cannot be disposed of with normal household

waste.

Please inform yourself about the local rules on

separate collection of batteries. The correct

disposal of batteries helps prevent potentially

negative consequences on the environment

and human health.

This product complies with the radio

interference requirements of the European

Community.

This product complies with the requirements

of the following directives and guidelines:

2004/108/EC + 2006/95/EC.

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and

old equipment.

Any changes or modiﬁcations made to this

device that are not expressly approved by

Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

English

lQuick start guide

mStandard connector

de f

klm

2 Your car audio

system

Congratulations on your purchase, and

welcome to Philips! To fully beneﬁt from the

support that Philips offers, register your product

at www.philips.com/welcome.

Introduction

With the in-car audio system, you can enjoy

your drive while you listen to:

FM or AM (MW) radio•

Audio from CD or MP3 disc•

Audio from your mobile phone•

Audio from a USB drive•

Audio from a SD/SDHC/MMC card•

Audio from external devices•

Besides, you can make a call, answer and hang

up a call on the audio system.

What’s in the box

Check and identify the contents of your

package:

aCar audio system

bRemote control

cMicrophone

dMicrophone hold

eRubber cushion

fDisassembly tool (2 pieces)

gFront panel

hCarrying case for front panel

iTrim plate

jScrew (4 pieces)

kUser manual

cSOURCE

Select audio source.•

Connect or disconnect bluetooth•

connection.

d/MUTE

Turn the unit on or off.•

Adjust volume.•

Conﬁrm selection.•

Enter characters for search.•

Dial phone number.•

Mute or restore the volume.•

Overview of the main unit

a(green/red)

Answer phone (green).•

Dial number (green).•

View call log (green).•

Terminate call (red).•

b/DBB

Select tuner band.•

Select MP3/WMA folder.•

Scroll up menu.•

Turn on or off Dynamic Bass Boost•

(DBB) sound.

Select RDS program type.•

abdghi

xwut

r q po nml kj

English

s/SEARCH

Select tuner band.•

Store radio stations automatically.•

Scroll up or down menu.•

Select MP3/WMA folder.•

Search a track or folder.•

Select RDS program type.•

tPanel power connection

uDisc slot

Take disc out.•

wRESET

Restore default settings•

xSD/MMC card slot

eMENU / DISP

Display radio frequency, clock and•

radio program type (if available).

Display track, elapsed time, artist,•

alburm, title, folder, ﬁle and clock.

Access system menu.•

Access RDS (Radio Data System)•

menu.

Return to previous menu.•

Stop search.•

Disable screen blackout.•

gDisplay panel

Unlock the panel•

iUSB socket

jExternal device socket

Select preset station 6.•

Select preset station 5.•

mSHUF, 4

Set shufﬂe play mode.•

Select preset station 4.•

n3, REP

Set repeat play mode.•

Select preset station 3.•

oINTRO, 2

Turn intro play on or off.•

Select preset station 2.•

p1,

Start play•

Pause or resume play.•

Select preset station 1.•

Tune to a radio station•

Skip/search for MP3/WMA track.•

rEQ/Audio

Select equalizer (EQ) setting.•

Access audio setting menu.•

dMENU

Access system menu.•

Access RDS (Radio Data System)•

menu.

eAUDIO

Access audio setting menu.•

f5/6/7/8/9/0+

Select track or preset radio station.•

Enter phone number.•

Answer phone.•

Dial number.•

h1,

Start play from the beginning of the•

ﬁrst track.

Pause or resume play.•

Select preset station 1.•

Enter phone number.•

iSHUF, 4

Set shufﬂe play mode.•

Select preset station 4.•

Enter phone number.•

jSEL

Conﬁrm selection.•

Tune for radio station•

Skip/search for MP3/WMA track.•

Select RDS program type.•

Return to previous menu.•

Disable screen blackout.•

mSOURCE

Select audio source.•

nVOLUME +/-

Adjust volume.•

oEQ

Select EQ setting.•

pDBB

Turn on or off Dynamic Bass Boost•

(DBB) sound.

Overview of the remote

control

Tune to a radio station•

Skip/search for a track.•

Mute or restore volume.•

cPWR

Turn the unit on or off.•

English

qSEARCH

Set radio station memory•

automatically.

Search a track or folder.•

rDISP

Display radio frequency, clock and•

radio program type (if available).

Display MP3/WMA elapsed time, last•

listened radio frequency, and clock.

Terminate call•

t3, REP

Set repeat play mode.•

Select preset station 3.•

Enter phone number.•

uINTRO, 2

Turn intro play on or off.•

Select preset station 2.•

Enter phone number.•

Note on the power supply lead (yellow)

When you connect other devices to this•

apparatus, ensure that the rating of the

car circuit is higher than the total fuse

value of all the connected devices.

Notes on speaker connection

Never connect speaker wires to the•

metal body or chassis of the car.

Never connect speaker wires with stripes•

to one another.

Overview of parts

These are the supplied parts needed to

connect and install this unit.

aIn-car audio system

bSleeve

cFront panel

dStandard connector

eTrim plate

fRubber cushion

gDisassembly tools

hScrews (4 pieces)

fgh

3 Get started

Caution

Use the controls only as stated in this user•

manual.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the

model and serial number of your apparatus.The

model number and serial number are on the

bottom of your apparatus.Write the numbers

here:

Model No. __________________________

Serial No. ___________________________

Install the car audio

These instructions are for a typical installation.

However, if your car has different requirements,

make the corresponding adjustment. If you have

any questions regarding installation kits, consult

your Philips car audio dealer.

Caution

This unit is designed for negative ground•

(earth) 12 V DC operation only.

Always install this unit in the car dashboard.•

Other locations can be dangerous as the rear

of the unit heats up during use.

To avoid short-circuit: before you connect,•

ensure that the ignition is off.

Ensure that you connect the yellow and red•

power supply leads after all other leads are

connected.

Ensure that all loose leads are insulated with•

electrical tape.

Ensure that the leads do not get caught under

•

screws orin parts that will move (e.g. seat rail).

Ensure that all ground (earth) leads are run to•

a common ground (earth) point.

Use only the supplied mounting hardware for a

•

safe and secure installation.

Improper fuses can cause damage or ﬁre.

•

When you need to change the fuse, consult a

professional.

English

Autres manuels pour CEM250/51

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Système stéréo de voiture

Philips

Philips CE120/55 Manuel utilisateur

Philips

Philips CarStudio CE132 Manuel utilisateur

Philips

Philips CEM200/55 Manuel utilisateur

Philips

Philips CED1900BT Manuel utilisateur

Philips

Philips CEM2000/00 Manuel utilisateur

Philips

Philips CED229/55 Manuel utilisateur

Philips

Philips CID3682/93 Manuel utilisateur

Philips

Philips CID3289 Manuel utilisateur

Philips

Philips CMB1100/55 Manuel utilisateur

Philips

Philips CE153DR Manuel utilisateur

Philips

Philips CarStudio CEM3100 Manuel utilisateur

Philips

Philips CID-3610 Manuel utilisateur

Philips

Philips CED750/51 Manuel utilisateur

Philips

Philips CED229/98 Manuel utilisateur

Philips

Philips CID3285/93 Manuel utilisateur

Philips

Philips CarStudio CE132 Manuel utilisateur

Philips

Philips CMB2100/55 Manuel utilisateur

Philips

Philips CED229/55 Manuel utilisateur

Philips

Philips CEM220/55 Manuel utilisateur

Philips

Philips CED320/51 Manuel utilisateur

Philips

Philips CID3680/93 Manuel utilisateur

Philips

Philips CID3280/93 Manuel utilisateur

Philips

Philips CED320/55 Manuel utilisateur

Philips

Philips CID3289/00 Manuel utilisateur

Manuels Système stéréo de voiture populaires d'autres marques

JL Audio

JL Audio Stealthbox SB-CAN-G2MVX3D/10TW3 Manuel utilisateur

Clarion

Clarion PU-9836A Manuel utilisateur

Sony

Sony MEX-BT5750U Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric AR0M Manuel utilisateur

Sony

Sony RM-X7BT Manuel utilisateur

Insignia

Insignia NS-HD5113 Manuel utilisateur

Clarion

Clarion BTD3341 Manuel utilisateur

USA SPECS

USA SPECS PA11-VW6 Manuel utilisateur

Sony

Sony MEX-N4380BT Manuel utilisateur

Kenwood

Kenwood KCD-BT6544U/UY Manuel utilisateur

JVC

JVC KD-DB912BT Manuel utilisateur

Alpine

Alpine TDM-7544 Manuel utilisateur

Autotek

Autotek TransAm TA 1400 Manuel utilisateur

Clarion

Clarion PN-3124N-A Manuel utilisateur

Denso TEN

Denso TEN FT0108A Manuel utilisateur

Pyle

Pyle PLD57MU Manuel utilisateur

Harman

Harman Chrysler Radio Navigation System RB4 Manuel utilisateur

Clarion

Clarion VS735 Manuel utilisateur
