Air Cleaner

HR 4340/A

Philips Domestic Appliances and Personal Care

Service Manual 4822 729 21616 herewith cancells.

PRODUCT INFORMATION

GENERAL

The HR 4340 is suitable for rooms / areas with a floor surface of

up to approx. 40 m2.

The air cleaner cleans the air effectively by catching 90% of the

gases and 95% of the particles produced by smoking.

This is done by 3 filters :

Foam pre-filter : The foam pre - filter catches the larger

dust particles floating in the air such as

fluff and hairs.

HEPA filter HR4940 : This filter takes out all smaller airborne

particles.

Carbon filter : The carbon filter with activated carbon

granulates (HR4941) effectively absorbes

the smoke gases.

Product meets the requirements regarding interference

suppression on radio and T.V.

FEATURES

Filter full indicator: Indicates that the filter has to be replaced.

This has to be done when the white part of the indicator has

turned pink like the other (pink) half.

Speed control: With 3 speed settings.

Safety lock: Prevents the customer from opening the front

cover whilst the air cleaner is switched on.

The front cover can only be opened, if the switch has been set to

the “0" position.

Overheating safety device: The overheating safety device

comes into operation when the motor becomes too hot. To

indicate that the appliance is still in “ON” position and connected

to the mains, the pilot light remains on.

If this happens : −Switch off the motor.

−After approx. 15 min. the air cleaner can be

switched on again.

TECHNICAL DATA

Voltages : 100 Volt : 95 Watts

110 - 120 Volt : 95 Watts

220 - 240 Volt : 95 Watts

Filters : 2 carbon filters

Life time filters : carbon filters : 3 months

Hepa filter : 6 months

Flow rate : 160 m3/hr

Surface filter surface : 1 m2

Room / area size : Max. 40 m2

Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ©Copyright reserved Subject to modification

4822 729 21809

97/03

PCS 88 615

1) The motor makes an irritating noise.

Check if : −The carbon filters are positioned properly in

the air cleaner.

:−The filters have to be cleaned or replaced.

:−The fan can be rotated freely by hand.

Only for the HR4340/A appliances, which have been

produced before week 9618.

If the motor still makes an irritating noise after the above

checks, the complete product should be replaced by a

sample, produced after week 9618.

2) The overheating device comes into operation.

Check : If the filters are not blocked and nothing is

obstructing the air inlet and air outlet openings.

: That the fan can be moved freely by hand.

In case the problem still remains, replace motor (item 13.0)

and belonging buffers (item 13.1).

POS DESCRIPTION SERVICE CODE

1 FRONT COVER 4822 442 00118

containing : frame 1

foam pre-filter 11

cover 100

2 CONTAINER CARBON GRANULES 4822 418 10132

3 HEPA FILTER HR4940 4822 480 10085

4 CONTROL PANEL 4822 466 10864

5 SWITCH KNOB 4822 410 10261

containing : switch knob 5

spring 101

6 SAFETY LOCK 4822 417 11271

containing : safety lock 6

spring 102

7 PILOT LAMP 220 - 240 V 4822 134 10012

PILOT LAMP 100 - 127 V 4822 134 10013

containing : lamp 7

lamp cover 103

8 SWITCH 4822 273 10304

9 AIR OUTLET 4822 458 10463

10 FRONT HOUSING 4822 441 11656

consisting of : front housing 10

hole plug 105

safety grill 106 2x

foot 107 2x

11 FOAM PRE-FILTER 4822 480 10086

12 FAN 4822 361 10778

containing : fan 12

lock washer 108

washer 109

nut M6 110

nut cover 111

13.0 MOTOR 220 - 240 V 4822 361 10779

MOTOR 110 - 120 V 4822 361 10781

MOTOR 100 V 4822 361 10782

13.1 SET BUFFERS 4822 310 10648

containing: rubber buffers 112 3x

metal bracket 113 3x

bush 115 3x

14 REAR HOUSING 4822 441 11657

consisting of: rear housing 14

foot 107 2x

15 REAR COVER 4822 442 00119

16 CARBON GRANULES HR 4941 4822 390 10139

17 CAPACITOR 110 - 127 V 4822 123 14028

MAINTENANCE

Pre-filter : Wash or vacuum clean the foam pre-filter at

least every 2 months. Fluff and / or hairs can

also be removed by using a soft brush.

Replacement filters are available under service

code 4822 480 10086

NEVER USE WET FILTERS.

HEPA filter : For a proper operation, replace this filter at

least every six months.

Replacement HEPA filters are available under

number HR 4940 and service code

4822 480 10085.

Carbon filter: Replace the carbon granules at least every

3 months.

New carbon granules are available under type

number HR 4941 and service code

4822 390 10139

POSSIBLE COMPLAINTS PARTS LIST HR 4340/A

N.B. PARTST, WITH NUMBERS FROM 100

UPWARDS, CANNOT BE ORDERED

SEPARATELY.

PCS 88 616
