PEUGEOT 207cc Manuel utilisateur
4
4
INSTRUMENTS AND CONTROLS
1.
Audio equipment steering wheel
control.
2.
Steering lock and ignition.
3.
Wipers/wash-wipe/trip computer
controls.
4.
Instrument panel.
5.
Driver’s air bag.
Horn.
6.
Dynamic stability control
(ESP/ASR) button.
Visual and audible rear parking
assistance button.
Central locking button.
Alarm button.
7.
Gear lever.
8.
Handbrake.
9.
Retractable roof control.
Control for the four windows.
10.
Exterior mirror controls.
Electric window controls.
11.
Headlamp height adjustment.
12.
Door window de-icing vent.
13.
Side adjustable and closing vent.
14.
Windscreen de-icing vent.
FAMILIARISATION
5
5
INSTRUMENTS AND CONTROLS
1.
Steering wheel adjustments
control.
2.
Cruise control/speed limiter switch.
3.
Lights and direction indicators
controls.
4.
Hazard warning lights switch.
5.
Fragrance diffuser.
6.
Multifunction display.
Seat belt fastening status warning
lights.
7.
Sunshine sensor.
8.
Passenger air bag.
9.
Speaker (medium tweeter).
10.
Glove box/Passenger air bag
disarming/Audio/video sockets/
Fuse box.
11.
Bonnet release control.
12.
Front ashtray/Lighter.
13.
Heating/air conditioning controls.
14.
CD changer.
15.
Audio RD4 or RT3 GPS audio/
telephone.
16.
Central adjustable and closing
vents.
FAMILIARISATION
i
6
6
OPENING
Remote control key
A.
Unfolding/Folding the key.
B.
Unlocking the vehicle.
C.
Unlocking and partially opening
the boot.
66
Also...
D.
Normal locking
or
Deadlocking of the vehicle.
Fuel tank
1.
Opening the fuel filler flap.
2.
Opening and hooking the fuel filler
cap.
Capacity of the tank: approximately 50 litres.
78
Boot
From outside
From inside
1.
Unlocking the boot or the vehicle.
2.
Opening the tailgate.
1.
Key in the starter.
2.
Unlocking using the manual
centralised control.
77
FAMILIARISATION
!! i
7
7
OPENING
Precautions to be taken before
operating the retractable roof
Park the vehicle on level ground.
Check that no object could hinder
the roof manoeuvre:
- nothing should be placed on the
moving rear shelf
1
or on the
screen
2
,
- if luggage is being transported
in the boot, it must not raise the
screen,
- any object, such as a jacket or
umbrella, placed in the boot, must
be secured using the luggage re-
taining net
3
.
Ensure that the screen
2
is secure.
Close the boot correctly.
When washing your vehicle:
- avoid spraying the upper part of
the windows,
- keep the end of the high-pres-
sure nozzle at least 1 metre from
the windows and door seals.
After washing the vehicle or fol-
lowing rain, wait until the roof has
dried before opening it.
The roof is operated under the
sole responsibility of the driver.
During roof manoeuvres, to avoid
the risk of injury, ensure that no
one is in the vicinity of the moving
parts.
You are strongly advised not to op-
erate the roof in strong winds.
It is preferable to carry out the roof
manoeuvre with the engine run-
ning.
The roof can be operated at
speeds below 6 mph (10 km/h).
It is only possible to carry out the
operation twice with the engine off,
to prevent discharging of the bat-
tery.
Preliminary conditions
Switch on the ignition.
Check thoroughly that:
- the vehicle is not in energy eco-
nomy mode (refer to the corres-
ponding section),
- the battery voltage is sufficient
(switching on of the indicator light
on the roof control button),
- the roof fuse is in good condition
(refer to the corresponding sec-
tion),
- the electric windows are initia-
lised (refer to the corresponding
section),
- the exterior temperature is above
-15 °C.
FAMILIARISATION
!
i
!
i
!
8
8
Switch to "cabriolet" configuration:
- the four windows lower,
- the boot opens,
- the roof folds into the boot,
- the boot closes.
Operating fault
If a malfunction of the roof oc-
curs, apply the handbrake, switch
off the ignition, restart the engine,
then start the required manoeuvre
again.
If the problem persists, contact a
PEUGEOT dealer.
OPENING
Retractable roof manoeuvres
Opening the roof
Pull this button until the roof
opening manoeuvre is com-
plete.
This is confirmed by an audible signal
and a message on the multifunction dis-
play.
Closing the roof
Press this button until the
roof closing manoeuvre is
complete.
This is confirmed by an audible signal
and a message on the multifunction dis-
play.
play.
If you continue to pull or press this
button after the end of the ma-
noeuvre, the four windows rise.
For correct operation, do not re-
lease the roof button during a roof
manoeuvre.
However, in the event of danger,
release the button, the roof stops;
then, when the danger has been
eliminated, complete the required
manoeuvre.
Switch to "coupé" configuration:
- the four windows lower,
- the boot opens,
- the roof unfolds and locks automati-
cally,
- the boot closes.
The electric window controls and
the control for the four windows
are deactivated during roof ma-
noeuvres.
Maintenance
Carry out a complete roof manoeu-
vre at least once a month to keep
it in perfect working order.
FAMILIARISATION
i
9
9
SITTING COMFORTABLY
Also...
5.
Access to the rear seats.
Front seat adjustment
Steering wheel adjustment
1.
Forwards-backwards adjustment.
2.
Height adjustment.
3.
Seat back angle adjustment.
4.
Head restraint height and angle
adjustment.
54
1.
Unlocking the control.
2.
Height and depth adjustment.
3.
Locking the control.
56
FAMILIARISATION
i
10
10
SITTING COMFORTABLY
Exterior mirrors adjustment
A.
Selecting the mirror.
B.
Adjusting the position of the mirror.
C.
De-selecting the mirror.
57
Also...
D.
Folding/Unfolding.
Interior mirror adjustment
1.
Selecting the "day" position of the
mirror.
2.
Directing the mirror.
58
Front seat belt
A.
Fastening.
96
FAMILIARISATION
11
11
SEEING CLEARLY
Lights
Wipers
Ring B
80
Front and rear fog lamps.
Ring A
Lever A: windscreen wipers
2.
Fast wipe.
1.
Normal wipe.
I.
Intermittent wipe.
0.
Park.
Single wipe.
Wash-wipe: pull the lever towards you.
83
Lights off.
Automatic switching on of the
lights.
Side lights.
Dipped/main beam headlamps.
79
FAMILIARISATION
–
12
12
VENTILATION
Advice on interior settings
I require...
Heating or Manual air conditioning
Air distribution
Air flow
Air recirculation/
Exterior air intake
Temperature
Manual A/C
HEAT
COOL
DEMISTING
DE-ICING
Automatic air conditioning:
use of the fully automatic mode by pressing the
"AUTO"
button is preferable.
FAMILIARISATION
13
13
MONITORING
Instrument panel
Controls bar
A.
With the ignition on, the fuel gauge
needle should rise.
B.
With the engine running, the
associated low level warning light
should switch off.
C.
With the ignition on, the oil level
indicator should display
"OIL OK"
for a few seconds.
If the levels are not correct, top up the
level which is low.
22
Lighting of the indicator light indicates
the status of the corresponding func-
tion.
A.
Deactivation of the ESP/ASR
system.
95
B.
Deactivation of the visual and
audible rear parking assistance.
110
C.
Central locking.
75
D.
Deactivation of the interior
protection alarm.
70
1.
With the ignition on, the orange
and red warning lights come on.
2.
With the engine running, these
warning lights should switch off.
If a warning light remains on, refer to
the page concerned.
23
Warning lights
FAMILIARISATION
