PEUGEOT 207 CC 2014 Manuel utilisateur

HANDBOOK

Please note the following point:

The fitting of electrical equipment or accessories which are not

recommended by PEUGEOT may result in a failure of your vehicle's

electronic system. Please note this specific warning. It is advisable

to contact a PEUGEOT dealer to be shown the recommended

equipment and accessories.

On-line handbook

You can find your handbook on the

PEUGEOT

website, under

"MyPEUGEOT".

Referring to the handbook on-line also gives you access to the

latest information available, easily identified by the bookmark,

associated with this symbol:

If the "MyPEUGEOT" function is not available on the

PEUGEOT

public website for your country, you can find your handbook at the

following address:

http://public.servicebox.peugeot.com/ddb/

The Vehicle documentation link in the home page (no registration is

needed),

the language,

the vehicle, its body style,

the print edition of your handbook appropriate for the date of

registration of your vehicle.

Select:

You have access to your handbook on line, together with the latest

information, identified by the symbol:

Thank you for choosing a 207 CC, a

symbol of conﬁ dence, passion and in-

spiration.

This handbook has been designed to

enable you to make the most of your

207 CC.

On the ﬁ rst few pages, you will ﬁ nd a

detailed summary, followed by a quick

reference guide intended to make it

easier for you to become familiar with

your coupé-cabriolet.

All of the details speciﬁ c to your 207 CC,

comfort, safety, driving, are then pre-

sented in this handbook, to increase

your appreciation of the vehicle help

you get the most from it.

Each model may only be ﬁ tted with

some of the equipment mentioned in

this handbook, depending on its version

and the speciﬁ cation for the country in

which it is sold.

Page reference:

this symbol invites you to refer to

the pages which provide details

of the function.

Key

Protection of the environment:

this symbol accompanies advice

relating to protection of the envi-

ronment.

Information:

this symbol draws your attention

to additional information for better

use of your vehicle.

Warning:

this symbol marks warnings which

it is essential to observe for your

own safety, for the safety of others

or to avoid any risk of damaging

your vehicle.

Welcome

CONTENTS

■Instrument panels 20

■Indicator and warning lamps 21

■Indicators 28

■Adjustment buttons 32

■Screens without

audio equipment 33

■Screens with audio equipment 35

■16/9 colour screen

(PEUGEOT Connect Navigation) 40

■Trip computer 42

■Ventilation 45

■Heating 47

■Manual air conditioning 47

■Rear screen

demist - defrost 49

■Digital air conditioning 50

■Seats 52

■Steering wheel adjustment 54

■Mirrors 55

■ Interior ﬁ ttings 57

■Windstop 62

COMFORT 45 64

■Remote control key 65

■Alarm 69

■Window controls 71

■Doors 73

■Boot 76

■Fuel tank 77

■Misfuel prevention

(Diesel) 79

ACCESS 65 79

■Lighting control stalk 80

■Static directional lighting 83

■Headlamp adjustment 83

■Wiper control stalk 84

■Courtesy lamp 85

VISIBILITY 80 85

■Conventional child seats 86

■Deactivating

the passenger's front airbag 87

■ISOFIX child seats 94

CHILD SAFETY 86 96

FAMILIARISATION 4 17

MONITORING 20 44

ECO-DRIVING 18 19

CONTENTS

■Direction indicators 97

■Emergency

or assistance call 97

■Warning triangle 97

■Hazard warning lamps 98

■Horn 98

■ Tyre under-inﬂ ation detection 99

■Braking

assistance systems 100

■Trajectory

control systems 101

■Seat belts 102

■Airbags 105

SAFETY 97 108

■Parking brake 109

■Manual gearbox 109

■Gear shift

indicator 110

■Automatic

gearbox 111

■Speed limiter 114

■Cruise control 116

■Parking sensors 118

DRIVING 109 119

■Bonnet 121

■Running out of fuel (Diesel) 121

■Petrol engines 122

■Diesel engine 123

■Checking levels 124

■Checks 126

CHECKS 120 127

■Temporary puncture

repair kit 128

■Changing a wheel 133

■Snow chains 137

■Changing a bulb 138

■Changing a fuse 142

■Battery 147

■Energy economy mode 149

■Changing

a wiper blade 149

■Towing the vehicle 150

■Towing a trailer 151

■Accessories 153

PRACTICAL

INFORMATION 128 153

■Petrol engines 154

■Weights (petrol) 155

■Diesel engine 156

■Weights (Diesel) 157

■Dimensions 158

■ Identiﬁ cation markings 159

TECHNICAL DATA

154 160

AUDIO EQUIPMENT and

TELEMATICS 161 214

■Emergency or assistance 161

■PEUGEOT Connect Navigation

(RNEG) 163

■PEUGEOT Connect Sound

(RD5) 195

ALPHABETICAL

INDEX 219223

VISUAL

SEARCH 215 218

FAMILIARISATION

EXTERIOR

Retractable roof

This system enables you to change the

vehicle from "coupé" to "cabriolet" con-

ﬁ guration and vice versa with a single

action.

Static directional lighting

This additional lighting automatically

provides extended visibility when

turning.

Visual and audible rear parking

sensors

This system provides a warning when

reversing by detecting obstacles locat-

ed behind the vehicle.

Under-inflation detection

This system monitors the pressure in

each tyre and warns you of a punc-

ture or drop in pressure.

Turbulence prevention

net (Windstop)

In "cabriolet" conﬁ guration, this

system reduces the wind turbu-

lence in the front seats.

Temporary puncture repair kit

This kit is a complete system, con-

sisting of a compressor and an inte-

gral sealant, for the temporary repair

of a tyre.

6

83 99 128

61

118

i i

FAMILIARISATION

OPENING

Remote control key

A. Unfolding/Folding the key.

B. Unlocking the vehicle.

C. Unlocking and partially opening the

boot.

Also...

D. Normal locking

Deadlocking of the vehicle.

Fuel tank

1. Opening the fuel ﬁ ller ﬂ ap.

2. Opening and hooking the fuel ﬁ ller

cap.

Capacity of the tank: approximately

50 litres (petrol) or 48 litres (Diesel).

Boot

From outside

From inside

1. Unlocking the complete vehicle or

unlocking the boot and the vehicle.

2. Opening the boot lid.

1. Key in the ignition switch.

2. Unlocking using the manual central

locking control or the door opening

control.

On Diesel vehicles, the fuel ﬁ ller

neck incorporates a misfuel preven-

tion device which prevents ﬁ lling

with petrol.

65

76

77

79

FAMILIARISATION

OPENING

Retractable roof

When washing your vehicle:

- lock the vehicle,

- avoid spraying the upper part

of the windows,

- keep the end of the high-pres-

sure nozzle at least 1 metre

from the windows and door

seals.

After washing the vehicle or fol-

lowing rain, wait until the roof has

dried before opening it.

The roof is operated under the

sole responsibility of the driver.

During operation of the roof, to

avoid the risk of injury, ensure that

no one is in the vicinity of the mov-

ing parts.

You are strongly advised not to op-

erate the roof in strong winds.

It is preferable to operate the roof

with the engine running.

The roof can be operated at

speeds below 6 mph (10 km/h).

It is only possible to carry out the

operation twice with the engine off,

to avoid discharging the battery.

Preliminary conditions

Switch on the ignition.

Ensure that:

- the vehicle is not in energy econo-

my mode (refer to the correspond-

ing section),

- the battery voltage is sufﬁ cient (il-

lumination of the indicator lamp in

the roof control),

- the roof fuse is in good condition

(refer to the corresponding section),

- the electric windows are initialised

(refer to the corresponding section),

- the ambient temperature is above

-15 °C.

Precautions to be taken before

operating the roof

Park the vehicle on level ground.

Check that no object could hinder

the operation of the roof:

- nothing should be placed on the

moving rear shelf 1or on the

net 2.

- if luggage is being carried in the

boot, it must not raise the net.

Ensure that the net 2is secure.

Close the boot correctly.

Maintenance

Carry out a complete opening

and closing operation of the roof

at least once a month to keep it in

good working order.

FAMILIARISATION

OPENING

Retractable roof operation

Opening the roof

Pull this control until the roof

is fully open.

Closing the roof

Press this control until the

roof is fully closed.

Do not release the roof control dur-

ing operation of the roof.

However, in the event of danger,

release the control, the roof stops;

then, when the danger is no longer

present, complete the required op-

eration.

If the operation has not completely

ﬁ nished, you will be warned by an

audible signal and a message in

the multifunction screen. These will

be repeated as the vehicle passes

a number of speed thresholds.

Changing to "cabriolet"

conﬁ guration:

- the four windows lower,

- the boot opens,

- the roof folds into the boot,

- the boot closes.

If you continue to pull or press this

control after the end of the opera-

tion, the four windows rise.

The electric window controls and

the control for the four windows

are deactivated during operation

of the roof.

The roof electronic control unit

may interrupt the operation in

progress as a precaution (for ex-

ample: door movement and roof

operation in quick succession). In

this case, release the control then

operate it again to complete the

required operation.

Operating fault

If a malfunction of the roof occurs,

apply the parking brake, switch

off the ignition, restart the engine,

then start the required operation

again.

If the problem persists, contact a

PEUGEOT dealer.

Changing to "coupé" conﬁ guration:

- the four windows lower,

- the boot opens,

- the roof opens out and locks auto-

matically,

- the boot closes.

The end of the operation is conﬁ rmed

by an audible signal and a message in

the multifunction screen.

The end of the operation is conﬁ rmed

by an audible signal and a message in

the multifunction screen.

FAMILIARISATION

INTERIOR

Dual-zone digital air

conditioning

This system allows different levels of

comfort to be set for the driver and the

front passenger. It then automatically

controls these levels according to the

ambient conditions.

Automatic gearbox

This system provides perfect driving

pleasure by combining a fully automatic

mode, associated with two special pro-

grammes, and a manual mode.

Audio and communication

systems

These systems beneﬁ t from the latest tech-

nology: MP3 compatible PEUGEOT Connect

Sound (RD5), PEUGEOT Connect USB,

Bluetooth hands-free system, PEUGEOT

Connect Navigation (RNEG) with 16/9 colour

screen, JBL audio system, auxiliary sockets.

PEUGEOT Connect Navigation (RNEG)

Electric windows

On the driver's side, control of

the electric window is automatic

when opening and when closing.

163

195

202

71

111

50

PEUGEOT Connect Sound (RD5)

PEUGEOT Connect USB

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels PEUGEOT Automobile

PEUGEOT

PEUGEOT 807 Manuel utilisateur

PEUGEOT

PEUGEOT RCZ Manuel utilisateur

PEUGEOT

PEUGEOT 4008 Manuel utilisateur

PEUGEOT

PEUGEOT 206 CC Manuel utilisateur

PEUGEOT

PEUGEOT 4008 2012 Manuel utilisateur

PEUGEOT

PEUGEOT 206 Manuel utilisateur

PEUGEOT

PEUGEOT 208 Manuel utilisateur

PEUGEOT

PEUGEOT 207 CC Manuel utilisateur

PEUGEOT

PEUGEOT 208 Manuel utilisateur

PEUGEOT

PEUGEOT 207 Spider Manuel utilisateur

PEUGEOT

PEUGEOT 2008 Manuel utilisateur

PEUGEOT

PEUGEOT Expert Manuel utilisateur

PEUGEOT

PEUGEOT 206 CC Manuel utilisateur

PEUGEOT

PEUGEOT 5008 Manuel utilisateur

PEUGEOT

PEUGEOT 406 Coupe Manuel utilisateur

PEUGEOT

PEUGEOT 607 Manuel utilisateur

PEUGEOT

PEUGEOT PARTNER Tepee Manuel utilisateur

PEUGEOT

PEUGEOT 508 Manuel utilisateur

PEUGEOT

PEUGEOT 508 Manuel utilisateur

PEUGEOT

PEUGEOT 308 Manuel utilisateur

PEUGEOT

PEUGEOT e-208 Manuel utilisateur

PEUGEOT

PEUGEOT 107 Manuel utilisateur

PEUGEOT

PEUGEOT PARTNER Tepee Manuel utilisateur

PEUGEOT

PEUGEOT ION Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Cadillac

Cadillac CTS 2008 Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur
