PEUGEOT 207 Spider Manuel utilisateur
Handbook
AP_207BB_01_2010_anglais_cag_pdfcouv1 couv1
AP_207BB_01_2010_anglais_cag_pdfcouv1 couv1
02/02/2010 13:54:28
02/02/2010 13:54:28
4
FAMILIARISATION
EXTERIOR
Panoramic sunroof
This extensively glazed roof provides
incomparable visibility and light in the
passenger compartment.
78
Static directional lighting
This additional lighting automatically
provides extended visibility when turning.
84
Opening rear screen (SW)
This system gives easy access to the
luggage compartment without having
to open the tailgate.
Check that the rear screen is closed
correctly before opening the boot or
locking the vehicle.
77
Temporary tyre repair kit
This kit is a complete system, con-
sisting of a compressor and an inte-
gral sealant, for the temporary repair
of a tyre.
132
Rear parking sensors
This system provides a warn-
ing when reversing by detect-
ing obstacles located behind
the vehicle.
123
Tyre under-inÀation detection
This system monitors the pres-
sure in each tyre and warns you
if a puncture or deÀation occurs.
101
AP_207BB_01_2010_anglais_cag_pdf4 4
AP_207BB_01_2010_anglais_cag_pdf4 4
02/02/2010 13:54:40
02/02/2010 13:54:40
ii
5
FAMILIARISATION
OPEN
Remote control key
A. Unfolding/Folding the key.
B. Unlocking the vehicle.
C. Unlocking and partially opening the
rear screen (SW).
66
Also...
D.
Normal locking
or
Deadlocking the vehicle.
Fuel tank
1. Opening the fuel ¿ller Àap.
2. Opening and hooking the fuel ¿ller
cap.
Capacity of the tank: approximately
50 litres.
79
Bonnet
A. Interior release lever.
B. Exterior safety catch.
C. Bonnet stay.
126
On Diesel vehicles, the fuel tank
opening incorporates a misfuel
prevention device which prevents
¿lling with petrol.
80
AP_207BB_01_2010_anglais_cag_pdf5 5
AP_207BB_01_2010_anglais_cag_pdf5 5
02/02/2010 13:54:42
02/02/2010 13:54:42
i
6
FAMILIARISATION
OPENING
Boot (SW)
1. Unlocking the vehicle.
2. Opening the boot.
77
Vehicle locked Panoramic sunroof (SW)
1. Unlocking and partially opening the
rear screen.
2. Opening the rear screen.
1. Opening the blind.
2. Closing the blind.
78
1. Partially opening the rear screen.
2. Opening the rear screen.
77
Vehicle unlocked
The tailgate and the rear screen
cannot both be open at the same
time, to avoid damaging the rear
screen.
Rear screen (SW)
AP_207BB_01_2010_anglais_cag_pdf6 6
AP_207BB_01_2010_anglais_cag_pdf6 6
02/02/2010 13:54:44
02/02/2010 13:54:44
7
FAMILIARISATION
INTERIOR
Dual-zone digital air conditioning
This system allows different levels of
comfort to be set for the driver and the
front passenger. It then automatically
controls these levels according to the
ambient conditions.
48
Distance recorder
The trip distance recorder is reset to
zero by pressing the right-hand button
on the instrument panel for more than
two seconds.
30
Audio and communication systems
This equipment bene¿ts from the latest
technology: MP3 compatible Peugeot
Connect Sound, Peugeot Connect USB,
Bluetooth hands-free system, Peugeot
Connect Navigation, auxiliary sockets,
JBL audio system.
Peugeot Connect Navigation
173
Peugeot Connect Sound
203
Peugeot Connect USB
210
AP_207BB_01_2010_anglais_cag_pdf7 7
AP_207BB_01_2010_anglais_cag_pdf7 7
02/02/2010 13:54:47
02/02/2010 13:54:47
8
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Cruise control/speed limiter switches.
2. Steering wheel adjustment control.
3. Lighting and direction indicator control
stalk.
4. Instrument panel.
5. Driver's airbag.
Horn.
6. Gear lever.
7. Parking brake.
8. Panoramic sunroof blind control
(SW).
9. Bonnet release lever.
10.Door mirror controls.
Electric window controls.
Rear electric windows deactivation
control.
11. Fusebox.
12.Headlamp height adjustment.
13.Side adjustable air vent.
14.Front door window demisting vent.
15.Speaker (tweeter).
16.Windscreen demisting vent.
AP_207BB_01_2010_anglais_cag_pdf8 8
AP_207BB_01_2010_anglais_cag_pdf8 8
02/02/2010 13:54:48
02/02/2010 13:54:48
9
FAMILIARISATION
INSTRUMENTS AND CONTROLS
1. Steering lock and ignition.
2. Audio equipment steering mounted
controls.
3. Wiper/wash-wipe/trip computer
control stalk.
4. Hazard warning lamps switch.
5. Multifunction screen.
Seat belt fastening status warning
lamps.
6. Sunshine sensor.
7. Passenger's airbag.
8. Glove box/Passenger's airbag
deactivation/Audio/video sockets.
9. Heated seat control.
10.Front ashtray.
11. 12 V accessories socket.
12.USB port.
13.Dynamic stability control
(ESP/ASR) button.
Central locking button.
Alarm button.
Electric child lock button.
14.Heating/air conditioning controls.
15.Storage compartment.
16.Peugeot Connect Sound or
Peugeot Connect Navigation.
17.Central adjustable air vents.
AP_207BB_01_2010_anglais_cag_pdf9 9
AP_207BB_01_2010_anglais_cag_pdf9 9
02/02/2010 13:54:51
02/02/2010 13:54:51
i
10
FAMILIARISATION
SITTING COMFORTABLY
Also...
5.
Access to the rear seats (3-door).
6. Armrest (except 3-door).
7. Heated seat.
Front seat adjustment Steering wheel adjustment
1. Forwards-backwards adjustment.
2. Height adjustment.
3. Seat back angle adjustment.
4. Head restraint height adjustment.
50
1. Unlocking the control.
2. Adjustment for height and reach.
3. Locking the control.
As a safety precaution, these operations
must only be carried out when stationary.
57
AP_207BB_01_2010_anglais_cag_pdf10 10
AP_207BB_01_2010_anglais_cag_pdf10 10
02/02/2010 13:54:53
02/02/2010 13:54:53
i
11
FAMILIARISATION
SITTING COMFORTABLY
Door mirror adjustment
A. Selecting the mirror.
B. Adjusting the position of the mirror.
C. De-selecting the mirror.
55
Also...
D. Folding/Unfolding.
Rear view mirror adjustment
1. Selecting the "day" position of the
mirror.
2. Adjusting the mirror.
56
Front seat belts
1. Fastening.
2. Height adjustment.
104
AP_207BB_01_2010_anglais_cag_pdf11 11
AP_207BB_01_2010_anglais_cag_pdf11 11
02/02/2010 13:54:55
02/02/2010 13:54:55
12
FAMILIARISATION
SEEING CLEARLY
Lighting
Ring A Switching on "AUTO" mode
)Push the control downwards and re-
lease it.
Ring B
Control A: windscreen wipers
2. Fast wipe.
1. Normal wipe.
I. Intermittent wipe.
0. Park.
AUTO ÈAutomatic wiping or single
wipe.
Wash-wipe: pull the control towards you.
85
Wipers
Switching off "AUTO" mode
)Push the control upwards and return
it to position "0".
87
Ring B: rear wiper
81 86
Lighting off.
Sidelamps.
Dipped/main beam headlamps.
Rear foglamps.
or
Front and rear foglamps.
Park.
Intermittent wipe.
Wash-wipe.
Automatic illumination of head-
lamps.
AP_207BB_01_2010_anglais_cag_pdf12 12
AP_207BB_01_2010_anglais_cag_pdf12 12
02/02/2010 13:54:58
02/02/2010 13:54:58
